| Ref | Part Number | Description |
|---|
| 1 |
125-7003 |
STARTER Price: $761.46 |
| 2 |
125-7004 |
SWITCH ASM Price: $310.64 |
| 2 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 3 |
125-7112 |
ARMATURE ASM Price: $1,004.37 |
| 4 |
125-7252 |
BEARING-BALL Price: $30.58 |
| 5 |
125-7249 |
BEARING, BALL Price: $74.15 |
| 5 |
532138457 |
BRACKET SWAY BAR Price: $9.99 |
| 6 |
125-7113 |
FIELD COIL ASM Price: $188.98 |
| 6 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 7 |
125-7114 |
BRUSH Price: $7.85 |
| 7 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532130832. Price: $9.99 |
| 8 |
125-7163 |
SCREW Price: $4.64 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 9 |
125-7115 |
COVER Price: $48.60 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
125-7116 |
BRUSH HOLDER ASM Price: $59.41 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
125-7114 |
BRUSH Price: $7.85 |
| 11 |
532137380 |
BLADE.50".HI-LIFT Price: $19.99 |
| 12 |
125-7036 |
SPRING Price: $8.92 |
| 13 |
125-7164 |
CASE-GEAR Price: $148.50 |
| 13 |
532137553 |
SHAFT.ASM.W/BEARING Price: $32.99 |
| 14 |
125-7005 |
HOUSING Price: Call Us |
| 14 |
532137152 |
HOUSING.MANDREL.44/46" VENT Price: $34.99 |
| 15 |
125-7165 |
LEVER SET Price: $12.41 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 18 |
125-7037 |
DUST COVER ASM Price: $32.44 |
| 18 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 19 |
125-7117 |
BOLT-THROUGH Price: $18.16 |
| 19 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 20 |
125-7166 |
PINION ASM Price: $520.47 |
| 20 |
532123713 |
SPRING TORSION Price: $6.99 |
| 21 |
125-7250 |
CLUTCH ASM Price: $223.38 |
| 21 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532137607. Price: $2.99 |
| 22 |
125-7251 |
BEARING-BALL Price: $113.29 |
| 22 |
532110452 |
NUT PUSH M Price: $2.99 |
| 23 |
125-7253 |
BEARING-BALL Price: $30.58 |
| 24 |
125-7167 |
SHAFT Price: $105.30 |
| 25 |
125-7168 |
STOPPER SET Price: $14.88 |
| 26 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 27 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 28 |
532132823 |
IDLER SPRING SPACER Price: $5.99 |
| 29 |
125-7210 |
BOLT Price: $2.32 |
| 29 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 30 |
125-7211 |
BOLT Price: $3.48 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532157722. Price: $3.99 |
| 31 |
125-7169 |
COVER Price: $7.32 |
| 31 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 33 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 34 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 36 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 37 |
532137166 |
STIFFENER ARM Price: $4.99 |
| 38 |
597024901 |
Keepers This part replaces 532173968. Price: $3.99 |
| 39 |
597025001 |
CLG This part replaces 532173438. Price: $22.99 |
| 42 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 43 |
532136460 |
ARM.IDLER.SEC.44" Price: $5.99 |
| 44 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 45 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 46 |
582740701 |
BOLT This part replaces 874760628. Price: $4.99 |
| 47 |
532137200 |
COVER MANDRELL Price: $21.99 |
| 48 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 49 |
532136574 |
COVER.MANDREL.LH.44" Price: $19.99 |
| 50 |
532137272 |
ARM.IDLER.PRIMARY Price: $4.99 |
| 51 |
532137273 |
SPRING.SEC.44"VEN Price: $6.99 |
| 52 |
532139245 |
PULLEY IDLER Price: $32.99 |
| 53 |
532137789 |
SHIELD IDLER Price: $4.99 |
| 54 |
532139573 |
V-BELT.PRMRY 46/50 VENT.BLK BK Price: $44.99 |
| 55 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 56 |
532138687 |
SPRING Price: $3.99 |
| 58 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 59 |
596434404 |
Bolts This part replaces 532137644. Price: $4.99 |
| 62 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 63 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 64 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 66 |
532173979 |
KEEPER BELT IDLER PLATED Price: $4.99 |
| 67 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 94 |
596580801 |
Bolts This part replaces 874780516. Price: $2.99 |
| 95 |
532175746 |
BRACKET ASM, ROLLER (L) Price: $7.99 |
| 96 |
531154101 |
SERVICE KIT BRACKET BRACKET AS This part replaces 532175747. Price: $12.99 |
| 97 |
819171416 |
Washer 1 17/32 X 7/8 X 16 Ga Price: $3.99 |
| 98 |
532132264 |
NOSE ROLLER Price: $29.99 |
| 99 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 103 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 104 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 112 |
734117771 |
BUSHING This part replaces 819171216. Price: $3.99 |
| 113 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110504. Price: $2.99 |
