Cutting Equipment - Type 4
Parts (40)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 98-9772 | HEAD-FILTER Price: $235.82 |
| 2 | 530029954 | Switch-Ignition Price: $4.99 |
| 2 | 98-9764 | ELEMENT Price: $39.02 |
| 3 | 530071655 | HANDLE This part replaces 530071656. Price: $23.99 |
| 3 | 98-9774 | O-RING Price: $20.04 |
| 4 | 530015611 | Washer-Clutch Price: $1.99 |
| 4 | 98-9775 | BASE-FILTER Price: $115.28 |
| 5 | 530057740 | CLUTCH ASSY This part replaces 530071803. Price: $14.99 |
| 5 | 98-9773 | PLUG-BASE, FILTER Price: $34.25 |
| 6 | 237-42 | O-RING Price: $2.78 |
| 6 | 530150583 | Assy-Drum Price: $8.99 |
| 7 | 237-78 | O-RING Price: $3.85 |
| 8 | 530015886 | Screw Price: $1.99 |
| 8 | 98-9776 | PLUG-HEAD, FILTER Price: $23.26 |
| 9 | 530016013 | Bearing-Gear Price: $2.99 |
| 9 | 98-9777 | DRAIN VALVE ASM Price: $74.38 |
| 10 | 530096009 | Assy-Pinion Price: $14.99 |
| 11 | 530015886 | Screw This part replaces 530015805. Price: $1.99 |
| 12 | 530032121 | Bushing-Blade Price: $2.99 |
| 13 | 530015940 | Screw Price: $1.99 |
| 14 | 530036046 | Plate-Isolator Price: $4.99 |
| 15 | 530015849 | Screw Price: $1.99 |
| 16 | 530015934 | Screw Price: $1.99 |
| 17 | 530016472 | Screw Price: $2.99 |
| 18 | 530029916 | Cover-Gear Box Plate Price: $2.99 |
| 20 | 530029948 | Seal-Blade (Felt) Price: $1.99 |
| 21 | 530403228 | Assy-Blade 19" Price: $29.99 |
| 22 | 545009101 | Nut Price: $1.99 |
| 23 | 530029946 | Spring Price: $1.99 |
| 24 | 577858601 | FUEL CAP ASSY W/RET LW PRM This part replaces 530014871. Price: $3.99 |
| 25 | 530016406 | Screw Price: $1.99 |
| 26 | 530053900 | Lockout-Throttle Price: $1.99 |
| 27 | 530015934 | Screw Price: $1.99 |
| 28 | 545008001 | Kit-Handle Cover Price: $14.99 |
| 29 | 530015940 | Screw Price: $1.99 |
| 30 | 530015775 | Screw Price: $1.99 |
| 31 | 530057818 | Lever-Trigger Price: $2.99 |
| 32 | 530036123 | Spring-Trigger Price: $1.99 |
| 33 | 530053884 | Trigger Price: $1.99 |
| 34 | 530094992 | Handle-Front Price: $6.99 |
