| Ref | Part Number | Description |
|---|
| 1 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 1 |
539105897 |
MUFFLER KAWASAKI GEN II Price: $349.99 |
| 2 |
32136-3 |
NUT-SHH Price: $1.22 |
| 2 |
539111093 |
MUFFLER BRACKET BLACK Price: $29.99 |
| 3 |
125-2835 |
HYD CYLINDER ASM Price: $991.83 |
| 3 |
510201702 |
WLDT, CLUTCH TIE DOWN BLK Price: $54.99 |
| 4 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 4 |
539105406 |
ELECTRIC CLUTCH W/CABLE Price: $329.99 |
| 5 |
32151-104 |
RING-RETAINING, EXTERNAL Price: $4.85 |
| 5 |
539106057 |
PULLEY Price: $54.99 |
| 6 |
539100152 |
KEY 1/4" SQ X 1 7/8" Price: $2.99 |
| 6 |
84-5300 |
NUT-JAM Price: $9.99 |
| 7 |
71-4740-03 |
RH TIE ROD END ASM Price: $163.79 |
| 8 |
106-6774 |
JOINT-BALL Price: $79.04 |
| 8 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 9 |
32136-2 |
NUT-SHH Price: $3.55 |
| 9 |
539991120 |
BOLT 7/16F X 2 1/2 Price: $5.99 |
| 10 |
100-2508 |
WASHER-THRUST Price: $24.09 |
| 10 |
539104415 |
KAW PIGTAIL Price: $27.99 |
| 11 |
100-4196 |
RING-RETAINING Price: $1.90 |
| 11 |
539102757 |
CABLE POSITIVE Price: $7.99 |
| 12 |
115-0169 |
WASHER-THRUST Price: $8.92 |
| 12 |
539105409 |
GROUND WIRE (KAW) Price: $6.99 |
| 13 |
100-3362 |
CAP-SPINDLE Price: $44.10 |
| 13 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 14 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 14 |
539107937 |
OIL DRAIN HOSE Price: $2.99 |
| 15 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 15 |
539990761 |
NUT 1/4C CENTER LOCK Price: $2.99 |
| 16 |
117-2986 |
CENTERLINK Price: $152.17 |
| 16 |
539102685 |
LOOM CLIP Price: $3.99 |
| 17 |
325-6 |
SCREW-HH Price: $1.42 |
| 17 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 18 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 18 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 19 |
3218-5 |
NUT-JAM Price: $0.27 |
| 19 |
539109867 |
DOUBLE TUBE CLAMP Price: $5.99 |
| 20 |
117-2984 |
ROD-TIE, REAR Price: $332.69 |
| 20 |
539102759 |
INSULATOR Price: $3.99 |
| 21 |
125-2832 |
REAR LH ARM ASM Price: $169.85 |
| 21 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 22 |
120-0392 |
REAR RH ARM ASM Price: $157.73 |
| 22 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 23 |
117-3137 |
PIN ASM Price: $152.79 |
| 23 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 24 |
120-0238 |
SPACER-CYLINDER Price: $30.48 |
| 24 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 25 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 25 |
99-5105 |
BOLT-SHOULDER Price: $5.89 |
