| Ref | Part Number | Description |
|---|
| 1 |
04001-44 |
Bolt, Hex Head 1/4-20 x 1/2” Price: Call Us |
| 2 |
04020-02 |
Nut, 1/4-20 UNC Price: Call Us |
| 3 |
48029-29 |
Cable, Battery - 18" Red Price: Call Us |
| 4 |
04002-06 |
Screw, M8-1.25 X 16 Shakeproof Price: Call Us |
| 5 |
48029-14 |
Cable, Battery - 31-1/2" Black Price: Call Us |
| 7 |
48126 |
Rubber Boot Price: Call Us |
| 8 |
485506 |
Pad, Battery - Rubber Price: Call Us |
| 9 |
485505 |
Pad, Battery - Rubber Price: Call Us |
| 10 |
04011-14 |
Screw, Self-Tapping 1/4-20 x 3/4 This part replaces 04011-13. Price: Call Us |
| 11 |
483278 |
Solenoid, Sealed Price: Call Us |
| 12 |
04001-08 |
Bolt, Hex Head 5/16-18 x 3/4" Price: Call Us |
| 13 |
04030-03 |
Lockwasher, 5/16" Price: Call Us |
| 14 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 Price: Call Us |
| 15 |
426766 |
Battery Hold Down Price: Call Us |
| 16 |
04017-15 |
Bolt, Hex Head 5/16-18 x 1/2" Serrated Flange Price: Call Us |
| 17 |
04117-01 |
Nut, 5/16-18 Elastic Stop Price: Call Us |
| 18 |
485360 |
Wire Harness Price: Call Us |
| 19 |
04003-12 |
Bolt, Carriage 5/16-18 x 3/4" Price: Call Us |
| 20 |
483474 |
Switch, Double Pole - Twist Price: Call Us |
| 21 |
04011-07 |
Screw, Hex Head 3/8-16 x 1-1/4" Self Tap Price: Call Us |
| 22 |
483629 |
Fuse Holder Price: Call Us |
| 23 |
426726 |
Plate, Anti-Rotation Price: Call Us |
| 24 |
462715 |
Clutch, GT1 Price: Call Us |
| 25 |
04041-28 |
Flatwasher, 7/16-.496 x 1.75 x .25 Price: Call Us |
| 26 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 27 |
04102-06 |
Bolt, Hex Head 7/16-20 x 3" w/Patch Price: Call Us |
| 28 |
484595 |
Pulley, 4-1/2" Dia. - 1" Bore Price: Call Us |
| 29 |
04063-01 |
Key, 1/4 x 1/4 x 1-1/4" Price: Call Us |
| 30 |
483589 |
Diode (part of wire harness) Price: Call Us |
| 31 |
04117-03 |
Nut, 1/4-20 Flange Elastic Stop Price: Call Us |
| 32 |
426727 |
Bracket, Switch Price: Call Us |
| 33 |
483473 |
Switch, Double Pole - Plunger Price: Call Us |
| 34 |
04003-02 |
Bolt, Carriage 1/4-20 x 3/4" Price: Call Us |
| 35 |
04003-04 |
Bolt, Carriage 5/16-181 x 1" Price: Call Us |
| 36 |
04019-03 |
Nut, 5/16-18 Serrated Flange Price: Call Us |
| 37 |
426579 |
Mounting Bracket, Fuel Tank Front Price: Call Us |
| 38 |
04031-03 |
Lockwasher, 5/16" Ext. Price: Call Us |
| 39 |
04041-38 |
Flatwasher, 3/8-.406 x 2.25 x .188 Price: Call Us |
| 40 |
463010 |
Console Tank, SZL This part replaces 485331. Price: Call Us |
| 41 |
483472 |
Ignition Switch Price: Call Us |
| 42 |
462069 |
Key Fob Assembly Price: Call Us |
| 42 |
483609 |
Key w/Shroud Only Price: Call Us |
| 43 |
485216 |
Hourmeter Price: Call Us |
| 44 |
463034 |
SEALED PTO SWITCH KIT This part replaces 483957. Price: Call Us |
| 45 |
483645 |
Throttle Cable Price: Call Us |
| 46 |
04021-26 |
Nut, #10-24 Elastic Stop Price: Call Us |
| 47 |
04003-43 |
Bolt, Carriage #10-24 x 1/2" Price: Call Us |
| 48 |
483646 |
Choke Control Price: Call Us |
| 49 |
483529 |
Wire Harness Adapter, Kawasaki" Price: Call Us |
| 50 |
04030-02 |
Lockwasher, 1/4" Price: Call Us |
| 51 |
04040-14 |
Flatwasher, 1/4-.312 x .750 x .065 Price: Call Us |
| 52 |
462793 |
Instrument Panel w/Decal Price: Call Us |
| 53 |
04024-03 |
Nut, 5/16 Push-On Price: Call Us |
| 55 |
482588 |
Clip, Wire Price: Call Us |
| 56 |
483571 |
Cover, Double Price: Call Us |
