| Ref | Part Number | Description |
|---|
| 1 |
39-8040-03 |
RH SPINDLE ASM This part replaces 39-8040. Price: $291.38 |
| 2 |
21-2000 |
TIE ROD-STEERING Price: $103.72 |
| 2 |
530042088 |
Muffler Spring Price: $1.99 |
| 3 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 3 |
530071391 |
Kit-Spark Arrestor Price: $7.99 |
| 4 |
32128-23 |
NUT-HF Price: $1.51 |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
325-7 |
SCREW-HH Price: $1.53 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
23-1450 |
DISCONTINUED Price: Call Us |
| 6 |
530071689 |
Kit-Cylinder Price: Call Us |
| 7 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 7 |
530069616 |
Gasket-Cyl./Carb.(kit) Price: $6.99 |
| 8 |
322-3 |
SCREW-HH Price: $0.79 |
| 8 |
530047659 |
Carb. Adaptor Price: $2.99 |
| 9 |
32534 |
Lockwasher Price: Call Us |
| 9 |
530016014 |
Screw Price: $1.99 |
| 10 |
23-1540 |
REAR AXLE PIN WA Price: $80.56 |
| 10 |
530069616 |
Gasket-Carb.(kit) Price: $6.99 |
| 11 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 12 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 12 |
530038747 |
Choke Plate Mounting Price: $1.99 |
| 13 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 13 |
530038686 |
Choke Shutter Price: $1.99 |
| 14 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 14 |
530052431 |
Air Box Price: $1.99 |
| 15 |
33-2890 |
REAR AXLE WA *RO Price: $745.14 |
| 15 |
530015887 |
Screw Price: $1.99 |
| 16 |
256-121 |
WASHER-THRUST Price: $4.55 |
| 16 |
530036569 |
Plate-Filter Support Price: $1.99 |
| 17 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 17 |
530036575 |
Air Filter Foam Price: $1.99 |
| 18 |
25494 |
Bearing Cone Price: Call Us |
| 18 |
530036568 |
Air Filter Cover Price: $1.99 |
| 19 |
231-105 |
TIRE-RIBBED Price: $62.56 |
| 19 |
530015880 |
Screw Price: $1.99 |
| 20 |
217-106 |
WHEEL-8 INCH Price: $141.58 |
| 20 |
530015852 |
Spacer-Choke Price: $1.99 |
| 21 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 21 |
530015254 |
Washer Price: $1.99 |
| 22 |
32136-5 |
NUT-HEX, SLOTTED Price: $2.71 |
| 23 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 23 |
530029924 |
Piston Ring Price: $4.99 |
| 24 |
530015162 |
Piston Pin Retainer Price: $1.99 |
| 25 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 25 |
530069615 |
Connecting Rod Ass'y. Price: $14.99 |
| 26 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 26 |
530069616 |
Gasket-Cylinder(kit) Price: $6.99 |
| 27 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 27 |
530055160 |
Ignition Module Price: $34.99 |
| 28 |
21-2820 |
HUB Price: $269.34 |
| 28 |
530016357 |
Screw Price: $1.99 |
| 29 |
253-129 |
SEAL Price: $21.73 |
| 29 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 30 |
39-8050-03 |
LH SPINDLE ASM This part replaces 39-8050. Price: $247.17 |
| 30 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 31 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 32 |
46-8830 |
REAR STRG. PIVOT W A This part replaces 23-1510. Price: $449.47 |
| 32 |
530016381 |
Screw-Nose Cone Price: $2.99 |
| 33 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 33 |
530016382 |
Nut-Nose Cone Price: $2.99 |
| 34 |
256-242 |
BUSHING Price: $3.32 |
| 34 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 35 |
530071356 |
Kit-On/Off Switch Price: $4.99 |
| 35 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 36 |
3220-5 |
NUT-JAM Price: $0.65 |
| 36 |
530027569 |
Starter Handle Price: $1.99 |
| 37 |
323-6 |
SCREW-HH Price: $0.66 |
| 37 |
530069232 |
Kit-Rope Price: $3.99 |
| 38 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 38 |
530016080 |
Screw Price: $1.99 |
| 39 |
21-2100 |
DISCONTINUED Price: Call Us |
| 39 |
530038604 |
Drive Coupling Price: $1.99 |
| 40 |
24-9830-01 |
AXLE SUPPORT ASM This part replaces 24-9830. Price: $83.43 |
| 40 |
530023817 |
Starter Dog Spring Price: $1.99 |
| 41 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 41 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 42 |
3217-9 |
NUT-HH Price: $0.37 |
| 42 |
530055728 |
Outer Bearing Price: $6.99 |
| 43 |
530071615 |
Kit-C'case Seal Price: $4.99 |
| 44 |
530032125 |
Inner Bearing Price: $11.99 |
| 45 |
530069685 |
Assy.-Fan Hsg/Shroud Price: $22.99 |
| 46 |
530015886 |
Screw Price: $1.99 |
| 47 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 48 |
530054536 |
Guard-Muffler Price: $1.99 |
| 50 |
530054753 |
Assy-Crankshaft Price: $27.99 |
| 53 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 54 |
530015828 |
Washer-Flat Price: $1.99 |
| 55 |
530015775 |
Screw Price: $1.99 |
| 56 |
530027523 |
Retainer-Can Price: $2.99 |
| 58 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 59 |
530069685 |
Kit-Fan Hsg/Shroud Price: $22.99 |
| 61 |
530016379 |
Retainer Price: $2.99 |
| 62 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 63 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 64 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 65 |
530069216 |
Kit-Fuel Line (Large Price: $3.99 |
