| Ref | Part Number | Description |
|---|
| 1 |
132-6161 |
RADIATOR/OIL COOLER Price: $2,023.65 |
| 1 |
547664401 |
KIT.SVC.DECK.WLD.97.TEX.428 This part replaces 532440971. Price: $449.99 |
| 2 |
340-129 |
FITTING-ELBOW, 90 DEG Price: $99.81 |
| 3 |
121-3084-03 |
MOUNT-RADIATOR Price: $432.29 |
| 3 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 4 |
114-3828 |
SEAL-BULB Price: $12.61 |
| 5 |
115-4363 |
PLENUM ASM Price: $386.67 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 6 |
281-13 |
PLUG-PIPE Price: $2.86 |
| 7 |
105-3921 |
FITTING-PLUG Price: $28.11 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 8 |
121-3143 |
HOSE-AIR CLEANER, INLET Price: $54.41 |
| 9 |
110-3258 |
HOSE-FUEL Price: $23.35 |
| 10 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 10 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 11 |
125-4615 |
SHROUD-RADIATOR, UPPER Price: $156.01 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 12 |
121-3106 |
SHROUD-RADIATOR, LOWER Price: $137.66 |
| 13 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 13 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 14 |
121-1476 |
HOSE-RADIATOR, UPPER Price: $53.04 |
| 14 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 15 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 16 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 17 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 18 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 18 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 19 |
532110485 |
BEARING Price: $11.99 |
| 20 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 21 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 22 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 23 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 24 |
121-3087 |
SEAL-FOAM, HOOD Price: $25.52 |
| 25 |
121-3086-0P |
BRACKET-SEAL HOOD This part replaces 121-3086-03. Price: $10.31 |
| 26 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 27 |
3274-55 |
SCREW-HSBH Price: $3.19 |
| 27 |
583544901 |
RP BELT.DRIVE.MWR.MECHN.97CRD This part replaces 532439726. Price: $84.99 |
| 28 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 29 |
117-4766 |
DECAL-WARNING, FAN Price: $5.80 |
| 30 |
120-5571 |
COOLANT RESERVOIR ASM Price: $151.27 |
| 31 |
3234-30 |
SCREW-HHF Price: $0.41 |
| 32 |
1-603903 |
SPACER Price: $4.99 |
| 32 |
532401872 |
SPRING RETURN Price: $4.99 |
| 33 |
117-4782 |
SEAL-BULB Price: $26.02 |
| 33 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 34 |
105-9858 |
SEAL-BULB Price: $31.67 |
| 34 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 35 |
532427984 |
BLADE.3N1.LH.CRD.97 Price: $49.99 |
| 36 |
2412-81 |
CLAMP-R Price: $3.39 |
| 36 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 37 |
46-6560 |
BUSHING Price: $2.94 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 39 |
109-0282 |
HOSE-FUEL Price: $7.39 |
| 40 |
121-1477 |
HOSE-RADIATOR, LOWER Price: $53.29 |
| 40 |
531169501 |
SERVICE KIT BELT KEEPER This part replaces 532197258. Price: $4.99 |
| 41 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 42 |
136-3693-0P |
BRACKET-MOUNT, TANK This part replaces 125-4609-03. Price: $84.48 |
| 42 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 43 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 45 |
532137152 |
HOUSING.MANDREL.44/46" VENT Price: $34.99 |
| 46 |
121-3085 |
PLATE-CROSSOVER Price: Call Us |
| 47 |
304-46 |
DRAINCOCK Price: $7.55 |
| 48 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 49 |
327-4 |
SCREW-HH Price: $2.20 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 71 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 72 |
582035601 |
CHUTE.TEX.CRD.GEN I.97 UPPER This part replaces 532446810. Price: $69.99 |
| 75 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 84 |
589676103 |
KEEPER 42 MANDREL BELT FOR 6.2 This part replaces 532199189. Price: $6.99 |
| 85 |
532427985 |
BLADE.3N1.RH.CRD.97 Price: $49.99 |
| 86 |
583117001 |
BOLT.3/8-24X1.25GR8. LHTHRD This part replaces 532181713. Price: $3.99 |
| 87 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 88 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 89 |
529846801 |
SERVICE.KIT ARM.BRAKE.97.LH AR This part replaces 532438124. Price: $12.99 |
| 90 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 91 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 92 |
583514701 |
ROD.BRAKE.97.CRD This part replaces 532436993. Price: $8.99 |
| 93 |
583527101 |
ARM.BRAKE.97.RH This part replaces 532438125. Price: $14.99 |
| 94 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 95 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 96 |
583261101 |
SPACER.NORAM.CRD This part replaces 532400271. Price: $4.99 |
| 97 |
583119101 |
SHIELD.IDLER.MOWER.CRD. This part replaces 532182061. Price: $4.99 |
| 98 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 100 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 101 |
596040601 |
Hardware This part replaces 873680900. Price: $3.99 |
| 102 |
532402511 |
SPACER BEARING Price: $3.99 |
| 103 |
583514601 |
GUARD.FRONT.VENT.97.CRD This part replaces 532436992. Price: $6.99 |
| 104 |
532441479 |
Price: Call Us |
| 105 |
532441478 |
Price: Call Us |
| 106 |
532193216 |
SPRING.BRAKE.RETURN.38" Price: $4.99 |
| 110 |
587934801 |
CRD.SPUR.GEAR This part replaces 532415356. Price: $11.99 |
| 111 |
583514001 |
GASKET.GEARCASE.97.CRD (2 2) This part replaces 532436979. Price: $4.99 |
| 112 |
583571601 |
SHAFT.CRD.GEARCASE.ADAPTER This part replaces 532443852. Price: $14.99 |
| 114 |
588170501 |
VENT.BREATHER.1/8 NPT This part replaces 532438534. Price: $8.99 |
| 115 |
583608901 |
SCREW.TORX#10-24X1 This part replaces 818031016. Price: $2.99 |
| 116 |
594976601 |
Bolts This part replaces 872110414. Price: $1.99 |
| 117 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 118 |
583514401 |
ARM.CLUTCHING.97.TEX This part replaces 532436989. Price: $17.99 |
| 119 |
583527601 |
GEAR.CASE.SUBASM. This part replaces 532438166. Price: $59.99 |
| 120 |
583514501 |
KEEPER.BELT.RH.MANDREL.97.CRD This part replaces 532436991. Price: $6.99 |
| 121 |
583514101 |
WASHER.687.I.D.X.1 OD.X.062THK This part replaces 532436985. Price: $2.99 |
| 124 |
583514201 |
MANDREL SHAFT NON/GREASEABLE This part replaces 532436986. Price: $37.99 |
| 125 |
583514801 |
BRACKET.IDLER.CHASSIS.97.CRD This part replaces 532436994. Price: $8.99 |
| 127 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 128 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 129 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $22.99 |
| 130 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 131 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 132 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 152 |
583548401 |
CBLE.CLTCH.MANUAL.W/SPR.LT.CRD This part replaces 532440488. Price: $32.99 |
