| Ref | Part Number | Description |
|---|
| 1 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 1 |
532434487 |
DECK.SVC.WELDMNT.30"419272X418 This part replaces 532442048. Price: $219.99 |
| 2 |
46-3710 |
FITTING-HYD, 90 DEG Price: $27.95 |
| 2 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 3 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 4 |
532417645 |
BRACKET.CLUTCH.CABLE Price: $4.99 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 6 |
532418863 |
ARMS.SUSP.MOWER.REAR.SRD Price: $17.99 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 7 |
84-8060 |
DISCONTINUED Price: Call Us |
| 8 |
2210-118 |
GASKET W/ENGINE Price: $3.02 |
| 8 |
583379801 |
ARM.IDLER.30"SRD This part replaces 532420252. Price: $7.99 |
| 9 |
49-9550-01 |
DISCONTINUED This part replaces 49-9550. Price: Call Us |
| 9 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 10 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 11 |
3217-6 |
NUT-HEX Price: $1.19 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 12 |
110-5236 |
HUB-ENGINE This part replaces 27-1960. Price: $30.97 |
| 12 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $14.99 |
| 13 |
110-9695 |
HUB-PUMP This part replaces 49-9600. Price: $55.09 |
| 13 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 14 |
37-8030-03 |
PUMP MOUNT This part replaces 37-8030. Price: $372.16 |
| 14 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 15 |
3217-9 |
NUT-HH Price: $0.37 |
| 15 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 16 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
3217-16 |
NUT-HEX Price: $0.25 |
| 17 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 18 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 18 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 19 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 19 |
532110485 |
BEARING Price: $11.99 |
| 20 |
46-8810 |
STOP-SPRING, LEAF Price: $9.17 |
| 20 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 21 |
29-6120-03 |
PUMP PLATE ASM This part replaces 29-6120. Price: $93.02 |
| 21 |
532416910 |
KEEPER.BELT.MANDREL.30" Price: $12.99 |
| 22 |
3219-2 |
NUT-HEX Price: $0.37 |
| 22 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 23 |
26-2950 |
WIRE-STANDOFF Price: $10.28 |
| 23 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 24 |
51-3150 |
SHIM-ARM, SPRING Price: $5.24 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 25 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 25 |
529311701 |
KEEPER, BELT, BLACK This part replaces 532420253. Price: $4.99 |
| 26 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 26 |
532430313 |
Price: Call Us |
| 27 |
32121-24 |
PIN-SPRING Price: $0.95 |
| 27 |
532419271 |
V-BELT.DRIVE.MOWER.30" Price: $49.99 |
| 28 |
532417344 |
SHIELD.DEFLECT.MWR.30S.BLACK Price: $37.99 |
| 28 |
86-5000 |
DISCONTINUED Price: Call Us |
| 29 |
49-2040 |
SCREW-HWHTF This part replaces 11-9760. Price: $1.99 |
| 29 |
593885101 |
Rods This part replaces 532420895. Price: $5.99 |
| 30 |
29-6170 |
EXTENDED LEAF SPRING ASM Price: $45.56 |
| 30 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 31 |
110-9650 |
LEAF SPRING ASM This part replaces 29-6150. Price: $33.06 |
| 31 |
532110452 |
NUT PUSH M Price: $2.99 |
| 32 |
321-6 |
SCREW-HH Price: $0.25 |
| 32 |
532401872 |
SPRING RETURN Price: $4.99 |
| 33 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 33 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 34 |
3210-7 |
SCREW-HH Price: $0.61 |
| 34 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 35 |
251-259 |
BEARING-BALL Price: $13.67 |
| 35 |
532419273 |
BLADE, MULCH.LRV30 Price: $29.99 |
| 36 |
322-17 |
SCREW-HH Price: $2.62 |
| 36 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 37 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 38 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 39 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 39 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 40 |
237-79 |
O-RING Price: $5.46 |
| 40 |
532419270 |
KEEPER.BELT.ENGINE.LH.LT.SRD Price: $14.99 |
| 41 |
325-8 |
SCREW-HH Price: $3.52 |
| 41 |
532419265 |
KEEPER.BELT.ENGINE.RH.LT.SRD Price: $11.99 |
| 42 |
353-370 |
FITTING-ELBOW, 90 DEG Price: $74.99 |
| 42 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 43 |
525568002 |
PULLEY.MANDREL 6.5" PULLEY This part replaces 532416877. Price: $24.99 |
| 43 |
92-8790 |
DISCONTINUED This part replaces 53-9360. Price: Call Us |
| 44 |
237-42 |
O-RING Price: $2.78 |
| 45 |
103-1802 |
FITTING-ELBOW, 90 DEG This part replaces 353-374. Price: $22.99 |
| 46 |
353-511 |
FITTING-HYD, 90 DEG Price: $31.93 |
| 47 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 48 |
323-6 |
SCREW-HH Price: $0.66 |
| 49 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 50 |
322-16 |
SCREW-HH Price: $3.39 |
| 51 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 52 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 53 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 54 |
3241-5 |
SCREW-SET Price: $0.61 |
| 55 |
10-7070 |
KEY-SQUARE Price: $1.02 |
| 56 |
3217-7 |
NUT-HEX Price: $0.28 |
| 57 |
49-9500-03 |
ENGINE BASE This part replaces 49-9500. Price: $172.07 |
| 59 |
323-8 |
SCREW-HH Price: $1.20 |
| 60 |
108-3831 |
FILTER-FUEL This part replaces 18-1520. Price: $10.09 |
| 61 |
110-9662 |
HOSE-FUEL This part replaces 51-0670. Price: $31.52 |
| 62 |
323-7 |
SCREW-HH Price: $0.65 |
| 63 |
86-4920 |
BRKT - DAMPNER *B Price: $76.87 |
| 64 |
86-4980 |
JAM NUT Price: $10.60 |
| 65 |
86-4970 |
DISCONTINUED Price: Call Us |
| 66 |
325-7 |
SCREW-HH Price: $1.53 |
| 67 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
61-3230 |
SPACER Price: $18.93 |
| 69 |
86-5070 |
DISCONTINUED Price: Call Us |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. Price: $29.99 |
