FUEL TANK & HANDLE
Parts (34)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 530150318 | STARTER HANDLE GRAY Price: $4.99 |
| 2 | 530069232 | KIT-ROPE Price: $4.99 |
| 3 | 530015920 | SCREW Price: $2.99 |
| 4 | 530016080 | SCREW Price: $2.99 |
| 5 | 530069313 | PULLEY 36/41 Price: $5.99 |
| 6 | 545008005 | RETURN SPRING This part replaces 530015891. Price: $4.99 |
| 7 | 530049811 | FAN HOUSING This part replaces 530047599. Price: $17.99 |
| 8 | 530015892 | SCREW,STRTR CVR 36/41 Price: $2.99 |
| 9 | 530015893 | SCREW Price: $4.99 |
| 10 | 530058562 | Decal - Fan Housing Price: $3.33 |
| 11 | 530403257 | LEAD WIRE ASSY Price: $4.99 |
| 12 | 530015896 | SCREW Price: $4.99 |
| 13 | 503717901 | SWITCH ON/OFF Price: $12.99 |
| 15 | 530015127 | WASHER-FLYWHEEL Price: $3.99 |
| 16 | 530016071 | NUT Price: $3.99 |
| 17 | 545121901 | SCREW Price: $2.99 |
| 18 | 575803501 | MODULE This part replaces 530039143. Price: $19.99 |
| 19 | 530029869 | THROTTLE SHAFT 36/41 Price: $4.99 |
| 20 | 530029863 | THROTTLE ACTUATOR 36/41 Price: $2.99 |
| 21 | 530029860 | PIN,TRIGGER 36/41 Price: $3.99 |
| 22 | 530029861 | TRIGGER SPRING 36/41 Price: $4.99 |
| 23 | 530069587 | THROTTLE TRIGGER-KIT Price: $4.99 |
| 24 | 530069247 | HOSE. FUEL Price: $6.99 |
| 25 | 530095646 | FUEL PICK-UP ASSY This part replaces 530014497. Price: $5.99 |
| 26 | 530015940 | SCREW Price: $2.99 |
| 27 | 530029870 | ISOLATOR Price: $10.99 |
| 28 | 530055613 | TANK HANDLE ASSY Price: $49.99 |
| 29 | 530015843 | SCREW Price: $2.99 |
| 30 | 530059961 | HANDLE FRONT This part replaces 530049876. Price: $21.99 |
| 31 | 530052439 | FRONT HANDLE ISOLATOR Price: $3.99 |
| 32 | 530029984 | SHOCK MOUNT(X2) 36/41 Price: $2.99 |
| 33 | 530026119 | VALVE-CHECK (DUCKBILL) Price: $4.99 |
| 34 | 530038264 | BRONZE PLUG Price: $3.99 |
| 35 | 530071266 | FUEL CAP KIT Price: $4.99 |
