| Ref | Part Number | Description |
|---|
| 1 |
322-7 |
SCREW-HH Price: $0.89 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $219.99 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
13-2970 |
BUSHING Price: $182.26 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
13-2800 |
SHEAVE Price: $961.42 |
| 5 |
13-2240 |
KEY-SQUARE Price: $14.31 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
13-3790 |
FAN SHAFT Price: $671.39 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
3217-7 |
NUT-HEX Price: $0.28 |
| 9 |
13-2810 |
SQUARE KEY Price: $31.13 |
| 10 |
13-3350-01 |
MOUNTING BRKT This part replaces 13-3350. Price: $59.51 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 12 |
13-3850-01 |
BOOT-BLOWER This part replaces 13-3850. Price: $344.08 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
321-4 |
SCREW-HH Price: $0.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
121-2839 |
DECAL-CAUTION This part replaces 13-6410. Price: $25.19 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
3244-14 |
SCREW-SET, SQH Price: $7.19 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
3218-5 |
NUT-JAM Price: $0.27 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
117-4979 |
DECAL-WARNING This part replaces 92-8309. Price: $12.04 |
| 19 |
121-2843 |
DECAL-WARNING This part replaces 93-7307. Price: $21.34 |
| 20 |
121-2842 |
DECAL-INSTRUCTION This part replaces 93-4041. Price: $31.63 |
| 21 |
13-3420-03 |
FAN ASM This part replaces 13-3420. Price: $2,196.74 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 22 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 23 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 24 |
325-6 |
SCREW-HH Price: $1.42 |
| 24 |
532177946 |
TRACK SLIDE, SEAT(L) Price: $59.99 |
| 25 |
532177947 |
TRACK SLIDE, SEAT(R) Price: $119.99 |
| 25 |
56-6220 |
BEARING Price: $122.98 |
| 26 |
596039901 |
Washers This part replaces 819111012. Price: $2.99 |
| 27 |
32153-5 |
NUT-HEX Price: $1.59 |
| 28 |
810010500 |
WASHER Price: $3.99 |
| 30 |
13-1420-01 |
COVER-INSPECTION This part replaces 13-1420. Price: $31.70 |
| 31 |
32103-12 |
NUT-WING Price: $1.15 |
| 32 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 33 |
119-6263 |
BLOWER AND THROAT ASM This part replaces 13-6280. Price: $7,479.09 |
| 33 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 34 |
323-6 |
SCREW-HH Price: $0.66 |
| 35 |
13-6390-01 |
HANDLE-FLAP This part replaces 13-6390. Price: $134.01 |
| 35 |
583670601 |
CAP.VINYL.BLK.SERVICE This part replaces 532178426. Price: $2.99 |
| 36 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 37 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 38 |
13-6360 |
ROD-LIFT, FLAP Price: $118.60 |
| 39 |
3218-6 |
NUT-JAM Price: $0.61 |
| 40 |
13-0330 |
BLOCK-PIVOT Price: $112.26 |
| 41 |
323-9 |
SCREW-HH Price: $1.29 |
| 42 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 43 |
321-3 |
SCREW-HH Price: $0.28 |
| 44 |
95-3112-01 |
LOWER FLAP BLADE ASM This part replaces 95-3112. Price: $682.32 |
| 45 |
13-3130 |
END-FLAP Price: $26.55 |
| 46 |
321-5 |
SCREW-HH Price: $0.22 |
| 47 |
13-4700 |
LOWER FLAP ASM Price: $1,182.39 |
| 48 |
13-4560-03 |
WEIGHT-FLAP This part replaces 13-4560. Price: $25.30 |
| 49 |
321-8 |
SCREW-HH Price: $0.34 |
| 50 |
13-1390-01 |
RETAINER-FLAP This part replaces 13-1390. Price: $96.90 |
| 51 |
3217-5 |
NUT-HEX Price: $0.25 |
| 53 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 54 |
13-4800-01 |
BELT GUARD WA This part replaces 13-4800. Price: $1,224.67 |
| 55 |
321-4 |
SCREW-HH Price: $0.99 |
| 56 |
323-7 |
SCREW-HH Price: $0.65 |
| 57 |
93-0183 |
BELT-V, IMPELLER Price: $173.29 |
| 58 |
325-7 |
SCREW-HH Price: $1.53 |
| 67 |
93-4020-01 |
COVER-INSPECTION This part replaces 93-4020. Price: $28.77 |
| 68 |
93-7708 |
STRIP-SEAL Price: $10.93 |
| 69 |
93-7707 |
SHIELD - BELT GUARD Price: $11.09 |
| 70 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 71 |
32128-32 |
NUT-HHF Price: $2.69 |
