| Ref | Part Number | Description |
|---|
| 1 |
74760520 |
BOLT Price: Call Us |
| 1 |
99-1644 |
DASH SHROUD ASM Price: $365.54 |
| 2 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 2 |
92-8997 |
COOLER-OIL Price: $512.86 |
| 3 |
10040500 |
LOCKWASHER Price: Call Us |
| 3 |
85-9550 |
RUBBER CLAMP ASM Price: $5.56 |
| 4 |
19121414 |
WASHER Price: Call Us |
| 4 |
85-9670 |
NUT-T Price: $1.63 |
| 5 |
4921H |
SPRING.RETAINER Price: Call Us |
| 5 |
AU218-5106 |
FITTING-ELB 90 This part replaces 353-371. Price: $10.29 |
| 6 |
74610624 |
BOLT.3/8-24X1-1/2 Price: Call Us |
| 6 |
95-0643 |
TUBE-VALVE TO COOLER Price: $45.04 |
| 7 |
318J |
STAKE.SUPT.TILLER Price: Call Us |
| 8 |
767148 |
FILTER CONVERSION KIT This part replaces 95-0610. Price: $112.49 |
| 8 |
9193R |
SUB= 9193R500 Price: Call Us |
| 9 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 9 |
7810H |
GRIPCO NUT Price: Call Us |
| 10 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 10 |
9551R |
DRILLED RIVET RT Price: Call Us |
| 11 |
317J |
SUB= 317J500 Price: Call Us |
| 11 |
322-14 |
SCREW-HH Price: $1.01 |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 12 |
74760512 |
BOLT Price: Call Us |
| 13 |
325J |
STAKE SPRING CT Price: Call Us |
| 13 |
92-7159 |
TREAD-FLOOR, LH Price: $26.24 |
| 14 |
121117X |
BOLT SHOULDER Price: Call Us |
| 14 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 15 |
9186R |
SUB= STD333760 Price: Call Us |
| 15 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 16 |
19131311 |
WASHER Price: Call Us |
| 16 |
95-5807 |
SPACER Price: $10.10 |
| 17 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 17 |
9189R |
SUB= 674H4 Price: Call Us |
| 18 |
322-2 |
SCREW-HH Price: $0.69 |
| 19 |
95-0620-01 |
STRIP-RETAINER Price: $12.71 |
| 20 |
95-5826 |
SHIELD-RUBBER Price: $40.16 |
| 21 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 22 |
95-0582 |
HOSE-INTAKE, AIR Price: $61.51 |
| 23 |
95-5805 |
AIR CLEANER ASM Price: $140.44 |
| 24 |
95-5806 |
BRACKET-MOUNTING Price: $28.01 |
| 25 |
92-7158 |
TREAD-FLOOR, RH Price: $26.24 |
| 26 |
95-5817 |
FRONT SHIELD ASM Price: $354.47 |
| 27 |
106-8103 |
DECAL Price: $36.44 |
| 28 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 30 |
94-4519 |
TUBE-CONVOLUTE Price: $2.24 |
| 31 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 32 |
106-8104 |
DECAL Price: $34.40 |
