| Ref | Part Number | Description |
|---|
| 1 |
77-4150 |
L/H FRT BRACKET WA *B Price: $80.39 |
| 2 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S This part replaces 580532301. Price: $39.99 |
| 3 |
77-4120 |
R/H FRT BRKT WA *B Price: $98.25 |
| 4 |
218-492 |
ROSE BUD CLIP Price: $1.58 |
| 5 |
80-3390 |
WIRE HARNESS Price: $354.96 |
| 6 |
218-456 |
FLASHER Price: $37.40 |
| 7 |
321-2 |
SCREW-HH Price: $2.79 |
| 8 |
28-4110 |
SWITCH-LIGHT Price: $41.30 |
| 9 |
218-498 |
NUT-LOCK Price: $0.68 |
| 9 |
596501502 |
Keepers This part replaces 584908001. Price: $9.99 |
| 10 |
218-497 |
DISCONTINUED PLEASE SEE NOTES Price: Call Us |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 11 |
77-4250 |
DISCONTINUED Price: Call Us |
| 12 |
48-7890 |
NUT-HEX Price: $0.25 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 14 |
32122-30 |
SCREW-PTH Price: $0.28 |
| 15 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 16 |
77-4100 |
DISCONTINUED Price: Call Us |
| 17 |
63-7590 |
RELAY Price: $78.15 |
| 18 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE Price: $27.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 108 |
583400501 |
COVER.PULLEY.ENGINE.SRD.FRENCH This part replaces 532423041. Price: $89.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
