| Ref | Part Number | Description |
|---|
| 1 |
4-7459 |
REAR BSKT & HNDL ASM Price: $573.68 |
| 2 |
3290-148 |
NUT-HF Price: $0.25 |
| 3 |
5-5690 |
DISCONTINUED Price: Call Us |
| 3 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 4 |
32122-32 |
SCREW Price: $1.79 |
| 4 |
532432420 |
SHIELD.INNER.BELT.GUARD.RT Price: $29.99 |
| 5 |
5-5600 |
DISCONTINUED Price: Call Us |
| 5 |
532164329 |
PIN.SPIROL.FLARED Price: $3.99 |
| 6 |
4-7449 |
DISCONTINUED Price: Call Us |
| 6 |
532162756 |
LEVER.ASM.SHIFT.RED Price: $9.99 |
| 7 |
5-5620 |
BASKET HANGER WA *B Price: $82.67 |
| 7 |
872110404 |
BOLT Price: $3.99 |
| 8 |
321-8 |
SCREW-HH Price: $0.34 |
| 8 |
583879201 |
PANEL.INDICATOR.SHIFT.BLACK. This part replaces 532161530. Price: $2.99 |
| 9 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 9 |
532086777 |
Screw, Hex, Washer Hd., Slotted, Thd. Cutting #10-24 x 1/2 Type D (AYP part number) Price: $1.99 |
| 10 |
32120-64 |
RING-SNAP, EXTERNAL Price: $0.25 |
| 10 |
532009484 |
CONDUIT CLIP T Price: $3.99 |
| 11 |
3-9274 |
SPACER Price: $6.33 |
| 12 |
256-90 |
BUSHING-FLANGE Price: $2.92 |
| 12 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 13 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 13 |
823230506 |
SET SCREW Price: $2.99 |
| 14 |
4-7439 |
DISCONTINUED Price: Call Us |
| 14 |
532156117 |
SPACER-SPLIT.327 X .42 Price: $3.99 |
| 15 |
5-2891 |
DISCONTINUED Price: Call Us |
| 15 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 16 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 16 |
532145102 |
SHEAVE, TRANSMISSION Price: $37.99 |
| 17 |
3290-133 |
SCREW Price: $1.19 |
| 18 |
3-3468-03 |
BASKET HANDLE This part replaces 3-3468. Price: $186.16 |
| 19 |
812000028 |
RETAINING RING LT Price: $4.99 |
| 21 |
532110652 |
SPACER CRT Price: $3.99 |
| 22 |
874770508 |
BOLT Price: $2.99 |
| 23 |
532102190 |
TIRE.CHV.13X5-6 Price: $59.99 |
| 24 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 25 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 26 |
532167778 |
GUARD.BELT.TILLER.YELLOW Price: $24.99 |
| 27 |
532132801 |
V-BELT Price: $19.99 |
| 28 |
532104679 |
PULLEY-IDLER TI Price: $11.99 |
| 29 |
812000032 |
KLIP RING Price: $3.99 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532159229. Price: $11.99 |
| 31 |
532102384 |
BOLT.FIN.HEX.3/8-16UNC Price: $3.99 |
| 32 |
532102141 |
SHIFT ARM CRT Price: $3.99 |
| 33 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
| 34 |
532102383 |
COUNTERWEIGHT.LH.CRT Price: $89.99 |
| 35 |
874760528 |
BOLT, HEX 5/16-18X1-3/4 Price: $2.99 |
| 36 |
584366901 |
BRACKET.REINFORCEMENT.LH.PNT This part replaces 532102331. Price: $5.99 |
| 37 |
532130812 |
ENGINE PULLEY Price: $17.99 |
| 38 |
874780544 |
BOLT HEX This part replaces 874760544. Price: $3.99 |
| 39 |
532140062 |
CAP.PLUNGER.BLACK Price: $3.99 |
| 40 |
532170488 |
SCREW.HEX.WSH.SLT.#10-24X.50 Price: $2.99 |
| 44 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 65 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873970500. Price: $2.99 |
| 66 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 68 |
873510600 |
NUT ** Price: $3.99 |
