| Ref | Part Number | Description |
|---|
| 1 |
106-8085 |
SUSPENSION ASM Price: $723.03 |
| 2 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 3 |
106-1031 |
TENSION ADJUSTER KNOB ASM Price: $68.93 |
| 5 |
951-11622A |
FLEXIBLE CLAMP This part replaces 951-11622. Price: $3.42 |
| 6 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 7 |
76-2940 |
BUMPER Price: $9.73 |
| 8 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 9 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 10 |
108-6702 |
ADJUSTER-SEAT, W/HANDLE This part replaces 66-8510. Price: $239.09 |
| 11 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 13 |
32128-25 |
NUT-HF Price: $3.19 |
| 15 |
93-3163 |
SPRING Price: $26.01 |
| 75 |
951-12238 |
Crankshaft Assembly Price: $258.60 |
| 76 |
951-11969 |
Main Bearing Price: $28.22 |
| 77 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 79 |
951-12239 |
Dipstick Assembly Price: $26.61 |
| 80 |
951-12241 |
Upper O-Ring Price: $3.49 |
| 81 |
951-12363 |
Lower O-Ring Price: $3.49 |
| 82 |
951-12240 |
Oil Fill Tube Assembly Price: $16.00 |
| 83 |
710-04980 |
Bolt M6×35 Price: $3.42 |
| 84 |
951-11644 |
ENGINE PLUG 3/8 NPT This part replaces 710-05311. Price: $8.96 |
| 85 |
951-12242 |
Regulator Price: $46.13 |
| 86 |
715-04121 |
Dowel Pin 8×14 Price: $3.56 |
| 87 |
951-12243 |
Ball 6.35 Price: $3.21 |
| 88 |
951-12244 |
Spring Price: $3.46 |
| 89 |
710-05312 |
Bolt Price: $4.09 |
| 90 |
736-04557 |
Crankshaft Thrust Washer Price: $3.52 |
| 91 |
951-12245 |
Balanceable Shaft Bearing Price: $26.77 |
| 92 |
751-12246 |
Balanceable Shaft Assembly Price: $140.57 |
| 93 |
736-04559 |
Balanceable Thrust Washer Price: $3.56 |
| 98 |
951-12248 |
Oil Pump Assembly Price: $59.85 |
| 99 |
951-12247 |
O-Ring 10×2.65 Price: $3.60 |
| 100 |
951-12249 |
Filter Price: $3.35 |
| 101 |
951-12250 |
Filter Spring Price: $3.49 |
| 102 |
951-12251 |
O-Ring 35.5×2.65 Price: $3.60 |
| 103 |
951-12252 |
Filter Cover Price: $5.79 |
| 104 |
951-11956 |
Governor Gear/Shaft Assembly Price: $36.12 |
| 112 |
710-05313 |
Bolt M8×15 Price: $3.56 |
| 113 |
736-04560 |
Oil Drain Plug Washer Price: $3.68 |
| 114 |
951-12690 |
Oil Filter Price: $15.89 |
| 115 |
951-12253 |
Screw Joint Price: $6.87 |
| 116 |
919-05090 |
Crankcase Cover Price: $123.86 |
| 117 |
710-04982 |
Bolt M8×54 Price: $3.37 |
| 118 |
951-11375A |
OIL SEAL This part replaces 951-11375. Price: $13.55 |
| 119 |
710-05314 |
Bolt M8×43 Price: $3.24 |
