| Ref | Part Number | Description |
|---|
| 1 |
105-2917 |
INSTRUMENT PANEL ASM Price: $119.85 |
| 1 |
140064 |
SPRING CLUTCH MWR Price: Call Us |
| 2 |
165723 |
SPACER.RETAINER.MOWER Price: Call Us |
| 2 |
98-9339 |
GAUGE-FUEL Price: $115.28 |
| 3 |
104-3438 |
DISCONTINUED Price: Call Us |
| 3 |
73680600 |
SUB= 73690600 Price: Call Us |
| 4 |
130840 |
BRAKE ASM Price: Call Us |
| 4 |
32128-30 |
NUT Price: $2.69 |
| 5 |
131251 |
IDLER BELT GUIDE Price: Call Us |
| 5 |
322-3 |
SCREW-HH Price: $0.79 |
| 6 |
121316X |
PULLEY IDLER Price: Call Us |
| 6 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 7 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 7 |
72110616 |
BOLT Price: Call Us |
| 8 |
19131410 |
WASHER Price: Call Us |
| 8 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 9 |
106-5190 |
BATTERY This part replaces 63-9230. Price: $170.85 |
| 9 |
127744 |
SUB= 140092 Price: Call Us |
| 10 |
104-9497 |
CABLE-BATTERY, NEGATIVE Price: $75.01 |
| 10 |
72140610 |
BOLT.3/8-14X1.25 Price: Call Us |
| 11 |
130841 |
BRAKE ROD Price: Call Us |
| 11 |
95-8853 |
CABLE-BATTERY, POSITIVE Price: $95.21 |
| 12 |
24-6420-03 |
HOLDDOWN-BATTERY Price: $55.90 |
| 13 |
24-6390 |
STUD-HOLDDOWN, BATTERY Price: $19.83 |
| 13 |
72140506 |
BOLT Price: Call Us |
| 14 |
3217-6 |
NUT-HEX Price: $1.19 |
| 14 |
73680500 |
SUB= 73690500 Price: Call Us |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 16 |
32103-2 |
NUT-WING Price: $0.68 |
| 17 |
128508 |
MOWER LINK STAB Price: Call Us |
| 18 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 19 |
112-6561 |
WARNING LIGHT ASM This part replaces 98-9306. Price: $121.84 |
| 20 |
98-9308 |
GAUGE-TEMPERATURE Price: $112.90 |
| 21 |
100-8072 |
SWITCH Price: $94.07 |
| 21 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 22 |
10030600 |
SUB= 10040600 Price: Call Us |
| 22 |
104-2541 |
SWITCH ASM Price: $36.70 |
| 23 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 23 |
850857 |
BLADE BOLT Price: Call Us |
| 24 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 24 |
43-3990 |
CONTROL-THROTTLE Price: $49.39 |
| 25 |
3290-134 |
SCREW Price: $0.27 |
| 26 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 27 |
105-0002-01 |
BRACKET-RELAY Price: $34.06 |
| 28 |
153531 |
PULLEY.MAND.36/46 Price: Call Us |
| 28 |
70-1480 |
RELAY Price: $105.19 |
| 29 |
137266 |
SUB= 139729 Price: Call Us |
| 29 |
98-7611 |
CONTROLLER-GLOW Price: $316.53 |
| 30 |
136631 |
SUB= 532136631 Price: Call Us |
| 30 |
37-2690 |
CAPACITOR Price: $155.98 |
| 31 |
17490508 |
SCREW LT Price: Call Us |
| 31 |
2412-74 |
R-CLAMP Price: $2.37 |
| 32 |
321-4 |
SCREW-HH Price: $0.99 |
| 33 |
131560X428 |
SHIELD, DEFLECTOR Price: Call Us |
| 33 |
32128-33 |
NUT-HF Price: $0.25 |
| 34 |
98-9321 |
RING-KEY Price: $1.80 |
| 36 |
121980X |
HINGE ROD Price: Call Us |
| 37 |
123713X |
SPRING TORSION Price: Call Us |
| 38 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 39 |
19111016 |
WASHER Price: Call Us |
| 40 |
110452X |
NUT PUSH M Price: Call Us |
| 41 |
131264 |
V-BELT.PRIM.78.5. Price: Call Us |
| 42 |
19171616 |
WASHER Price: Call Us |
| 43 |
163552 |
RETAINER SPRING Price: Call Us |
| 44 |
140608 |
KEEPER BELT LH Price: Call Us |
| 45 |
110485X |
BEARING Price: Call Us |
| 46 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 47 |
129895 |
BEARING.BALL Price: Call Us |
| 48 |
137645 |
SUB= 137646 Price: Call Us |
| 49 |
133943 |
HARDENED WASHER Price: Call Us |
| 62 |
153390 |
WASHER.FELT. Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
