| Ref | Part Number | Description |
|---|
| 1 |
115-8092 |
SWASHPLATE This part replaces 110-6482. Price: $863.05 |
| 2 |
75-0400 |
PLATE-THRUST Price: $41.27 |
| 3 |
110-6483 |
BEARING KIT Price: $125.81 |
| 4 |
110-6471 |
SEAL-LIP Price: $50.69 |
| 5 |
95-4400 |
WASHER-BACKUP Price: $7.74 |
| 6 |
69-3200 |
RING-RETAINING Price: $20.29 |
| 7 |
110-6484 |
SHAFT-AUXILIARY Price: $714.38 |
| 8 |
110-6472 |
CYLINDER BLOCK KIT ASM Price: $1,735.97 |
| 9 |
110-6473 |
PLATE-VALVE (CLOCKWISE) Price: $593.29 |
| 10 |
110-6485 |
PIN-SLOTTED Price: $1.97 |
| 11 |
110-6486 |
PLUG-RELIEF, CHARGE Price: $67.11 |
| 12 |
110-6480 |
COUPLING Price: $478.20 |
| 13 |
92-1353 |
SHIM KIT Price: $36.78 |
| 14 |
110-6474 |
SPRING Price: $31.79 |
| 15 |
110-6475 |
POPPET Price: $36.37 |
| 16 |
115-8087 |
CAP-END This part replaces 110-6487. Price: $1,692.55 |
| 17 |
110-6476 |
GASKET-CAP, END Price: $31.07 |
| 18 |
75-0500 |
BEARING-NEEDLE Price: $83.78 |
| 19 |
110-6489 |
SCREW Price: $13.10 |
| 20 |
136-1026 |
PLUG ASM This part replaces 94-9415. Price: $9.75 |
| 21 |
107-4364 |
BYPASS VALVE ASM Price: $166.69 |
| 22 |
110-6491 |
SPRING Price: $26.02 |
| 23 |
110-6492 |
SPOOL-LOOP, FLUSH Price: $103.46 |
| 24 |
110-6493 |
PIVOT-RETURN, NEUTRAL Price: $265.40 |
| 25 |
69-3170 |
RING-RETAINING Price: $11.40 |
| 26 |
75-0460 |
BEARING-BALL Price: $175.71 |
| 27 |
110-6495 |
SPRING-RETURN, NEUTRAL Price: $144.13 |
| 28 |
110-6496 |
NUT-SEAL Price: $10.99 |
| 29 |
110-6497 |
NEUTRAL RETURN ARM ASM Price: $301.72 |
| 30 |
69-3130 |
PLUG Price: $62.97 |
| 31 |
112-0158 |
PIN Price: Call Us |
| 32 |
112-0157 |
SCREW Price: $1.57 |
| 33 |
110-6477 |
VALVE-RELIEF Price: $438.26 |
| 34 |
112-0156 |
ARM-CONTROL Price: $402.93 |
| 35 |
112-0155 |
SCREW Price: $1.07 |
| 36 |
110-6499 |
TRUNNION COVER ASM Price: $262.88 |
| 37 |
94-3936 |
NUT-LOCK, HEX Price: $3.00 |
| 38 |
84-0430 |
O-RING Price: $6.94 |
| 39 |
112-0150 |
SCREW Price: $1.90 |
| 40 |
84-0440 |
COVER-TRUNNION Price: $235.07 |
| 41 |
112-0151 |
SCREW Price: $4.27 |
| 42 |
112-0152 |
BRACKET-SWITCH, NEUTRAL START Price: $29.28 |
| 43 |
100-1270 |
SWITCH-PROXIMITY Price: $96.57 |
| 44 |
112-0153 |
SCREW Price: $3.26 |
| 45 |
112-0154 |
NUT-LOCK Price: $4.70 |
| 46 |
110-6481 |
SEAL KIT Price: $140.87 |
