| Ref | Part Number | Description |
|---|
| 1 |
72050411 |
SUB= 872050411 Price: Call Us |
| 1 |
98-1880-03 |
KNUCKLE-PIVOT This part replaces 98-1880-01. Price: $350.23 |
| 2 |
127423X |
SUB= 140119 Price: Call Us |
| 2 |
99-5610 |
PIN Price: $40.16 |
| 3 |
340-82 |
FITTING-ELBOW, 90 DEG Price: $20.57 |
| 3 |
74641008 |
SUB= 71031008 Price: Call Us |
| 4 |
340-1 |
FITTING-STRAIGHT Price: $10.19 |
| 4 |
73680500 |
SUB= 73690500 Price: Call Us |
| 5 |
104-9250 |
CONTROL-FLOW Price: $404.51 |
| 5 |
105529X |
SUB= 139888 Price: Call Us |
| 6 |
4171R |
CLIP T Price: Call Us |
| 7 |
94-9974 |
RING-RETAINING Price: $0.70 |
| 8 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 8 |
74760612 |
SUB= 74780612 Price: Call Us |
| 9 |
126656X |
SUB= 140551 Price: Call Us |
| 9 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 10 |
138-6952 |
CYLINDER ASM-HYDRAULIC This part replaces 99-2550. Price: $664.52 |
| 11 |
19133210 |
WASHER Price: Call Us |
| 11 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 12 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 12 |
73680600 |
SUB= 73690600 Price: Call Us |
| 13 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 13 |
74780814 |
BOLT Price: Call Us |
| 14 |
10040800 |
LOCKWASHER Price: Call Us |
| 14 |
321-4 |
SCREW-HH Price: $0.99 |
| 15 |
19171912 |
WASHER Price: Call Us |
| 15 |
302-61 |
FITTING-GREASE Price: $10.99 |
| 16 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 17 |
121251X |
STRIP FORM Price: Call Us |
| 17 |
92-7548 |
PIN-CYLINDER Price: $16.62 |
| 18 |
123976X |
SUB= 73900400 Price: Call Us |
| 19 |
121248X |
BUSHING Price: Call Us |
| 20 |
121250X |
SPRING Price: Call Us |
| 21 |
121249X |
SPACER SPLIT Price: Call Us |
| 21 |
82-6840 |
SPACER Price: $3.31 |
| 22 |
121246X |
BRKT SWITCH Price: Call Us |
| 22 |
322-7 |
SCREW-HH Price: $0.89 |
| 23 |
99-2560 |
PIN Price: $105.63 |
| 24 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 25 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 26 |
105-0108 |
LIFT ARM ASM # 3 Price: $587.29 |
| 27 |
105-0107 |
LIFT ARM ASM # 2 Price: $971.54 |
| 28 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 29 |
99-5608-03 |
SPRING-TORSION, RH This part replaces 99-5608. Price: $35.46 |
| 30 |
99-5609-03 |
SPRING-TORSION, LH This part replaces 99-5609. Price: $35.46 |
| 31 |
67-6570 |
SPACER-WHEEL Price: $15.99 |
| 32 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 33 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 34 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 35 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 36 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 37 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 38 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 39 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 40 |
104-3714 |
DISCONTINUED Price: Call Us |
| 41 |
104-3717 |
HYD HOSE ASM Price: $123.78 |
| 42 |
105-0146 |
HYD HOSE ASM Price: $148.67 |
