| Ref | Part Number | Description |
|---|
| 1 |
05896A |
BRACKET-IDLR- Not Available Price: |
| 3 |
710-0888 |
Hex Bolt 5/16-24 x 1" Lg. This part replaces 710-0117. Price: $3.86 |
| 4 |
710-0157 |
Screw Price: $3.90 |
| 5 |
710-0230 |
HEX SCREW 1/4-28 x .50 GR5 Not Available Price: |
| 6 |
710-3005 |
Hex Bolt 3/8-16 x 1.25" Lg. This part replaces 710-0342. Price: $3.61 |
| 7 |
710-0696 |
Screw Price: $5.94 |
| 8 |
710-0888 |
Screw Price: $3.86 |
| 9 |
710-0896 |
Screw Price: $3.86 |
| 10 |
712-0181 |
Nut, Hex Price: $3.90 |
| 11 |
731-1324 |
Belt Cover Price: $19.12 |
| 12 |
932-0710 |
Extension Spring This part replaces 732-0710. Price: $6.92 |
| 13 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 14 |
736-0242 |
Washer-Bell Price: $3.75 |
| 15 |
736-0247 |
Washer-Flat Price: $8.82 |
| 16 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 17 |
736-0331 |
Washer-Bell Price: $3.50 |
| 18 |
736-0505 |
Washer-Flat Price: $5.65 |
| 19 |
748-0234 |
Shoulder Spacer Price: $3.86 |
| 20 |
948-0360 |
Adapter Pulley This part replaces 748-0360. Price: $19.88 |
| 21 |
954-0346 |
V - Belt This part replaces 754-0346. Price: $26.67 |
| 22 |
954-0430C |
BELT: 3V X 35.00 LG This part replaces 754-0430. Price: $26.49 |
| 23 |
756-0313 |
Idler, Flat Price: $24.48 |
| 24 |
756-0569 |
Pulley, Half Not Available Price: |
| 25 |
756-0967 |
Pulley-Auger Price: $52.75 |
| 26 |
756-0986 |
HALF PULLEY Not Available Price: |
| 27 |
956-0987 |
HALF PULLEY Not Available This part replaces 756-0987. Price: |
| 29 |
N/A |
Engine |
