| Ref | Part Number | Description |
|---|
| 1 |
577013202 |
HANDLE HALF RIGHT Price: $17.99 |
| 1 |
779-3599 |
LABEL-STEERING CAPLARGE Not Available Price: |
| 1 |
98-9512 |
GEAR-CAM Price: $246.18 |
| 2 |
580292901 |
SCREW ITXSCT PW4.2X18 10.9 ZN This part replaces 579211901. Price: $2.99 |
| 2 |
731-3104 |
CAP-STEERI Not Available Price: |
| 2 |
98-9510 |
STOPPER-CAMSHAFT Price: $12.25 |
| 3 |
577512301 |
THROTTLE LOCKOUT Price: $4.99 |
| 3 |
712-3056 |
Nut, Hex Jam, 5/8-18 Price: $4.21 |
| 3 |
98-9378 |
KEY-FEATHER Price: $1.23 |
| 4 |
112-0185 |
TAPPET This part replaces 98-9616. Price: $25.58 |
| 4 |
577013101 |
HANDLE HALF LEFT Price: $17.99 |
| 4 |
736-0187 |
Washer, Flat, .640 X 1.24 X .06 Thk HDN Price: $4.02 |
| 5 |
127-0421 |
ROD-PUSH This part replaces 98-9509. Price: $5.90 |
| 5 |
589377903 |
TRIGGER GRAY This part replaces 589377901. Price: $6.99 |
| 5 |
731-3103 |
STEERING WHEEL Not Available Price: |
| 6 |
577014101 |
COVER Price: $6.99 |
| 6 |
936-3094 |
FLAT WASHER .755X2.0X.0 Not Available This part replaces 736-3094. Price: |
| 6 |
98-7449 |
SCREW-SET Price: $1.83 |
| 7 |
108-6576 |
CAMSHAFT ASM This part replaces 98-9617. Price: $828.79 |
| 7 |
577013002 |
HOUSING RIGHT Price: $32.99 |
| 7 |
735-3028 |
STEERING SHAFT BOOT Not Available Price: |
| 8 |
577996601 |
PUSH BUTTON Price: $3.99 |
| 8 |
741-0338 |
FLANGE BEARING Price: $8.37 |
| 8 |
98-7692 |
BOLT Price: $0.92 |
| 9 |
585480001 |
SPRING PUSH OUT Price: $4.99 |
| 9 |
716-0101 |
Ring, Snap Price: $3.37 |
| 9 |
98-9533 |
SHAFT-GEAR, IDLE Price: $101.45 |
| 10 |
577022201 |
CLAMP Price: $6.99 |
| 10 |
731-3093 |
GUIDE Not Available Price: |
| 10 |
98-9535 |
COLLAR-GEAR, IDLE Price: $2.37 |
| 11 |
577007603 |
HOUSING LEFT Price: $49.99 |
| 11 |
731-3094 |
BUSHING-SHAFT GUIDE Not Available Price: |
| 11 |
98-9649 |
IDLE GEAR ASM Price: $88.78 |
| 12 |
587346001 |
TRIGGER GUARD Price: $19.99 |
| 12 |
732-3064 |
TORSION SPRING Not Available Price: |
| 13 |
587345801 |
BUMPER SKID PLATE Price: $19.99 |
| 13 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 13 |
98-9536 |
COLLAR-GEAR, IDLE Price: $3.41 |
| 14 |
577014201 |
SKID PLATE Price: $17.99 |
| 14 |
911-3295 |
CLEVIS PIN Not Available This part replaces 711-3295. Price: |
| 14 |
98-9534 |
CIRCLIP-GEAR, IDLE Price: $1.69 |
| 15 |
588602803 |
DECAL PRODUCT LIPX Price: $3.99 |
| 15 |
710-3013 |
Screw, Hex Cap, 1/4-20 X .50 Lg GR5 Price: $4.02 |
| 16 |
731-3107 |
TILT CONTROL BUTTON Not Available Price: |
| 17 |
588602801 |
DECAL PRODUCT LIPT5 Price: $3.99 |
| 17 |
703-1805 |
PLATE-TILT CONTROL Not Available Price: |
| 18 |
577844301 |
DECAL Price: $3.99 |
| 18 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 19 |
738-3080 |
SHAFT-UPPER STEER 16.75 LG Not Available Price: |
| 20 |
725-0157 |
Strap, Tie Price: $3.46 |
| 21 |
735-3029 |
COUPLING BOOT Not Available Price: |
| 22 |
748-3030A |
DRIVE COUPLING Not Available Price: |
| 23 |
723-3022 |
BALL-5/8 DIA Not Available Price: |
| 24 |
748-3029 |
HUB-DRIVE Not Available Price: |
| 25 |
721-3025 |
O-RING 2.489 ID x .070 Not Available Price: |
| 26 |
736-3092 |
Washer, Flat, .265 X 1.0 X .030 Thk HDN Price: $3.68 |
| 27 |
748-3033 |
ADAPTER-STEERING Not Available Price: |
| 28 |
710-3213 |
SCREW 1/4-20X1.12 Not Available Price: |
| 29 |
710-3211 |
Screw, Socket Hd Cap, 1/4-20 X 1.75 Lg Price: $4.52 |
