| Ref | Part Number | Description |
|---|
| 1 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144925. Price: $139.99 |
| 2 |
874760412 |
Bolt Hex Hd 1/4-20unc X 3/4 (AYP part number) Price: $3.99 |
| 3 |
237-68 |
O-RING Price: $3.22 |
| 3 |
819091016 |
Washer 9/32 X 5/8 X 16 Ga. (AYP part number) Price: $2.99 |
| 4 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 4 |
810040400 |
Washer Lock Hvy Helical 1/4 (AYP part number) Price: $3.99 |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
532121264 |
Caps Battery 20/25/30 AMP (AYP part number) Price: $10.91 |
| 6 |
119-4067 |
SCREW-HH Price: $0.81 |
| 6 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 7 |
532109238 |
Tube Plastic 12" (AYP part number) Price: $5.46 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 8 |
532144940 |
Case Battery (AYP part number) Price: $24.99 |
| 9 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 9 |
532109596 |
Clamp Hose Olive (AYP part number) Price: $2.99 |
| 10 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 11 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 12 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 13 |
119-4039 |
NUT-HEX, NI Price: $0.28 |
| 15 |
105-8095-01 |
BEDBAR-FAIRWAY Price: $303.06 |
| 15 |
532144935 |
Screw Cap Hex Nylon 3/8-16 x 1 (AYP part number) Price: Call Us |
| 16 |
119-4151 |
SCREW-BEDKNIFE Price: $0.41 |
| 16 |
532145355 |
Nut, Nylon 3/8-16 (AYP part number) Price: Call Us |
| 19 |
137-6093 |
BEDKNIFE-EDGEMAX LOWCUT This part replaces 127-7132. Price: $166.88 |
| 19 |
810040400 |
LOCKWASHER This part replaces 810090400. Price: $3.99 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $3.99 |
| 21 |
532136850 |
Harness Asm Light W/4152j (AYP part number) Price: $15.99 |
| 22 |
532004152 |
Bulb Light #1156 (AYP part number) Price: $2.99 |
| 23 |
811150400 |
Washer Lock Internal Tooth 1/4 (AYP part number) Price: $2.99 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $6.99 |
| 24 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 25 |
532146147 |
Cable Battery 6 Ga 44" red (AYP part number) Price: $19.99 |
| 25 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 26 |
131-4715 |
WASHER Price: $0.95 |
| 26 |
532108824 |
Fuse 30 AMP Auto Green (AYP part number) Price: $3.99 |
| 27 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 28 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 28 |
532124773 |
Cable Ground 6 Ga 12" black (AYP part number) Price: $4.99 |
| 29 |
127-4284 |
WASHER-SPECIAL Price: $5.88 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $7.99 |
| 30 |
115-5258 |
SPRING-WIRE, FLAT Price: $3.40 |
| 30 |
532140301 |
Switch Ign 4 pos w/lights (AYP part number) Price: $22.99 |
| 31 |
140-5510 |
BEARING-SEALED, STAINLESS This part replaces 115-3296. Price: $28.48 |
| 31 |
532124211 |
Nut Ignition (AYP part number) Price: $3.99 |
| 32 |
115-3299 |
SEAL-FLOCKED Price: $13.85 |
| 32 |
532141226 |
Cover Sw Ignition (AYP part number) Price: $3.99 |
| 33 |
532122147 |
Key Ign Modleded Generic (AYP part number) Price: $4.99 |
| 34 |
137-8427 |
ES REEL+,5IN FWY(22)11 BLD LD(FSR) This part replaces 132-7112. Price: $770.20 |
| 35 |
532108236 |
Bracket Switch Clutch (AYP part number) Price: $2.99 |
| 36 |
817021008 |
Screw Tap Hex #10-24unc X 1/2 (AYP part number) Price: $1.99 |
| 37 |
130-0064 |
INSERT-THREADED, 5 INCH (LH) Price: $42.48 |
| 38 |
130-0063 |
INSERT-THREADED, 5 INCH (RH) Price: $42.48 |
| 38 |
532140336 |
Bracket, Switch, Interlock (AYP part number) Price: $2.42 |
| 39 |
539101080 |
SWITCH, INTERLOCK This part replaces 532109553. Price: $4.99 |
| 40 |
532146058 |
Harness Chassis LT PL Mech (AYP part number) Price: Call Us |
| 41 |
871110412 |
Bolt Blk Fin Hex 1/4 - 20 x 3/4 (AYP part number) Price: $3.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532145673. Price: $14.99 |
| 44 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 45 |
532140844 |
Adapter Ammeter Rectangular (AYP part number) Price: $3.99 |
| 46 |
532141940 |
Protection Wire Loop Price: $3.99 |
