| Ref | Part Number | Description |
|---|
| 1 |
92-1724 |
HOSE ASM This part replaces 75-6030. Price: $189.75 |
| 2 |
237-78 |
O-RING Price: $3.85 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 4 |
237-21 |
O-RING Price: $0.70 |
| 5 |
92-1722 |
HOSE ASM This part replaces 75-5980. Price: $97.53 |
| 6 |
75-6000 |
DISCONTINUED Price: Call Us |
| 7 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 8 |
92-1719 |
HOSE ASM This part replaces 75-6190. Price: $165.50 |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 9 |
75-6110 |
HOSE Price: $60.64 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 10 |
75-6040 |
DISCONTINUED Price: Call Us |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 11 |
88-9460 |
HOSE This part replaces 75-6120. Price: $129.98 |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 12 |
75-6100 |
HOSE Price: $109.38 |
| 13 |
340-21 |
FITTING Price: $55.94 |
| 14 |
75-6050 |
HOSE ASSY Price: $135.22 |
| 15 |
532179115 |
TANK.FUEL.5.0 LEFT.FILL.YTGT Price: $89.99 |
| 15 |
92-1727 |
HOSE ASM This part replaces 75-6010. Price: $144.54 |
| 16 |
75-5950 |
DISCONTINUED Price: Call Us |
| 17 |
75-5990 |
DISCONTINUED Price: Call Us |
| 18 |
237-79 |
O-RING Price: $5.46 |
| 18 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 19 |
237-22 |
O-RING Price: $2.43 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 20 |
92-1726 |
HOSE ASM This part replaces 75-5960. Price: $92.84 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 26 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 28 |
532008542 |
FUEL LINE 42" This part replaces 532124703. Price: $5.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 unc Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
532175545 |
TUBE EXHAUST LH Price: $68.99 |
| 71 |
532175546 |
TUBE.EXHAUST.LV675.COMMAND.RH Price: $59.99 |
| 80 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 81 |
532188800 |
TUBE, DRAIN, OIL Price: $2.99 |
| 82 |
532188799 |
VALVE.OIL.DRAIN.GT Price: $45.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
