| Ref | Part Number | Description |
|---|
| 1 |
108-2928-01 |
BOX ASM Price: $1,031.60 |
| 2 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $49.99 |
| 3 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
110-1376 |
PIVOT PIN ASM Price: $30.46 |
| 6 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 7 |
144-7097 |
TINE-SCARIFIER This part replaces 110-0259-03. Price: $55.22 |
| 8 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 9 |
283-60 |
PIN-CLEVIS Price: $6.45 |
| 9 |
584908001 |
KEEPER BELT ENGINE This part replaces 532194320. Price: $2.99 |
| 10 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 11 |
23-2790-01 |
BLADE-SCRAPER Price: $323.46 |
| 11 |
532414737 |
KIT.SVC.CLTCH.OG.1.125" This part replaces 532179335. Price: $229.99 |
| 12 |
110-1395-03 |
TOOL BAR ASM Price: $548.35 |
| 12 |
532194343 |
PULLEY ENGINE Price: $44.99 |
| 14 |
23-2770 |
ROD-ACTUATING Price: $97.95 |
| 15 |
23-2740 |
PIN-ACTUATING Price: $94.46 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $99.99 |
| 16 |
108-2288-01 |
SUPPORT-SPRING Price: $45.53 |
| 17 |
20-9420-01 |
COMP SPRING Price: $106.49 |
| 18 |
112-1400 |
PIVOT ASM Price: $241.88 |
| 18 |
584248701 |
CAP.ASSY.FUEL.3".N-EPA.BLK.428 This part replaces 532430218. Price: $7.99 |
| 19 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 20 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN. Price: $19.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 21 |
62-7400 |
DECAL Price: $24.54 |
| 22 |
323-6 |
SCREW-HH Price: $0.66 |
| 22 |
532191596 |
CONTROL CHOKE Price: $24.99 |
| 28 |
532401135 |
LINE.FUEL.64"REAR.EMIS Price: $19.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR(392390 B&S) Price: $129.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
