| Ref | Part Number | Description |
|---|
| 1 |
115-0080-03 |
SHAFT-CONTROL, SPEED Price: $515.26 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
117-3255 |
BEARING-SIDE FLANGE Price: $19.99 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
323-6 |
SCREW-HH Price: $0.66 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 6 |
323-29 |
SCREW-HH Price: $0.42 |
| 7 |
85-9120 |
SPACER-PIVOT, TILT Price: $4.01 |
| 8 |
251-259 |
BEARING-BALL This part replaces 251-307. Price: $13.67 |
| 8 |
586365702 |
TRAY.BATTERY.FRNT.CARB W/SNAPS Price: $139.99 |
| 9 |
112-5099 |
LINK ASM Price: $76.35 |
| 10 |
115-0084-03 |
ARM Price: $57.94 |
| 11 |
119-1351-03 |
CHANNEL-PIVOT Price: $37.30 |
| 12 |
322-6 |
SCREW-HH Price: $0.45 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
325-4 |
SCREW-HH Price: $0.95 |
| 16 |
52-2891 |
BUSHING-FLANGED, NYLON Price: $3.19 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
323-15 |
SCREW-HH Price: $1.53 |
| 18 |
105-7239 |
ROD-THREADED Price: $40.86 |
| 19 |
1-633131 |
YOKE-LINKAGE, BRAKE Price: $14.99 |
| 20 |
103-1167 |
JOINT-BALL END, LH Price: $30.99 |
| 21 |
103-2399 |
PIN-SPRING, CLEVIS Price: $5.59 |
| 21 |
585436401 |
HARNESS LIGHT ASSY TRACTOR, Price: $22.99 |
| 22 |
3219-20 |
NUT-HEX, LH Price: $1.15 |
| 23 |
52-2860 |
WASHER Price: $0.84 |
| 24 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 Price: $7.99 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 Price: $7.99 |
| 26 |
3217-6 |
NUT-HEX Price: $1.19 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
322-9 |
SCREW-HH Price: $3.09 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
140-6248 |
DAMPER This part replaces 76-8870. Price: $159.54 |
| 28 |
532416588 |
CABLE.GROUND.21"BLK.8GA.90T Price: $11.99 |
| 29 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
119-1415 |
PIN-COTTER, LOCKING Price: $0.22 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
3219-3 |
NUT-HEX Price: $0.34 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
501133001 |
HARNESS.IGN.DASH.CBL.YTGT.PRED Price: $64.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 582042801. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 586161801. Price: $19.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
