| Ref | Part Number | Description |
|---|
| 1 |
127-3071 |
WATER PUMP ASM Price: $827.54 |
| 1 |
547565001 |
SERVICE KIT DECK 38" X428 This part replaces 532411483. Price: $379.99 |
| 3 |
125-6998 |
GASKET Price: $12.33 |
| 4 |
125-6999 |
PLATE Price: $58.91 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
127-3017 |
JOINT Price: $71.31 |
| 10 |
125-7123 |
PLUG Price: $9.86 |
| 11 |
127-3175 |
PLUG Price: $2.87 |
| 11 |
532138497 |
BLADE.HI.LIFT.38" Price: $22.99 |
| 11 |
581116302 |
BLADE.2 IN 1.38"DECK.BLACK This part replaces 532193957. Price: $14.99 |
| 12 |
125-7195 |
PLUG Price: $2.71 |
| 13 |
125-7234 |
SCREW Price: $2.32 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
125-7047 |
GASKET Price: $5.13 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
125-6986 |
JOINT Price: $24.66 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
125-7048 |
O-RING Price: $2.87 |
| 17 |
125-6978 |
GASKET Price: $2.00 |
| 18 |
125-7192 |
GASKET Price: $1.14 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 19 |
93-0362 |
BOLT Price: $3.89 |
| 20 |
125-7214 |
BOLT Price: $3.77 |
| 21 |
125-7219 |
BOLT Price: $4.58 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
125-7222 |
BOLT Price: $4.99 |
| 23 |
125-7039 |
V-PULLEY Price: $23.56 |
| 24 |
127-2998 |
V-BELT Price: $20.88 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
125-7206 |
BOLT Price: $1.97 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
125-7029 |
THERMOSTAT Price: $56.77 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
125-7026 |
GASKET Price: $2.90 |
| 27 |
532192572 |
SHIELD.DEFLECTOR.MOWER.38" This part replaces 532193968. Price: $32.99 |
| 28 |
125-7034 |
COVER Price: $78.09 |
| 29 |
125-7110 |
GASKET Price: $3.76 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
125-7594 |
BOLT Price: $3.00 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
125-6953 |
PLUG Price: $7.59 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
125-7124 |
SENSOR-THERMOSTAT, CW Price: $96.15 |
| 32 |
531170001 |
SERVICE KIT PULLEY PULLEY.MAND This part replaces 532199789. Price: $17.99 |
| 33 |
125-6979 |
GASKET Price: $2.55 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
125-7176 |
WASHER-SEAL Price: $7.31 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
127-3017 |
JOINT Price: $71.31 |
| 36 |
127-3072 |
WATER IN PIPE ASM Price: $51.67 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 38 |
532400140 |
BELT KEEPER.MANDREL.38"COATED This part replaces 532199541. Price: $39.99 |
| 40 |
127-3115 |
WATER OUT PIPE ASM Price: $21.26 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 43 |
127-3116 |
WATER OUT PIPE ASM Price: $47.67 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 44 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
127-3117 |
PIPE-OUT, CW Price: Call Us |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC Price: $11.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
532408381 |
V-BELT Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 115 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 116 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $9.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 144 |
531148901 |
SERVICE.KIT KEEPER BELT KEEPER This part replaces 532193414. Price: $3.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401872 |
SPRING RETURN Price: $4.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $29.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 199 |
531170401 |
SERVICE KIT BAFFLE BAFFLE.VORT This part replaces 532400095. Price: $14.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
