| Ref | Part Number | Description |
|---|
| 6 |
139-3209 |
DECAL - DECK Price: $5.71 |
| 7 |
139-2448-03 |
BAFFLE-CORNER Price: $15.65 |
| 8 |
138-9753 |
SCREW Price: $0.39 |
| 9 |
139-3214 |
SPINDLE ASM Price: $51.71 |
| 10 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 11 |
117-7268 |
SHAFT-SPINDLE Price: $19.98 |
| 12 |
133-1199 |
PULLEY Price: $25.89 |
| 13 |
3219-6 |
NUT-HEX Price: $2.78 |
| 14 |
115-9649-03 |
BLADE-HI FLOW Price: $24.61 |
| 16 |
145-0411 |
BOLT-BLADE, SEMS Price: Call Us |
| 17 |
132-9420 |
PULLEY-IDLER, FLAT Price: $25.16 |
| 18 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 19 |
323-9 |
SCREW-HH Price: $1.29 |
| 20 |
110-9981 |
WASHER-PLAIN Price: $13.99 |
| 21 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 22 |
114-0463 |
WASHER-FRICTION, COMPOSITE Price: $4.79 |
| 23 |
115-4986 |
SPACER Price: $1.39 |
| 24 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 25 |
138-7262 |
ARM-IDLER Price: $12.02 |
| 26 |
109-3661 |
BELT Price: $68.94 |
| 27 |
137-2019 |
ROD-PIVOT Price: $8.15 |
| 28 |
138-7502 |
DEFLECTOR-DISCHARGE Price: $41.95 |
| 29 |
138-7268 |
SPRING-TORSION Price: $1.69 |
| 30 |
138-9800-03 |
BAFFLE-CUTOFF Price: $6.71 |
| 31 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 32 |
1-603299 |
ROLLER-SCALP, ANTI Price: $21.99 |
| 33 |
112-3977 |
BOLT-SHOULDER Price: $7.37 |
| 34 |
138-7266 |
SPRING-RETURN, HOOK Price: $2.95 |
| 35 |
138-7264 |
SPRING-EXTENSION Price: $5.10 |
| 36 |
133-9282 |
COVER-BELT, LH Price: $14.23 |
| 37 |
133-9283 |
COVER-BELT, RH Price: $12.93 |
| 39 |
133-9289 |
FITTING-WASHOUT Price: $3.86 |
| 40 |
32144-4 |
SCREW-HWH Price: $1.29 |
