| Ref | Part Number | Description |
|---|
| 1 |
75-5450 |
ARM WA - LIFT, RH Price: $822.45 |
| 2 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 3 |
237-78 |
O-RING Price: $3.85 |
| 4 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 5 |
237-21 |
O-RING Price: $0.70 |
| 6 |
75-5880 |
HOSE Price: $87.63 |
| 7 |
98-8069 |
CYLINDER - HYD 1-5/8 This part replaces 83-7480. Price: $778.75 |
| 8 |
75-5330 |
CLAMP- HOSE Price: $31.69 |
| 9 |
67-1750 |
BUSHING Price: $0.92 |
| 10 |
75-5340 |
TUBE Price: $45.89 |
| 11 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 12 |
75-6300 |
DISCONTINUED Price: Call Us |
| 13 |
328-9 |
SCREW-HH Price: $16.42 |
| 14 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 15 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 16 |
75-5210-03 |
BRACKET-SPRING, CENTER This part replaces 75-5210. Price: $94.91 |
| 17 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 18 |
328-7 |
SCREW-HH Price: $4.00 |
| 19 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 20 |
32151-48 |
E-RING Price: $1.41 |
| 21 |
282-4 |
SHACKLE Price: $32.98 |
| 22 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 23 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 24 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 25 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 26 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 27 |
75-4550-03 |
SHAFT-LIFT, CENTER This part replaces 75-4550. Price: $259.44 |
| 28 |
75-5890 |
HOSE Price: $75.32 |
| 29 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 30 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 31 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 32 |
75-5460 |
ARM WA - LIFT, LH Price: $796.56 |
| 33 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 34 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 36 |
75-5370 |
DISCONTINUED Price: Call Us |
| 37 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 38 |
75-5380-03 |
CLAMP BRACKET This part replaces 75-5380. Price: $16.82 |
| 39 |
323-10 |
SCREW-HH Price: $0.89 |
| 40 |
75-5420 |
DISCONTINUED Price: Call Us |
| 41 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 42 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 43 |
106-9208 |
SHORT CYLINDER PIN ASM This part replaces 83-6790. Price: $83.12 |
| 44 |
75-3040 |
CARRIER FRAME WA *B Price: $1,352.49 |
| 45 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 46 |
163-3535 |
CYLINDER-HYDRAULIC This part replaces 75-0780. Price: $582.35 |
| 47 |
75-5900 |
HOSE Price: $78.45 |
| 48 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 49 |
75-6370 |
CAP-SENSOR Price: $8.87 |
| 50 |
99-5301 |
RETAINER KIT This part replaces 32151-94. Price: $7.10 |
| 51 |
75-6310 |
DISCONTINUED Price: Call Us |
| 52 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 53 |
75-5410 |
BRACKET-ARM Price: $12.57 |
| 54 |
110-0009 |
JOINT ARM ASM This part replaces 75-3010. Price: $199.32 |
| 55 |
32121-122 |
PIN-ROLL Price: $2.93 |
| 56 |
323-12 |
SCREW-HH Price: $1.14 |
| 57 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 58 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 59 |
325-4 |
SCREW-HH Price: $0.95 |
| 60 |
75-5910 |
HOSE Price: $69.05 |
| 61 |
83-6780 |
PIN-CYLINDER Price: $130.51 |
| 62 |
93-6687 |
DECAL-NO STEP This part replaces 36-3400. Price: $14.45 |
| 63 |
75-5300 |
ROD - HOSE SUPPORT Price: $27.99 |
| 64 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 65 |
82-6490 |
HOSE Price: $83.18 |
| 66 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 510605901 |
510605901 |
Price: $148.44 |
| 511676501 |
511676501 |
ADAPTER, ENGINE Price: $54.99 |
| 511696808 |
511696808 |
Price: $78.31 |
| 511781206 |
511781206 |
Price: $37.53 |
| 511806100 |
511806100 |
CUTTING DISC-HVT2100 Price: $20.66 |
| 511810400 |
511810400 |
Price: $54.88 |
| 512037704 |
512037704 |
Price: $9.85 |
| 512607703 |
512607703 |
Price: $6.90 |
| 512616304 |
512616304 |
Price: $2.92 |
| 512621000 |
512621000 |
SLOTTED, GUIDE Price: $11.99 |
| 512669607 |
512669607 |
Price: $29.63 |
| 512753700 |
512753700 |
HOOK, SLOTTED GUIDE Price: $24.99 |
| 513649902 |
513649902 |
Price: $31.80 |
| 513790302 |
513790302 |
HVT TRIMMER LINE Price: Call Us |
| 513790500 |
513790500 |
LABEL:"STEP HERE" Price: $16.99 |
| 513790600 |
513790600 |
LABEL:"HOT MUFFLER" Price: $8.99 |
| 513804100 |
513804100 |
LABEL "FINGER WARNING" Price: $3.99 |
| 513833800 |
513833800 |
Price: $8.36 |
| 514005300 |
514005300 |
KEY Price: $5.99 |
| 514009203 |
514009203 |
PIN/PIVOT Price: $4.99 |
| 514042300 |
514042300 |
CLIP/SPRING Price: $4.99 |
| 514086600 |
514086600 |
Price: $1.09 |
| 514094300 |
514094300 |
WASHER, FLAT SLOTTED GUIDE Price: $1.33 |
| 514098000 |
514098000 |
FLAT WASHER Price: $0.42 |
| 514158501 |
514158501 |
Screw Price: $0.96 |
| 514165901 |
514165901 |
FOAM, PLASTIC FILTER Price: $1.50 |
| 514166000 |
514166000 |
FILTER, CLOTH FILTER Price: $3.97 |
| 514168500 |
514168500 |
Price: $3.33 |
| 514604501 |
514945100 |
SCREW This part replaces 514604501. Price: $2.99 |
| 514604503 |
514604503 |
SCREW, SLOTTED GUIDE Price: $0.42 |
| 514630900 |
514630900 |
WASHER Price: $1.46 |
| 514633800 |
514633800 |
Washer, Cup Type Price: $0.34 |
| 514647600 |
514647600 |
Knob Price: $1.50 |
| 514673100 |
514673100 |
SCREW-ON/OFF SWITCH Price: $2.99 |
| 514715000 |
514715000 |
Cable Tie Price: $1.42 |
| 514718000 |
514718000 |
NUT M6 NYLOC GME/D Price: $0.39 |
| 514752400 |
514752400 |
WASHER, SPRING Price: $1.99 |
| 514753400 |
514753400 |
COVER, WIRE INSULATOR Price: $3.99 |
| 514908800 |
514908800 |
Price: $0.83 |
| 514934400 |
514934400 |
Price: $1.31 |
| 514948000 |
514948000 |
Price: $1.97 |
| 514957301 |
514957301 |
WASHER Price: $3.99 |
| 514959600 |
514959600 |
Price: Call Us |
| 514964900 |
514964900 |
Price: $2.12 |
| 531030397 |
531030397 |
TVS600 TECUMSEH ENGINE Price: $420.75 |
| 531030428 |
531030428 |
Price: Call Us |
| 531030429 |
531030429 |
DECAL HVT/LOGO NLA Price: $3.31 |
| 531030430 |
531030430 |
GASKET Price: $1.05 |
| 531030431 |
531030431 |
HEX BOLT Price: $1.22 |
| 531030432 |
531030432 |
DEBRIS SCREEN Price: $52.47 |
| 531030433 |
531030433 |
BRACKET/DEBRIS SCREEN Price: $1.26 |
| 531030434 |
531030434 |
TOP SCREEN COVER SCREW Price: $1.17 |
