Housing & Ignition Assembly
Parts (43)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 140-5567 | SHAFT ASM, GROOMER This part replaces 125-3478. Price: $404.92 |
| 1 | 530058344 | Bolt-Lock Price: $1.99 |
| 2 | 140-5582 | BLADE-GR GROOMER, HELIX (0.015") This part replaces 127-6124. Price: $3.07 |
| 2 | 572L0600 | Nut-Nylon Price: Call Us |
| 3 | 140-5616 | SPACER-SS This part replaces 70-1350. Price: $2.60 |
| 3 | 51123-179 | Case-Fan Price: Call Us |
| 4 | 51125-112 | Fan Price: Call Us |
| 5 | 530089324 | Nut-Hex Price: $1.99 |
| 6 | 51123-178 | Case-Fan Price: Call Us |
| 7 | 36083-105 | Cover-Fan Price: Call Us |
| 8 | 412L0665 | Screw-Socket Price: Call Us |
| 9 | 470L0520 | Screw-Tapping m5x20 Price: Call Us |
| 10 | 530089368 | Isolator-Vibro Rubber Price: $3.33 |
| 11 | 530058346 | Bolt-Lock Price: $0.99 |
| 12 | 530089445 | Assy-Ignition Coil Price: $109.99 |
| 13 | 530094080 | Bolt Price: $0.99 |
| 14 | 920712077 | Grommet Price: $3.33 |
| 15 | 260112321 | Wire-Lead Price: $3.99 |
| 16 | 530094085 | Cap-Spark Plug Price: $3.33 |
| 17 | 530094086 | Terminal Price: $3.33 |
| 18 | 920702107 | Plug-Spark NGK (BPMR7A)solid Price: $9.99 |
| 19 | 490062051 | Boot Price: $2.99 |
| 20 | 920592233 | Tube-6x7.4x300 Price: $1.99 |
| 21 | 920092218 | Screw Price: $2.99 |
| 22 | 922002019 | Washer Price: $1.99 |
| 23 | 591012085 | Reel-Starter Recoil Price: $17.99 |
| 24 | 921442038 | Spring-Recoil Price: $19.99 |
| 25 | 314R1000 | Nut-Hex (fine) Price: Call Us |
| 26 | 920222147 | Washer Price: $3.33 |
| 27 | 210502260 | Flywheel Price: $84.99 |
| 28 | 920382078 | Key Price: $3.99 |
| 29 | 920332010 | Ring-Snap Price: $1.99 |
| 30 | 490802155 | Pulley-Starting Price: $12.99 |
| 31 | 921442046 | Spring-Return Price: $3.99 |
| 32 | 131652070 | Pawl-Recoil Starter Price: $4.99 |
| 33 | 315B0800 | Nut-Hex (fine) Price: Call Us |
| 34 | 410B0800 | W-Plain-S Price: Call Us |
| 35 | 131692386 | Plate-Recoil Starter Price: $2.99 |
| 36 | 530058416 | Grip-Recoil Starter Price: $29.99 |
| 37 | 530058422 | Screw Price: $2.32 |
| 38 | 130702064 | Guide-Rope Price: $4.99 |
| 39 | 591062117 | Rope 3.8x850 Price: $9.99 |
| 40 | 320992210 | Case-Recoil Starter Price: $27.99 |
