| Ref | Part Number | Description |
|---|
| 1 |
76-1420 |
WHEEL-STEERING Price: $202.69 |
| 2 |
32121-111 |
PIN-ROLL Price: $2.39 |
| 3 |
85-6610 |
SHAFT-STEERING Price: $54.65 |
| 4 |
256-185 |
BUSHING Price: $19.18 |
| 5 |
92-5035 |
STEERING POST ASM Price: $105.83 |
| 6 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 7 |
65-8770 |
BUSHING-BELLCRANK Price: $5.35 |
| 8 |
32121-112 |
SPIROL PIN 1/4" X 1.25" Price: $1.36 |
| 9 |
85-9180 |
SPROCKET-STEERING Price: $56.99 |
| 10 |
95-0571 |
DISCONTINUED Price: Call Us |
| 11 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 12 |
3217-7 |
NUT-HEX Price: $0.28 |
| 13 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 14 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 15 |
251-166 |
BEARING-FLANGE Price: $14.74 |
| 16 |
251-165 |
BEARING-BALL Price: $104.65 |
| 17 |
84-7940 |
SHAFT-AXLE Price: $248.60 |
| 18 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 19 |
85-8290 |
TIRE-2PLY, KNOBBY Price: $120.96 |
| 20 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 21 |
18-6380 |
PIN-ADJUSTMENT, STEERING Price: $12.89 |
| 22 |
2710-11 |
LINK-CHAIN Price: $5.68 |
| 23 |
92-5039 |
CHAIN-STEERING Price: $36.82 |
| 24 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 25 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 26 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 27 |
95-0604 |
TUBE - EXTENSION Price: $51.61 |
| 28 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 29 |
95-0600-01 |
FRAME ASM This part replaces 95-0600. Price: $2,207.18 |
| 30 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 31 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 32 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 33 |
85-9200 |
KNUCKLE-STEERING Price: $100.34 |
| 34 |
98-0996 |
STEERING SHFT KIT-SANDPRO This part replaces 85-9210. Price: $35.09 |
| 35 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 38 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 39 |
114-4643 |
WHEEL This part replaces 94-6116. Price: $149.61 |
| 530035031 |
505520127 |
LEVER This part replaces 530035031. Price: $4.99 |
| 530035139 |
530035188 |
SPRING-METERING LEVER This part replaces 530035139. Price: $3.99 |
| 530035164 |
504130906 |
GASKET This part replaces 530035164. Price: $9.99 |
| 530035166 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $27.99 |
| 530035223 |
503563401 |
INLET NEEDLE This part replaces 530035223. Price: $14.99 |
| 530035236 |
505316717 |
SCREW This part replaces 530035236. Price: $6.99 |
| 530035250 |
505520125 |
FULCRUM PIN This part replaces 530035250. Price: $6.99 |
| 530035306 |
530035306 |
CARBURETOR Price: $49.23 |
| 530035331 |
530035178 |
SCREEN-DUTCH TWILL INLE This part replaces 530035331. Price: $2.99 |
| 530035332 |
530035320 |
GASKET This part replaces 530035332. Price: $4.99 |
