| Ref | Part Number | Description |
|---|
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
