| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX This part replaces 532197526. Price: $159.99 |
| 1 |
93-4032 |
SHAFT-JACK Price: $245.00 |
| 2 |
68-3220 |
KEY-STOCK Price: $4.60 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 3 |
79-2000 |
KEY-SQUARE Price: $3.69 |
| 4 |
3243-6 |
SCREW-SET, SQH Price: $4.23 |
| 5 |
3218-3 |
NUT-JAM Price: $0.25 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
13-5520 |
SPACER-SCREW, ADJUSTING Price: $23.41 |
| 10 |
324-7 |
SCREW-HH Price: $1.79 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 11 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 12 |
32128-49 |
NUT-HHF Price: $1.04 |
| 13 |
325-20 |
SCREW-HH Price: $6.29 |
| 14 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 15 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
13-0100 |
PIVOT-LINK, RAKE LIFT Price: $61.98 |
| 17 |
3219-3 |
NUT-HEX Price: $0.34 |
| 18 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 19 |
1-633131 |
YOKE-LINKAGE, BRAKE This part replaces 282-22. Price: $14.99 |
| 20 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
108-0930 |
LIFTING BELL CRANK-RH This part replaces 93-4440. Price: $337.37 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 23 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 24 |
56-6210 |
BEARING Price: $90.04 |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 26 |
3217-8 |
NUT-HEX Price: $1.34 |
| 27 |
13-2680 |
BUSHING Price: $217.68 |
| 28 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 29 |
322-7 |
SCREW-HH Price: $0.89 |
| 32 |
13-0600 |
IDLER ASM Price: $783.75 |
| 33 |
93-7706 |
TUBE-SPACER Price: $30.07 |
| 34 |
3218-5 |
NUT-JAM Price: $0.27 |
| 35 |
3244-21 |
SCREW-SQH Price: $10.59 |
| 36 |
250-5 |
TIE-CABLE Price: $5.19 |
| 37 |
3339-175 |
STRAPPING-WEB This part replaces 94-1445. Price: $18.99 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 38 |
106-5190 |
BATTERY This part replaces 55-7290. Price: $170.85 |
| 39 |
93-7595 |
BATTERY BOX ASM Price: $83.58 |
| 40 |
119-6807 |
DECAL-WARNING This part replaces 61-5950. Price: $7.37 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
13-0480 |
SPRING Price: $30.51 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 42 |
13-3990-01 |
HANDLE-TRIP Price: $189.07 |
| 43 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
108-0928 |
LIFTING BELL CRANK-LH This part replaces 13-5500. Price: $337.37 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
| 45 |
13-0050 |
SPRING-EXTENSION Price: $93.83 |
| 46 |
13-5530 |
ROD-ADJUST, SPRING Price: $67.42 |
| 47 |
13-6790 |
BATTERY CABLE Price: $115.82 |
| 48 |
112-6808 |
CABLE-BATTERY, POSITIVE Price: $70.12 |
| 53 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 55 |
13-4490-01 |
DISCONTINUED This part replaces 13-4490. Price: Call Us |
| 56 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 57 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 58 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 61 |
93-4409-01 |
TONGUE WA This part replaces 93-4409. Price: $481.19 |
| 62 |
327-6 |
SCREW-HH Price: $12.99 |
| 63 |
322-7 |
SCREW-HH Price: $0.89 |
| 64 |
13-2670-01 |
SHEAVE Price: $1,182.76 |
| 65 |
108-0891-01 |
MOUNT-GUARD Price: $156.48 |
| 66 |
56-6230 |
BEARING-ROLLER Price: $72.34 |
| 67 |
140-2208 |
PULLEY-DRIVE This part replaces 93-4033-01. Price: $163.75 |
| 68 |
13-3710 |
WASHER Price: $3.05 |
