| Ref | Part Number | Description |
|---|
| 1 |
32-4060 |
DISCONTINUED Price: Call Us |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
530042088 |
Muffler Spring Price: $1.99 |
| 3 |
322-3 |
SCREW-HH Price: $0.79 |
| 3 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 4 |
32-2970 |
DISCONTINUED Price: Call Us |
| 4 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 5 |
30-8290 |
DISCONTINUED Price: Call Us |
| 5 |
530012416 |
Cylinder This part replaces 530071359. Price: $17.99 |
| 6 |
32-5850 |
DISCONTINUED Price: Call Us |
| 6 |
530071363 |
Gasket-Cyl/Carb.(kit) Price: $5.99 |
| 7 |
32-4240 |
DISCONTINUED Price: Call Us |
| 7 |
530055535 |
Adaptor-carb. Price: $3.99 |
| 8 |
32103-19 |
WING NUT Price: $1.15 |
| 8 |
530016014 |
Screw Price: $1.99 |
| 9 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 9 |
530071363 |
Gasket-Carb.(kit) Price: $5.99 |
| 10 |
32-1500 |
DISCONTINUED Price: Call Us |
| 11 |
32128-14 |
NUT-HF Price: $0.41 |
| 11 |
530047914 |
Plate-Choke Mounting Price: $3.99 |
| 12 |
3229-3 |
SCREW-CARR Price: $4.49 |
| 12 |
530047916 |
Lever-Choke Price: $1.99 |
| 13 |
30-8120 |
DISCONTINUED Price: Call Us |
| 13 |
530015254 |
Washer Price: $1.99 |
| 14 |
36-7740 |
DISCONTINUED Price: Call Us |
| 14 |
530016353 |
Screw Price: $1.99 |
| 15 |
530016141 |
Screw Price: $1.99 |
| 15 |
66-6140 |
DECAL This part replaces 18-2180. Price: $25.48 |
| 16 |
323-6 |
SCREW-HH Price: $0.66 |
| 16 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 17 |
3256-41 |
WASHER Price: $1.18 |
| 17 |
530049079 |
Cover-Air Box Price: $2.99 |
| 18 |
31-4540 |
DISCONTINUED Price: Call Us |
| 18 |
530047932 |
Foam-Air Filter Price: $1.99 |
| 19 |
30-3550 |
DISCONTINUED Price: Call Us |
| 19 |
530047908 |
Box-Air Price: $3.99 |
| 20 |
32-1510 |
DISCONTINUED Price: Call Us |
| 20 |
530015852 |
Spacer-Choke Price: $1.99 |
| 21 |
32128-21 |
NUT-HF Price: $0.39 |
| 22 |
30-0010 |
DISCONTINUED Price: Call Us |
| 22 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 23 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 24 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 25 |
530071363 |
Gasket-Cylinder(kit) Price: $5.99 |
| 26 |
530036145 |
Spacer-Module Price: $1.99 |
| 27 |
530055160 |
Ignition Module Price: $34.99 |
| 28 |
530015954 |
Screw Price: $1.99 |
| 29 |
530049389 |
Assy-Ground Wire Price: $1.99 |
| 30 |
530049390 |
Assy-Leadwire Price: $0.28 |
| 31 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 32 |
530071356 |
Kit-Momentary Switch Price: $4.99 |
| 33 |
530027569 |
Handle-Starter Price: $1.99 |
| 34 |
530069232 |
Kit - Rope Price: $3.99 |
| 35 |
530016080 |
Screw Price: $1.99 |
| 36 |
530027953 |
Coupling-Drive Price: $1.99 |
| 37 |
530023817 |
Spring-Starter Dog Price: $1.99 |
| 38 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 39 |
530032124 |
Bearing-Outer Price: $4.99 |
| 40 |
530019179 |
Seal-C'case Price: $2.99 |
| 41 |
530015945 |
Retainer Ring-C'case Price: $1.99 |
| 42 |
530032125 |
Bearing-Inner Price: $11.99 |
| 43 |
530049233 |
Shroud Price: $3.33 |
| 44 |
530015880 |
Screw Price: $1.99 |
| 45 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 46 |
530054536 |
Guard-Muffler Price: $1.99 |
| 47 |
530036793 |
Isolator-Shroud Price: $5.99 |
| 48 |
530071363 |
O-Ring-C'case(kit) Price: $5.99 |
| 49 |
530012413 |
Assy-Crankshaft Price: $14.99 |
| 50 |
530036792 |
Isolator-Crankcase Price: $4.99 |
| 53 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 54 |
530015828 |
Washer-Flat Price: $1.99 |
| 55 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 56 |
530016226 |
Retainer-Can Price: $1.99 |
| 58 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 59 |
530049468 |
Assy-Fan Housing Price: $17.99 |
| 61 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 63 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 64 |
530069247 |
Kit-Fuel Line Price: $3.99 |
