| Ref | Part Number | Description |
|---|
| 1 |
93-7974-03 |
PLATE-BOX, BATTERY This part replaces 93-7974. Price: $87.76 |
| 2 |
33105-030 |
SCREW-HHF Price: $1.56 |
| 2 |
BS-797673 |
Kit-Bushing/Seal (Magneto Side) This part replaces BS-261623. Price: $19.95 |
| 3 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 3 |
BS-391086S |
Seal-Oil (Magneto Side) This part replaces BS-391086. Price: $7.18 |
| 4 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 4 |
BS-213181 |
CYLINDER HEAD Not Available Price: |
| 5 |
33005-00 |
NUT-HF Price: $0.68 |
| 5 |
BS-271866S |
CYLINDER HEAD GASKET Not Available This part replaces BS-271866. Price: |
| 6 |
108-3282 |
HOSE-FUEL This part replaces 92-7522. Price: $36.93 |
| 6 |
BS-495734 |
BREATHER ASSEMBLY Not Available This part replaces BS-394217. Price: |
| 7 |
66-8121 |
STANDPIPE Price: $23.18 |
| 7 |
BS-27803S |
BREATHER GASKET Not Available This part replaces BS-27803. Price: |
| 8 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 8 |
BS-691666 |
BREATHER ASSEMBLY SCREW Not Available This part replaces BS-93394. Price: |
| 9 |
46-6560 |
BUSHING Price: $2.94 |
| 9 |
BS-692253 |
BREATHER TUBE Not Available This part replaces BS-280100. Price: |
| 10 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 10 |
BS-692226 |
CRANKCASE GASKET Not Available This part replaces BS-271916. Price: |
| 11 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 11 |
BS-93723 |
SCREW Not Available Price: |
| 12 |
304-46 |
DRAINCOCK Price: $7.55 |
| 12 |
BS-490466 |
CRANKSHAFT Not Available Price: |
| 13 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 14 |
63-8410 |
WASHER Price: $1.76 |
| 14 |
BS-291675S |
OIL SEAL Not Available This part replaces BS-291675. Price: |
| 15 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 15 |
BS-93405 |
Screw, Base Mounting Sem Price: Call Us |
| 16 |
105-7949 |
TANK-FUEL This part replaces 92-7422. Price: $768.96 |
| 16 |
BS-222698S |
Key-Flywheel (Aluminum) This part replaces BS-222698. Price: $3.71 |
| 17 |
62-7650 |
GASKET Price: $4.28 |
| 18 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 18 |
BS-499996 |
PISTON RING SET STD Not Available This part replaces BS-394665. Price: |
| 19 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 19 |
BS-260924 |
LOCK PISTON PIN Not Available Price: |
| 20 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 21 |
110-6184 |
HOSE-FUEL This part replaces 92-7521. Price: $49.59 |
| 22 |
BS-222299 |
LOCK Not Available Price: |
| 23 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 23 |
BS-92909 |
SCREW CONNECTING ROD Not Available Price: |
| 24 |
BS-262246 |
EXHAUST VALVE Not Available Price: |
| 25 |
BS-262247S |
INTAKE VALVE Not Available This part replaces BS-262247. Price: |
| 26 |
BS-65906 |
SPRING Not Available Price: |
| 27 |
BS-26828 |
SPRING Not Available Price: |
| 28 |
BS-690656 |
VALVE RETAINER Not Available This part replaces BS-221596. Price: |
| 29 |
BS-691939 |
VALVE RETAINER Not Available This part replaces BS-292260. Price: |
| 30 |
BS-494553 |
RETAINER-ROTO Not Available This part replaces BS-93630. Price: |
| 31 |
BS-262248 |
TAPPET, VALVE Not Available Price: |
| 32 |
BS-212897 |
CAMSHAFT & GEAR Not Available Price: |
| 33 |
BS-67218 |
ELBOW-FUEL LINE Not Available Price: |
| 34 |
BS-93535 |
SCREW-SEM Not Available Price: |
| 35 |
BS-261609 |
GOVERNOR LINK Not Available Price: |
| 36 |
BS-792813 |
Spring-Governor (Brown) This part replaces BS-261306. Price: $5.76 |
| 37 |
BS-691968 |
Governor/Oil Slinger This part replaces BS-391764. Price: $46.54 |
| 38 |
BS-390746 |
PLATE, GOVERNOR CONTROL Not Available Price: |
| 39 |
BS-692012 |
Governor Crank This part replaces BS-231058. Price: $47.28 |
| 41 |
BS-691691 |
Washer (Governor Crank) This part replaces BS-222450. Price: $10.24 |
| 42 |
BS-692207 |
LINK SPRING Not Available This part replaces BS-260584. Price: |
| 43 |
BS-691024 |
Clamp-Casing This part replaces BS-221535. Price: $6.90 |
| 44 |
710-0432 |
HEX SCREW #10-32 x .38 Not Available Price: |
| 45 |
BS-223715 |
SHIELD, CYLINDER Not Available Price: |
| 46 |
BS-93163 |
Screw, Cylinder Shield Mtg Sem Price: Call Us |
| 47 |
BS-223718 |
CYLINDER COVER Not Available Price: |
| 48 |
BS-691077 |
Washer (Ground Terminal) This part replaces BS-92791. Price: $11.38 |
| 49 |
712-0142 |
Nut, Hex Price: $3.90 |
| 50 |
BS-93380 |
Screw Sem Price: Call Us |
| 51 |
BS-791885 |
FUEL PUMP KIT Not Available This part replaces BS-390818. Price: |
| 52 |
BS-691084 |
Terminal Ground This part replaces BS-93722. Price: $11.38 |
| 53 |
BS-692014 |
DIPSTICK Not Available This part replaces BS-490327. Price: |
| 54 |
BS-281370S |
Seal-Dipstick Tube This part replaces BS-68838. Price: $6.73 |
| 55 |
BS-280741 |
BS-495768 Not Available Price: |
| 56 |
BS-223721 |
OIL FILL CLAMP Not Available Price: |
| 58 |
BS-491986 |
CRANK BUSHING Not Available This part replaces BS-231055. Price: |
| 59 |
BS-92613 |
BOLT Not Available Price: |
| 60 |
BS-231082 |
HEX NUT Not Available Price: |
| 61 |
BS-791850 |
Clamp-Hose (Green) This part replaces BS-93053. Price: $3.78 |
| 62 |
BS-93306 |
COTTER PIN Not Available Price: |
| 63 |
BS-93307 |
RETAINER Not Available Price: |
| 64 |
BS-690804 |
SLOTTED HEX SCREW Not Available This part replaces BS-93496. Price: |
| 65 |
BS-691284 |
TIMING GEAR Not Available This part replaces BS-262135. Price: |
| 66 |
BS-212359 |
LINK COUNTERWEIGHT Not Available Price: |
| 68 |
BS-298909 |
Pin, Counterweight Price: $8.83 |
| 69 |
BS-93875 |
Screw, Counterweight Price: Call Us |
| 70 |
BS-691870 |
O-RING SEAL Not Available This part replaces BS-270920. Price: |
| 72 |
BS-691802 |
INTAKE VALVE SEAT Not Available This part replaces BS-261463. Price: |
| 73 |
BS-210940 |
EXHAUST VALVE SEAT Not Available Price: |
| 74 |
BS-261961 |
VALVE GUIDE Not Available Price: |
| 75 |
BS-691972 |
Insulator This part replaces BS-398525. Price: $9.75 |
| 76 |
BS-280687 |
FLYWHEEL FAN Not Available Price: |
| 77 |
BS-223726 |
Retainer, Fan Price: Call Us |
| 78 |
751-3058 |
TUBE-OIL DRAIN Not Available Price: |
| 79 |
751-3001 |
PLUG-HEX HEAD 1/4" Not Available Price: |
| 80 |
710-0432 |
HEX SCREW #10-32 x .38 Not Available This part replaces BS-93572. Price: |
| 539102563 |
539102563 |
LANYARD Price: $7.99 |
| 539105743 |
581724301 |
DECAL.DECK.6MIL.EURO.NOSTEP This part replaces 539105743. Price: $3.99 |
| 539105744 |
539105744 |
DECAL, BELT DRIVE Price: $5.99 |
| 539108120 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 539108951 |
539112138 |
HCS, 7/16-20 X 2 1/2, GR8 This part replaces 539108951. Price: $32.99 |
| 539109660 |
539109660 |
DRAW LATCH Price: $13.99 |
| 539110740 |
539110740 |
RIVET, BLIND, 5/32 DIA Price: $2.99 |
| 539111236 |
539111236 |
BLOWER DECK PLATE Price: $279.99 |
| 539111240 |
539111240 |
BLOWER DECK PLATE WLDMNT, 61" Price: $399.99 |
| 539111264 |
539111264 |
BLOWER DECK PLATE WLDMT, 52 Price: $219.99 |
| 539111270 |
539111270 |
PIN Price: $7.99 |
| 539111272 |
539111272 |
BELT SHIELD ASSY 48" Price: $179.99 |
| 539111273 |
539111273 |
BELT SHIELD ASSY 52" Price: $179.99 |
| 539111274 |
539111274 |
BELT SHIELD ASSY 61" Price: $179.99 |
| 539111277 |
539111277 |
DRIVE KIT 52" DECK Price: $239.95 |
| 539111278 |
539111278 |
DRIVE KIT 61" DECK Price: $259.95 |
| 539111280 |
539111280 |
Hood Assembly Collection System (HSC9) Price: $1,899.95 |
| 539111305 |
539111305 |
BELT Price: $19.99 |
| 539111306 |
539111306 |
BELT Price: $19.99 |
| 539111307 |
539111307 |
BELT Price: $22.99 |
| 539976998 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 539990074 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
