| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 2 |
532142033 |
AXLE ASSY Price: $59.99 |
| 2 |
76-9790 |
FOAM-TANK, FUEL Price: $10.89 |
| 3 |
532135227 |
SPINDLE LH Price: $15.39 |
| 3 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 4 |
532135228 |
SPINDLE RH Price: $12.97 |
| 4 |
76-6600 |
PIPE-STAND Price: $70.58 |
| 5 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
108-3280 |
HOSE-FUEL This part replaces 63-7626. Price: $5.28 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
46-6560 |
BUSHING Price: $2.94 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
532130468 |
LINK.DRAG.SOL.BALL JT.20.064 Price: $64.99 |
| 10 |
68-6150 |
BREATHER Price: $27.22 |
| 11 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
76-8780 |
DECAL-CAUTION, FUEL Price: $7.93 |
| 12 |
873610600 |
NUT Price: $2.99 |
| 13 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 14 |
354-95 |
FITTING-STRAIGHT Price: $6.75 |
| 14 |
874011056 |
Bolt Hex 5/8-11 Unc X 3-1/2 Price: $4.99 |
| 15 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 16 |
354-94 |
FITTING-FEMALE, BARBED Price: $9.70 |
| 16 |
532132624 |
AXLE PIN Price: $2.42 |
| 17 |
532156544 |
STEERING SHAFT This part replaces 532128762. Price: $64.99 |
| 17 |
74-9122 |
HOSE-OVERFLOW, RADIATOR Price: $20.47 |
| 18 |
240-6 |
GROMMET-RUBBER Price: $15.80 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 20 |
323-7 |
SCREW-HH Price: $0.65 |
| 20 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 21 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 21 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 22 |
110-4107 |
HOSE-FUEL This part replaces 63-7622. Price: $7.77 |
| 22 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $3.99 |
| 23 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 23 |
76-5300 |
DISCONTINUED Price: Call Us |
| 24 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 24 |
532109816 |
NYLINER T (7283A) Price: $4.99 |
| 25 |
14-0859 |
FUEL TANK PLATE Price: $72.11 |
| 25 |
531152201 |
SERVICE KIT BRACKET BRKT This part replaces 532124036. Price: $12.99 |
| 26 |
2812-1 |
BUSHING-PIPE Price: $4.28 |
| 27 |
285-22 |
PLUG-PIPE Price: $0.87 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 28 |
62-7650 |
GASKET Price: $4.28 |
| 29 |
106-1014 |
SENDER-FUEL This part replaces 74-5860. Price: $246.39 |
| 29 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 30 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 31 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $79.99 |
| 32 |
74-5580 |
DISCONTINUED Price: Call Us |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
321-3 |
SCREW-HH Price: $0.28 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
70-1480 |
RELAY Price: $105.19 |
| 35 |
873610500 |
This part replaces 873810500. Price: $2.15 |
| 36 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 36 |
532145207 |
BUSHING STRG 3/4 Price: $4.99 |
| 37 |
817211008 |
Screw Slftp #10-16 x 1/2 Ty-Ab This part replaces 817431008. Price: $3.99 |
| 37 |
94-5623 |
MAIN HARNESS Price: $1,410.45 |
| 38 |
32148-10 |
NUT-CLINCH Price: $1.29 |
| 38 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 39 |
106-1018 |
BRACKET-COVER This part replaces 82-3660. Price: $12.55 |
| 39 |
532100712 |
WASHER Price: $2.42 |
| 40 |
323-4 |
SCREW-HH Price: $1.02 |
| 40 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 41 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 42 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
