| Ref | Part Number | Description |
|---|
| 1 |
112-5267 |
FITTING-SUCTION This part replaces 104-5604. Price: $62.39 |
| 1 |
144927 |
Battery Price: Call Us |
| 2 |
2412-80 |
CLAMP-HOSE Price: $4.39 |
| 2 |
74760412 |
Bolt Hex Head 1/4-20 x 3/4 Price: Call Us |
| 3 |
110-4109 |
HOSE-FUEL This part replaces 39-1120. Price: $11.24 |
| 4 |
104-5605 |
FITTING-RETURN Price: $50.63 |
| 5 |
110-0471 |
HOSE-FUEL This part replaces 105-9242. Price: $25.93 |
| 6 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 7 |
46-6560 |
BUSHING Price: $2.94 |
| 8 |
186491 |
Box Battery Price: Call Us |
| 10 |
104-5601 |
FUEL TANK ASM Price: $694.96 |
| 11 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 12 |
63-8410 |
WASHER Price: $1.76 |
| 13 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
98-7612 |
FILTER-FUEL Price: $10.48 |
| 15 |
104-5215 |
PUMP-FUEL, ELECTRIC Price: $264.12 |
| 16 |
176138 |
Switch Interlock Push-In Price: Call Us |
| 16 |
2412-138 |
R-CLAMP Price: $1.36 |
| 17 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 18 |
2412-148 |
CLAMP-R Price: $2.71 |
| 19 |
108-3283 |
HOSE-FUEL This part replaces 105-9196. Price: $4.60 |
| 20 |
109-0309 |
HOSE-FUEL This part replaces 93-2230. Price: $18.99 |
| 21 |
175688 |
Harness Socket Light W/4152J Price: Call Us |
| 22 |
4152J |
Bulb Light Price: Call Us |
| 24 |
400253 |
Cable Battery Price: Call Us |
| 25 |
198893 |
Cable Start Red 17.5" Price: Call Us |
| 26 |
175158 |
Fuse Price: Call Us |
| 27 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 28 |
145491 |
Cable, Ground Price: Call Us |
| 29 |
401545 |
Switch, Seat Price: Call Us |
| 30 |
193350 |
Switch, Ignition Price: Call Us |
| 33 |
140401 |
Key, Ignition Price: Call Us |
| 34 |
110712X |
Switch Light / Reset Price: Call Us |
| 40 |
194276 |
Harness Ignition Price: Call Us |
| 41 |
17720408 |
Screw Thd Cut 1/4-20 x 1/2 Price: Call Us |
| 42 |
131563 |
Cover, Terminal Price: Call Us |
| 43 |
192507 |
Solenoid Price: Call Us |
| 46 |
198138 |
Gauge Hourmeter Price: Call Us |
| 50 |
174653 |
Switch, PTO Price: Call Us |
| 55 |
17490512 |
Screw Thdrol 5/16-18 x 3/4 TYTT Price: Call Us |
| 59 |
400303 |
Outlet 12-Volt Price: Call Us |
| 71 |
400260 |
Harness Ign. Dash Price: Call Us |
| 79 |
175242 |
Bulbholder Asm. Incan Descent Price: Call Us |
| 90 |
180449 |
Cover Terminal Battery Price: Call Us |
| 91 |
190270 |
Strap Battery Mount Front Price: Call Us |
| 99 |
17670412 |
Screw Hexwsh Thdrol 1/4-20 x 3/4 Price: Call Us |
