| Ref | Part Number | Description |
|---|
| 1 |
131-2033-01 |
ARM-PITCH, LH This part replaces 121-2244-01. Price: $54.59 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 1A |
631030 |
SHAFT & LEV Price: Call Us |
| 2 |
131-2034-01 |
ARM-PITCH, RH This part replaces 121-2249-01. Price: $54.59 |
| 2 |
631045 |
RET SPRING Price: Call Us |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
121-2251-01 |
SHIELD-TOP Price: $179.89 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
121-2246 |
BRACE-FRAME Price: $53.05 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
115-5227 |
MOTOR ADAPTER ASM Price: $98.96 |
| 7 |
121-2248 |
HOUSING-BEARING Price: $138.75 |
| 7C |
630971 |
SHAFT & LEV Price: Call Us |
| 8 |
532414126 |
TRAY.ASM.BATTERY.FRT.TEX.CARB Price: $27.99 |
| 8 |
94-3405 |
BEARING-BALL Price: $22.27 |
| 9 |
3274-83 |
SCREW-HSH Price: $2.78 |
| 9 |
630758 |
SHUTTER Price: $1.20 |
| 10 |
115-3340 |
WEIGHT ASM Price: $136.76 |
| 10 |
630898 |
ADJ SCREW Price: $1.69 |
| 11 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 11 |
630738 |
SPRING Price: $1.25 |
| 11A |
630738 |
SPRING Price: $1.25 |
| 12 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 12 |
630739 |
WASHER Price: $1.25 |
| 12A |
630739 |
WASHER Price: $1.25 |
| 13 |
117-6706 |
CLAMP-MOTOR Price: $34.81 |
| 13 |
630740 |
O RING Price: $1.49 |
| 13A |
630740 |
O RING Price: $1.49 |
| 14 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 14 |
630898 |
ADJ SCREW Price: $1.69 |
| 15 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 15 |
630748 |
WELCH PLUG Price: $1.17 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 17 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 18 |
631049 |
SPRING Price: $1.20 |
| 19 |
630742 |
GASKET Price: $1.25 |
| 20 |
630932A |
INLET NEEDLE Price: $4.39 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $29.99 |
| 21 |
630750A |
GASKET This part replaces 630750. Price: $3.00 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 22 |
630978 |
DIAPHRAGM Price: $4.49 |
| 23 |
630751 |
COVER Price: $8.60 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $4.99 |
| 24 |
650545 |
SCREW Price: $1.20 |
| 25 |
532412894 |
CABLE.STARTER.6GA.BL/RED.14. Price: $11.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 26A |
632164 |
FUEL FITTING This part replaces 631803. Price: $5.95 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $24.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411933 |
KEY.CHAIN.BLISTER.PACK.GEN.USA Price: $6.99 |
| 33 |
630735 |
SPRING Price: $1.25 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $74.99 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 46 |
586161801 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $17.99 |
| 55 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $24.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT Price: $5.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
532192540 |
SCREW.PLASTITE Price: $2.99 |
| 94 |
532191834 |
MODULE.REVERSE.ROS Price: $22.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
