| Ref | Part Number | Description |
|---|
| 0 |
632205C |
CARBURETOR This part replaces 632156A. Price: Call Us |
| 1 |
532175904 |
WHEEL.STEERING.AYP.P/L.BLACK Price: $24.99 |
| 1 |
632160 |
SHAFT & LEV Price: $13.61 |
| 2 |
100-8397 |
COVER-TANK Price: $147.37 |
| 2 |
32096 |
RET SPRING Price: $2.62 |
| 2 |
532175131 |
AXLE ASM. Price: $39.99 |
| 3 |
100-7011 |
SPIGOT-90 DEG Price: $17.78 |
| 3 |
532169840 |
SPINDLE.ASM.LH.15"TIRES Price: $17.99 |
| 4 |
100-7009 |
LATCH-DRAW Price: $11.03 |
| 4 |
532169839 |
SPINDLE.ASM.RH.15"TIRES Price: $17.99 |
| 5 |
100-7010 |
HINGE Price: $23.12 |
| 5 |
532006266 |
WASHER THRUST Price: $5.99 |
| 5 |
632039 |
WASHER Price: $3.86 |
| 6 |
100-7062 |
RIVET Price: $6.79 |
| 6 |
532121748 |
WASHER Price: $1.99 |
| 6 |
631682 |
SHUTTER Price: $10.04 |
| 7 |
100-7063 |
RIVET Price: $0.27 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 7 |
819272016 |
WASHER Price: $2.99 |
| 8 |
100-7064 |
SCREW Price: $4.27 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 9 |
100-7065 |
WASHER Price: $0.20 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN Price: $1.99 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $44.99 |
| 10 |
631683 |
SHAFT & LEV Price: $12.88 |
| 11 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
532005298 |
TUBE-PIVOT AXLE T Price: $5.99 |
| 13 |
632040 |
WASHER Price: $3.86 |
| 14 |
631684 |
SHUTTER Price: $3.86 |
| 15 |
27113 |
SPRING Price: $2.62 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $2.99 |
| 17 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180641. Price: $54.99 |
| 17 |
650399 |
SCREW Price: $1.20 |
| 18 |
27114 |
SPRING Price: $2.62 |
| 20 |
27112 |
IDLE SCREW Price: $1.26 |
| 21 |
27114 |
SPRING Price: $2.62 |
| 25 |
29170 |
FLOAT BOWL Price: Call Us |
| 26 |
31503 |
SPRING Price: $1.23 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) This part replaces 532120754. Price: $2.99 |
| 27 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 28 |
27105 |
FLOAT Price: $20.00 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
27109 |
GASKET Price: $1.18 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $2.99 |
| 30 |
631687 |
INLET NEEDLE Price: $17.46 |
| 30 |
876020412 |
COTTER PIN Price: $3.99 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM This part replaces 532130465. Price: $12.99 |
| 36 |
532155106 |
KIT.BUSHING This part replaces 532155099. Price: $5.99 |
| 36 |
632330 |
NOZZLE Price: Call Us |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532175905 |
CAP.WHEEL.STEERING.BLACK This part replaces 532140045. Price: $6.99 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8""OD Price: $3.99 |
| 40 |
631764 |
POWER SCREW Price: $22.59 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 41 |
27544 |
O RING Price: $1.26 |
| 41 |
532437747 |
STEERING.WHEEL.ADAPTER This part replaces 532186737. Price: $19.99 |
| 43 |
532121749 |
WASHER Price: $1.99 |
| 43 |
630786 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 44 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180640. Price: $54.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED Price: $3.99 |
| 51 |
873540400 |
NUT.CROWNLOCK.1/4-28 Price: $3.99 |
| 54 |
871130420 |
HEX BOLT Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $2.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $2.99 |
| 68 |
532169827 |
BRACE.AXLE.15"TIRES Price: $14.99 |
| 71 |
532175146 |
STEERING ASM Price: $64.99 |
| 82 |
532199978 |
BRACKET.SUSP.CHASSIS.FRONT.15 This part replaces 532169835. Price: $11.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $3.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $8.99 |
