| Ref | Part Number | Description |
|---|
| 1 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 1 |
703-0178 |
PLATE ASSEMBLY-ENG MTG Not Available Price: |
| 1 |
82-5780 |
CAP-THREAD Price: $94.64 |
| 2 |
82-5770 |
ROD Price: $244.95 |
| 2 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 2 |
950-3009 |
SPACER This part replaces 750-3009. Price: $10.74 |
| 3 |
539104427 |
SPACER .70" Price: $7.65 |
| 3 |
703-1865A |
TWIN BOTTOM DUCT Not Available This part replaces 703-1865. Price: |
| 4 |
539105308 |
KEY 1/4 SQ X 1.0 Price: $3.99 |
| 4 |
751-3083 |
MUFFLER Not Available Price: |
| 5 |
539104429 |
PULLEY Price: $45.99 |
| 5 |
726-3016 |
MUFFLER CLAMP ASSEMBLY Not Available Price: |
| 5 |
82-5790 |
HEAD-CAP, THREAD Price: $279.42 |
| 6 |
539104428 |
SPACER .508" Price: $7.11 |
| 6 |
703-1839 |
DUCT-TOP AIR Not Available Price: |
| 7 |
539104515 |
CLUTCH Price: $279.99 |
| 7 |
750-0470 |
Spacer, .326 X .47 X .96 Lg Price: $5.99 |
| 8 |
596238901 |
Washers This part replaces 539990427. Price: $2.99 |
| 8 |
712-3004 |
Nut, Hex Flange Lock, 5/16-18 Price: $3.49 |
| 9 |
539991120 |
BOLT 7/16F X 2 1/2 Price: $5.99 |
| 9 |
710-0599 |
Screw, Hex Wash Hd Tapp, 1/4-20 X .50 Lg Price: $3.86 |
| 10 |
539103251 |
CLUTCH TIE DOWN Price: $34.99 |
| 11 |
539105047 |
MUFFLER GUARD, PAINT Price: $22.44 |
| 11 |
82-5760 |
PISTON Price: $211.58 |
| 12 |
539104415 |
KAW PIGTAIL Price: $27.99 |
| 12 |
539104416 |
KOH PIGTAIL Price: $34.99 |
| 12 |
82-5750 |
NUT-LOCK, ELASTIC Price: $9.02 |
| 13 |
539104956 |
MUFFLER KOH Price: $271.99 |
| 13 |
539104957 |
MUFFLER KAW. Price: $242.60 |
| 14 |
539105048 |
MUFFLER MT, PAINT Price: $25.06 |
| 14 |
82-5740 |
NUT-JAM Price: $29.95 |
| 15 |
539105025 |
ENGINE MOUNT Price: $19.99 |
| 15 |
82-5730-01 |
END-ROD, TIE This part replaces 82-5730. Price: $310.82 |
| 16 |
32121-44 |
PIN-ROLL Price: $0.47 |
| 16 |
539105031 |
ENGINE MOUNT Price: $29.99 |
| 17 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 18 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 19 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 20 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 21 |
539104959 |
ISOLATOR WASHER Price: $12.99 |
| 22 |
539104958 |
ISOLATORS Price: $32.99 |
| 23 |
539102757 |
CABLE POSITIVE Price: $7.99 |
| 24 |
539101714 |
SOLENOID Price: $22.99 |
| 25 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 26 |
539990761 |
NUT 1/4C CENTER LOCK Price: $2.99 |
| 27 |
539105034 |
ISOLATOR SPACER Price: $11.99 |
| 29 |
539105073 |
PIPE 3/8 NPT 1-1/2 Price: $4.99 |
