| Ref | Part Number | Description |
|---|
| 1 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
87-3470 |
BUMPER Price: $18.89 |
| 3 |
110-5072 |
BOLT-SHOULDER Price: $26.52 |
| 4 |
3217-8 |
NUT-HEX Price: $1.34 |
| 5 |
107-8667 |
DECAL-JACKING Price: $14.57 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
93-6161 |
WASHER Price: $3.68 |
| 7 |
121-5089-03 |
PLATE-TOP, SPRING Price: $34.56 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
127-2913 |
SPACER Price: $11.26 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
26-0672 |
BOLT-BLADE Price: $3.94 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
325-12 |
SCREW-HH Price: $2.27 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532174894. Price: $17.99 |
| 11 |
121-9774 |
ABSORBER-SHOCK Price: $110.25 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 12 |
99-0569 |
SPRING LEAF This part replaces 99-0570. Price: $176.73 |
| 13 |
42574 |
SHACKEL-OUTSIDE Price: $7.32 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
87-7480 |
WASHER Price: $1.26 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
106-0327 |
NUT-HEX Price: $0.41 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
42576 |
SHACKEL-INSIDE Price: $7.18 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
42592 |
BUSHING-SHACKLE Price: $31.94 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 19 |
93-6166 |
NUT-HEX Price: $0.41 |
| 20 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
87-3920 |
BUSHING Price: $1.48 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
