| Ref | Part Number | Description |
|---|
| 1 |
100-6131 |
SEAL KIT This part replaces 94-8178. Price: $102.14 |
| 1 |
532123385 |
Pulley Price: $22.99 |
| 2 |
532002267 |
Ring, Retaining This part replaces 812000028. Price: $3.99 |
| 3 |
532170269 |
TRANSAXLE 6 SPEED This part replaces 532142603. Price: $454.99 |
| 4 |
532125096 |
Key, Woodruff #9 Price: $3.99 |
| 5 |
873800500 |
Nut,Lock Hex w/Ins 5/16-18 Price: $2.69 |
| 6 |
539990316 |
RHSNB.5/16-18.X3/4.GR.5.ZD This part replaces 872140506. Price: $1.49 |
| 7 |
532123378 |
Strap, Torque Price: $2.99 |
| 8 |
539976934 |
HCS.5/16-18X3/4 This part replaces 817490512. Price: $1.99 |
| 8 |
76-1040 |
SCREW-CAP, HH Price: $2.75 |
| 9 |
532146682 |
Spring Return Brake This part replaces 532110422. Price: $4.99 |
| 9 |
76-0820 |
LINE-DRIVE Price: $322.75 |
| 10 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Gauge Price: $1.99 |
| 10 |
76-0810 |
HOUSING ASM Price: $1,097.49 |
| 11 |
532123583 |
Key, Square Price: $2.69 |
| 12 |
874760644 |
Bolt, Hex, Fin. 3/8-16 Unc x 2-3/4 Price: $3.99 |
| 15 |
532052160 |
Washer This part replaces 819171616. Price: $3.99 |
| 16 |
532124600 |
Support Handle Shift, LH Price: $2.38 |
| 16 |
76-0890 |
END COVER ASM Price: $981.97 |
| 17 |
532123632 |
Link, Shift Price: $14.99 |
| 17 |
76-0830 |
ROTOR SET Price: $1,566.85 |
| 18 |
76-0840 |
MANIFOLD Price: $790.28 |
| 18 |
871040412 |
Bolt, Hex, Fin. 1/4-28 UNF x 3/4 Grade 8 Price: $3.99 |
| 19 |
76-0850 |
BEARING-THRUST Price: $30.56 |
| 19 |
810040400 |
Washer, Lock 1/4 Price: $3.99 |
| 20 |
734115201 |
WASHER - M6 This part replaces 819091210. Price: $1.99 |
| 20 |
76-0860 |
SHAFT-COUPLING Price: $688.74 |
| 21 |
532123539 |
Arm, Shift Price: $2.38 |
| 21 |
92-9754 |
PLATE-WEAR This part replaces 76-0870. Price: $359.13 |
| 22 |
3257-42 |
KEY-WOODRUFF Price: $5.99 |
| 22 |
532105701 |
Washer, Shift Plate Price: $3.99 |
| 23 |
532121274 |
Knob, Duckhead Price: $5.99 |
| 24 |
532128215 |
Rod Assembly, Shift Price: $20.99 |
| 25 |
876020416 |
Pin, Cotter 1/8 x 1 Price: $3.99 |
| 26 |
873610500 |
NUT This part replaces 873810500. Price: Call Us |
| 27 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873510500. Price: $2.69 |
| 28 |
532128085 |
Extension, Spring Price: $4.99 |
| 29 |
532128084 |
Support Handle Shift, RH Price: $2.38 |
| 31 |
532109502 |
Spacer Split Price: $3.99 |
| 33 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
