| Ref | Part Number | Description |
|---|
| 2 |
532146682 |
SPRING,BRAKE RETURN Price: $4.99 |
| 3 |
532123666 |
PULLEY TRANS Price: $22.99 |
| 4 |
532002267 |
Ring, Retaining This part replaces 812000028. Price: $3.99 |
| 5 |
532121520 |
STRAP TORQUE Price: $3.99 |
| 6 |
532171877 |
Bolt 5/16-18 unc x 3/4 This part replaces 817060512. Price: $3.99 |
| 8 |
532192706 |
ROD SHIFT FENDER ADJUST LT Price: $19.99 |
| 10 |
876020416 |
PIN COTTER Price: $3.99 |
| 10 |
98-9459 |
CAMSHAFT-FUEL Price: $159.71 |
| 11 |
532105701 |
WASH-SHFT PLT LT Price: $3.99 |
| 13 |
871040412 |
Bolt, Shift Plate This part replaces 874550412. Price: $3.99 |
| 14 |
810040400 |
LOCKWASHER Price: $3.99 |
| 15 |
874490540 |
BOLT Price: $2.99 |
| 16 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.69 |
| 18 |
874780616 |
BOLT Price: $3.99 |
| 19 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 20 |
107-9077 |
BEARING-BALL Price: $81.95 |
| 21 |
532106933 |
KNOB T (1/2-HOLE) Price: $3.99 |
| 22 |
532130804 |
ROD BRAKE Price: $17.99 |
| 24 |
873220600 |
Nut, Hex 3/8-16 This part replaces 873350600. Price: $3.99 |
| 25 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 26 |
819131316 |
WASHER Price: $2.99 |
| 27 |
876020412 |
COTTER PIN Price: $3.99 |
| 28 |
532175765 |
ROD, PARKING BRAKE Price: $3.99 |
| 29 |
532071673 |
PLUNGER CAP Price: $3.99 |
| 30 |
107-9078 |
BEARING-BALL Price: $81.95 |
| 30 |
532130807 |
Bracket, Transaxle This part replaces 532174973. Price: $3.99 |
| 32 |
539976934 |
HCS.5/16-18X3/4 This part replaces 874760512. Price: $1.99 |
| 34 |
532175578 |
SHAFT, FOOT PEDAL Price: $19.99 |
| 35 |
532120183 |
BEARING.NYLON Price: $2.99 |
| 36 |
819211616 |
WASHER LT Price: $3.99 |
| 37 |
532002882 |
DRIVE PIN This part replaces 532124963. Price: $2.99 |
| 38 |
532179114 |
PULLEY IDLER COMPOSITE Price: $19.99 |
| 39 |
872110622 |
BOLT Price: $3.99 |
| 41 |
532175556 |
KEEPER, BELT IDLER Price: $5.99 |
| 47 |
532139245 |
Pulley, Idler V Groove This part replaces 532127783. Price: $22.99 |
| 48 |
532154407 |
BELLCRANK, CLUTCH Price: $4.99 |
| 49 |
532123205 |
RETAIN BELT Price: $3.99 |
| 50 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 51 |
873680600 |
LOCKNUT Price: $1.99 |
| 52 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 53 |
532199652 |
LINK.CLUTCH.7.66.2005 Price: $8.99 |
| 55 |
532105709 |
SPRING, RETURN LT Price: $7.99 |
| 56 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 57 |
532138255 |
BELT, V GROUND DRIVE 95 25 Price: $25.99 |
| 60 |
98-9590 |
NUT-CAP Price: $3.86 |
| 62 |
532008883 |
Cover, Pedal This part replaces 532124872. Price: $3.49 |
| 63 |
532175410 |
ENGINE PULLEY Price: $50.99 |
| 64 |
532150280 |
SUB= 150280 This part replaces 532173937. Price: $3.99 |
| 65 |
539990247 |
LOCKWASHER.7/16 This part replaces 810040700. Price: $1.99 |
| 66 |
532154778 |
KEEPER BELT ENGINE Price: $8.99 |
| 69 |
532142432 |
SCREW.HI-LO.CONSOLE Price: $3.99 |
| 70 |
532134683 |
KEEPER BELT ENG Price: $5.99 |
| 70 |
98-9669 |
GEAR-PUMP, INJECTION Price: $86.00 |
| 74 |
532137057 |
SPACER AXLE Price: $3.99 |
| 75 |
532121749 |
WASHER Price: $1.99 |
| 76 |
812000001 |
E-RING LT Price: $2.99 |
| 77 |
532123583 |
SQUARE KEY Price: $2.69 |
| 78 |
532121748 |
WASHER Price: $1.99 |
| 79 |
532125096 |
KEY STD Price: $3.99 |
| 80 |
532131486 |
ARM SHIFT Price: $2.99 |
| 80 |
98-9595 |
KEY-WOODRUFF Price: $2.04 |
| 81 |
532165594 |
Price: $22.99 |
| 82 |
532165711 |
SHIFT SPRING Price: $3.99 |
| 83 |
734117771 |
BUSHING This part replaces 819171216. Price: $2.99 |
| 84 |
532166228 |
Price: $38.99 |
| 85 |
873610400 |
NUT This part replaces 532150360. Price: $2.99 |
| 89 |
532194971 |
CONSOLE SHIFT STLT Price: $10.99 |
| 90 |
98-9511 |
STOPPER-FUEL, CAMSHAFT Price: $5.18 |
| 96 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 100 |
98-7692 |
BOLT Price: $0.92 |
| 110 |
98-9644 |
GOVERNOR SHAFT ASM Price: $527.54 |
| 112 |
734115201 |
WASHER - M6 This part replaces 819091210. Price: $1.99 |
| 113 |
532127285 |
STRAP TORQUE LH LT Price: $3.99 |
| 116 |
872110608 |
Bolt, Carriage 3/8-16 x 1 Gr. 5 This part replaces 872140608. Price: $3.99 |
| 120 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 120 |
98-9562 |
HOLDER-GEAR, GOVERNOR Price: $61.49 |
| 130 |
98-9673 |
GEAR-GOVERNOR Price: $137.25 |
| 140 |
98-9561 |
HOLDER-WEIGHT, GOVERNOR Price: $23.68 |
| 150 |
532175456 |
SPACER, RETAINER Price: $3.99 |
| 150 |
98-9559 |
GOVERNOR WEIGHT ASM Price: $105.15 |
| 151 |
532413524 |
WASHER.13/32 X 1 X 1/2.11GUARD This part replaces 819133210. Price: $2.99 |
| 156 |
532166002 |
WASHER.SRRTD.5/16 Price: $3.99 |
| 158 |
532437458 |
BRACKET.SHIFT.MOUNT This part replaces 532165589. Price: $3.99 |
| 159 |
532444304 |
HUB.SHIFT This part replaces 532183900. Price: $4.99 |
| 160 |
98-9560 |
SHAFT-WEIGHT, GOVERNOR Price: $6.17 |
| 161 |
872110407 |
BOLT, HEX HEAD This part replaces 872140406. Price: $2.99 |
| 162 |
873680400 |
NUT.CROWNLOCK.1/4 Price: $2.69 |
| 163 |
874780416 |
BOLT Price: $3.99 |
| 165 |
532438250 |
BRACKET.PIVOT.LEVER This part replaces 532165623. Price: $4.99 |
| 166 |
817490510 |
SCREW Price: $2.99 |
| 168 |
532165492 |
BOLT.SHOULDER.5/16-18X Price: $3.99 |
| 169 |
532165581 |
PLATE FASTENING LT Price: $2.99 |
| 170 |
532187414 |
KEEPER BELT T/A Price: $8.99 |
| 170 |
98-9692 |
ROLLER Price: $11.45 |
| 180 |
98-9563 |
SLEEVE-GOVERNOR Price: $29.68 |
| 190 |
98-9564 |
WASHER-THRUST Price: $5.01 |
| 197 |
532169613 |
NYLINER SNAP 5/8" ID Price: $3.99 |
| 198 |
532169845 |
WASHER NYL Price: $2.99 |
| 200 |
107-9079 |
BEARING-BALL Price: $81.78 |
| 202 |
872110614 |
BOLT Price: $3.99 |
| 210 |
98-9657 |
CIRCLIP-SHAFT, GOVERNOR Price: $4.48 |
| 263 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 268 |
532182402 |
Price: $4.99 |
