Discharge Chute
Parts (47)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 25_086_11 | Screw-Hex Flange Price: Call Us |
| 2 | X-82-2 | Nut Price: Call Us |
| 3 | 41_468_01 | Washer-Flat Price: Call Us |
| 4 | X-352-33 | Stud Price: Call Us |
| 5 | 25_086_13 | Screw-Hex Flange Price: Call Us |
| 6 | 52_072_12 | Stud Price: Call Us |
| 7 | 25_086_10 | Screw-Hex Flange Price: Call Us |
| 9 | 52_755_57 | Kit-Closure Plate (Incl. Ref. #13) Price: Call Us |
| 10 | X-583-5 | Seal-RearOil Price: Call Us |
| 11 | X-802-9 | Screw-Wash Head Price: Call Us |
| 12 | 52_030_12 | Bearing-Sleeve .020" Price: Call Us |
| 13 | 52_468_03 | Washer-Thrust Price: Call Us |
| 14 | 52_012_09 | Camshaft Price: Call Us |
| 15 | 52_014_64 | Crankshaft Price: Call Us |
| 16 | 52_755_50 | Kit-Oil Relief Price: Call Us |
| 18 | X-269-43 | Ring-Retaining Price: Call Us |
| 19 | 52_078_05 | Shaft-Governor Price: Call Us |
| 20 | X-75-23 | Plug Price: Call Us |
| 21 | 25_086_12 | Screw-Hex Flange Price: Call Us |
| 22 | X-75-10 | Plug Price: Call Us |
| 23 | X-75-32 | Plug-Hex Price: Call Us |
| 24 | 52_032_10 | Seal-ReAR Oil Price: Call Us |
| 25 | X-702-15 | Plug-Cup Price: Call Us |
| 26 | 52_123_10 | Tube-Oil Pickup Price: Call Us |
| 27 | 52_237_05 | Clamp Price: Call Us |
| 28 | X-67-64 | Screw Price: Call Us |
| 29 | 52_139_08 | Plug Price: Call Us |
| 30 | 5223702 | Clip-Spring Price: Call Us |
| 31 | 5209503 | Housing-Oil Price: Call Us |
| 32 | 52_019_03 | Tappet Price: Call Us |
| 52_030_10 | Bearing-Sleeve | Price: Call Us 52_030_10 |
| 52_468_04 | Washer-Thrust | Price: Call Us 52_468_04 |
| 52_468_05 | Washer-Thrust | Price: Call Us 52_468_05 |
| 580 | 601505187 | RING CHUTE Price: $22.99 |
| 581 | 601505188 | SCREW # 10 X .50 Price: $6.99 |
| 582 | 601001386 | CHUTE GUIDE Price: $3.99 |
| 583 | 601505190 | DONUT, FOAM 21 PLAST A Price: $37.99 |
| 590 | 601505191 | LOWER CHUTE-BLACK Price: $59.99 |
| 591 | 601505133 | SCREW 1/4-20X.75 Price: $2.99 |
| 592 | 601505154 | NUT 1/4-20 HEX CONTROL LOCK Price: $3.99 |
| 600 | 601400049 | UPPER CHUTE-GRAY 314704MA This part replaces 601505194. Price: $59.99 |
| 601 | 601001389 | HINGE WIRE Price: $3.99 |
| 602 | 601001390 | BOLT Price: $4.99 |
| 603 | 601400081 | WASHER, FLAT .349X.69 Price: $6.99 |
| 604 | 601400069 | KNOB, WING Price: $12.99 |
| 605 | 601505129 | NUT 5/16-18 Price: $5.99 |
| 606 | 601002038 | SCREW, 5/16-18X.75 Price: $3.99 |
