| Ref | Part Number | Description |
|---|
| 1 |
127-3107 |
GASKET-MANIFOLD, INTAKE Price: $21.63 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
127-3135 |
INTAKE MANIFOLD ASM Price: $518.40 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT Price: $119.99 |
| 3 |
127-3134 |
MANIFOLD-INTAKE Price: $263.05 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
127-3180 |
STUD Price: $3.41 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
127-3031 |
SENSOR-TEMP, AIR Price: $1,039.57 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
125-7220 |
BOLT Price: $4.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
127-3152 |
DUCT-SUCTION Price: $220.31 |
| 8 |
127-3096 |
JOINT-RUBBER Price: $332.63 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
127-3153 |
JOINT-RUBBER Price: $108.13 |
| 10 |
125-7189 |
CLAMP-HOSE Price: $4.61 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
127-3170 |
CLAMP-HOSE Price: $23.69 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
125-7190 |
CLAMP-HOSE Price: $12.29 |
| 13 |
127-3171 |
CLAMP-HOSE Price: $6.48 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
127-3034 |
GASKET-COLLECTOR Price: $9.66 |
| 15 |
127-3093 |
INTAKE COLLECTOR ASM Price: $584.00 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
127-3092 |
COLLECTOR-INTAKE Price: $203.81 |
| 17 |
127-3139 |
VALVE-REED Price: $187.29 |
| 17 |
532190753 |
SHAFT STEERING SPLINE Price: $37.99 |
| 18 |
127-3080 |
JOINT-HOSE Price: $52.33 |
| 19 |
127-3081 |
JOINT-HOSE Price: $79.17 |
| 20 |
127-3166 |
WASHER-SEAL Price: $6.77 |
| 21 |
127-3168 |
SCREW Price: $2.67 |
| 22 |
127-3181 |
STUD Price: $3.97 |
| 23 |
127-3045 |
SPACER-VALVE, E G R Price: $34.81 |
| 24 |
127-3046 |
GASKET-E G R Price: $4.88 |
| 25 |
125-7220 |
BOLT Price: $4.99 |
| 26 |
127-3178 |
BOLT Price: Call Us |
| 27 |
127-3182 |
STUD Price: $2.86 |
| 28 |
125-7229 |
NUT Price: $3.12 |
| 29 |
127-3035 |
BEND-INLET Price: Call Us |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
127-3036 |
BODY-THROTTLE Price: $1,205.87 |
| 31 |
127-3037 |
GASKET-THROTTLE Price: $2.87 |
| 32 |
125-7209 |
BOLT Price: $2.74 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
125-7211 |
BOLT Price: $3.48 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 39 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532199978. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 97 |
596039701 |
Bolts This part replaces 532428982. Price: $3.99 |
| 118 |
532406013 |
BUSHING, AXLE CAST Price: $4.99 |
