| Ref | Part Number | Description |
|---|
| 1 |
38-0840 |
SEAT This part replaces 47-2350. Price: $377.48 |
| 1 |
TBD |
Price: Call Us |
| 2 |
3-9337 |
DISCONTINUED Price: Call Us |
| 2 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $4.99 |
| 3 |
532121327 |
Transaxle (Driven) Pulley (AYP part number) Price: $22.03 |
| 4 |
32122-20 |
DISCONTINUED Price: Call Us |
| 4 |
812000004 |
RING Price: $3.99 |
| 5 |
3217-5 |
NUT-HEX Price: $0.25 |
| 5 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 6 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 6 |
TBD |
Price: Call Us |
| 7 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 8 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 8 |
532141002 |
Rod Shift Fender YT (AYP part number) Price: $16.58 |
| 9 |
32122-30 |
SCREW-PTH Price: $0.28 |
| 9 |
532137140 |
Clutch, Electric (AYP part number) Price: $279.99 |
| 10 |
249-10 |
DISCONTINUED Price: Call Us |
| 10 |
876020416 |
PIN COTTER Price: $3.99 |
| 11 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 11 |
532105701 |
WASH-SHFT PLT LT Price: $3.99 |
| 12 |
3217-26 |
NUT-HEX Price: $0.25 |
| 13 |
8-0030 |
DISCONTINUED Price: Call Us |
| 13 |
871040412 |
BOLT LT Price: $3.99 |
| 14 |
5-3276 |
DISCONTINUED Price: Call Us |
| 15 |
40-7830 |
DISCONTINUED Price: Call Us |
| 15 |
874490544 |
BOLT HEX 5/16-18 GR 5 Price: $2.99 |
| 16 |
5-0946 |
KEY-SQUARE Price: $1.76 |
| 17 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
532126197 |
WASHER Price: $4.99 |
| 18 |
51-2710 |
DISCONTINUED This part replaces 5-1894. Price: Call Us |
| 19 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 19 |
873680600 |
LOCKNUT This part replaces 532062336. Price: $1.99 |
| 20 |
3-8516 |
DISCONTINUED Price: Call Us |
| 20 |
501606501 |
Speed Clip This part replaces 871170768. Price: $1.99 |
| 21 |
532106933 |
KNOB T (1/2-HOLE) Price: $3.99 |
| 21 |
6-9930 |
DISCONTINUED Price: Call Us |
| 22 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 22 |
532145340 |
ROD.ASM.BK.44.MWR (NLAD) Price: $8.99 |
| 23 |
3242-7 |
Setscrew Price: Call Us |
| 23 |
532137141 |
BRACKET ASM MTG Price: $3.99 |
| 24 |
3-9374 |
DISCONTINUED Price: Call Us |
| 24 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 25 |
218-219 |
DISCONTINUED Price: Call Us |
| 25 |
532126909 |
SPRING,ROD BRAKE Price: $2.99 |
| 26 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 26 |
819131316 |
WASHER Price: $2.99 |
| 27 |
3290-244 |
WASHER-LOCK Price: $0.85 |
| 27 |
876020412 |
COTTER PIN Price: $3.99 |
| 28 |
40-7480 |
DISCONTINUED Price: Call Us |
| 28 |
532145204 |
Rod Brake Parking LT/YT (AYP part number) Price: $3.12 |
| 29 |
323-6 |
SCREW-HH Price: $0.66 |
| 29 |
532071673 |
PLUNGER CAP Price: $3.99 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 30 |
532123780 |
BRKT TRANS LH Price: $4.99 |
| 31 |
20-9530 |
WASHER-END Price: $28.36 |
| 31 |
532123791 |
KEEPER BELT LH Price: $5.99 |
| 32 |
57-6480 |
DISCONTINUED This part replaces 38-6150. Price: Call Us |
| 33 |
298-8 |
DISCONTINUED Price: Call Us |
| 33 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 34 |
237-62 |
DISCONTINUED Price: Call Us |
| 34 |
532151128 |
SHAFT Price: $44.99 |
| 35 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 35 |
532120183 |
BEARING.NYLON Price: $2.99 |
| 36 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 36 |
819211616 |
WASHER LT Price: $3.99 |
| 37 |
3217-7 |
NUT-HEX Price: $0.28 |
| 37 |
532001572 |
Pin, Roll, 3/16 x 1 (AYP part number) Price: $3.99 |
| 38 |
3-8782 |
DISCONTINUED Price: Call Us |
| 38 |
532123674 |
Idler, Flat (AYP part number) This part replaces 532004859. Price: $17.99 |
| 39 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
874760644 |
BOLT Price: $3.99 |
| 40 |
3217-6 |
NUT-HEX Price: $1.19 |
| 40 |
532124965 |
SPACER T This part replaces 532004470. Price: $3.99 |
| 41 |
3-8524 |
SWAGED STRG CABLE ASM Price: $226.19 |
| 41 |
532153399 |
BELT GUIDE Price: $7.99 |
| 42 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 42 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 43 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 43 |
819111012 |
WASHER T Price: $3.99 |
| 44 |
256-268 |
BUSHING Price: $18.24 |
| 44 |
532105706 |
BEARING LT (2 2) Price: $3.99 |
| 45 |
257-4 |
DISCONTINUED Price: Call Us |
| 45 |
532110812 |
WASHER LT Price: $3.10 |
| 46 |
40-7870 |
DISCONTINUED Price: Call Us |
| 46 |
812000039 |
KLIP RING Price: $3.99 |
| 47 |
40-7050 |
DISCONTINUED Price: Call Us |
| 47 |
532139245 |
Pulley, Idler V Groove (AYP part number) This part replaces 532127783. Price: $22.99 |
| 48 |
251-182 |
DISCONTINUED Price: Call Us |
| 48 |
532123789 |
Bellcrank Assembly (Inc. Key No. 54) (AYP part number) Price: $13.07 |
| 49 |
242-36 |
DISCONTINUED Price: Call Us |
| 49 |
532123205 |
RETAIN BELT Price: $3.99 |
| 50 |
232-3 |
TUBE-INNER Price: $30.40 |
| 50 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 (AYP part number) This part replaces 874760624. Price: $3.99 |
| 51 |
231-21 |
DISCONTINUED Price: Call Us |
| 51 |
873680600 |
LOCKNUT Price: $1.99 |
| 52 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 52 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 53 |
3-8542 |
DISCONTINUED Price: Call Us |
| 53 |
532199652 |
LINK.CLUTCH.7.66.2005 This part replaces 532105710. Price: $8.99 |
| 54 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 54 |
532126471 |
CLIP,INSULATOR Price: $2.99 |
| 55 |
323-20 |
SCREW-HH Price: $1.28 |
| 55 |
532105709 |
SPRING, RETURN LT Price: $7.99 |
| 56 |
874760620 |
BOLT Price: $3.99 |
| 56 |
HY2562 |
DISCONTINUED This part replaces 256-2. Price: Call Us |
| 57 |
3-8523 |
DISCONTINUED Price: Call Us |
| 57 |
532123796 |
BELT.GROUND.DRIVE Price: $29.99 |
| 58 |
3257-30 |
KEY-WOODRUFF Price: $5.35 |
| 58 |
532123792 |
KEEPER,BELT RH Price: $3.99 |
| 59 |
3-8521 |
DISCONTINUED Price: Call Us |
| 59 |
532136715 |
Keeper Belt Chassis Span Ctr (AYP part number) This part replaces 532104777. Price: $6.79 |
| 60 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 60 |
532121218 |
Keeper, Belt, Engine, L.H. (AYP part number) Price: $2.86 |
| 61 |
44-0290 |
DISCONTINUED Price: Call Us |
| 61 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 62 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 62 |
532008883 |
PEDAL COVER Price: $3.99 |
| 63 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 63 |
532123795 |
Pulley, Engine (AYP part number) Price: $27.99 |
| 64 |
3290-239 |
DISCONTINUED Price: Call Us |
| 65 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 65 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 66 |
3-9046 |
DISCONTINUED Price: Call Us |
| 67 |
3-8522 |
DISCONTINUED Price: Call Us |
| 68 |
38-1420 |
SWITCH-SEAT Price: Call Us |
| 68 |
532105730 |
KEEPER,BLT ENG LT Price: $2.99 |
| 69 |
322-1 |
SCREW-HH Price: $0.22 |
| 70 |
40-7120 |
DISCONTINUED Price: Call Us |
| 71 |
3217-26 |
NUT-HEX Price: $0.25 |
| 72 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 74 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 74 |
532108097 |
SPACER HYT Price: $3.99 |
| 75 |
25-6250 |
DISCONTINUED Price: Call Us |
| 75 |
532123800 |
WASHER Price: $3.99 |
| 76 |
24-2090 |
STEERING WHEEL CAP Price: $30.55 |
| 76 |
812000053 |
E RING HYT Price: $3.99 |
| 77 |
532009396 |
SQ KEY Price: $3.99 |
| 79 |
532125096 |
KEY STD (1373) DANA This part replaces 532002228. Price: $3.99 |
| 80 |
532123794 |
ARM,SHIFT Price: $2.38 |
| 81 |
532123772 |
Shaft Assembly, Shifter (AYP part number) Price: $13.22 |
| 82 |
532123782 |
SPRING,TORSION Price: $2.99 |
| 83 |
734117771 |
BUSHING This part replaces 819171216. Price: $2.99 |
| 84 |
532123793 |
Rod, Tie (AYP part number) Price: $27.99 |
| 85 |
873610400 |
NUT.FIN HEX 1/4-28 UNF This part replaces 532150360. Price: $2.99 |
| 86 |
532071208 |
BUSHING.STEERING.ROD Price: $3.99 |
| 87 |
819212016 |
WASHER D Price: $3.99 |
| 88 |
812000008 |
KLIP RING Price: $3.99 |
| 89 |
532139992 |
Price: Call Us |
| 90 |
532124346 |
NUT.PUSH.3/16 Price: $3.99 |
| 96 |
532004497 |
RETAINER M Price: $5.99 |
| 110 |
874760612 |
BOLT Price: $1.99 |
| 111 |
532123776 |
Bracket, Transaxle, RH (AYP part number) Price: $4.06 |
| 115 |
819132203 |
WASHER GT Price: $3.99 |
