| Ref | Part Number | Description |
|---|
| 0010 |
094618MA |
HUB CAP This part replaces 721318. Price: $5.00 |
| 0020 |
0011X3MA |
RING, E .750D .050T This part replaces 720010. Price: $4.92 |
| 0030 |
17X195MA |
WASHER, .765 ID, 1.8 OD, .0598 Thk, Flat ZP This part replaces 722620. Price: $4.26 |
| 0040 |
885693YP |
AXLE, Front This part replaces 885693. Price: $159.99 |
| 0050 |
2176440SM |
BUSHING-0.765IDX This part replaces 2176440. Price: $4.36 |
| 0060 |
1738193YP |
SPACER, .641 ID X.980 0D X 2.0 Long This part replaces 1738193. Price: $5.82 |
| 0070 |
1727902SM |
PLATE, Axle Support This part replaces 1727902. Price: $39.47 |
| 0080 |
2860646SM |
NUT, Hex Flange, 5/8-11 This part replaces 2860646. Price: $9.09 |
| 0090 |
703409 |
NUT, 5/16-18, GR5 This part replaces 1931277. Price: $4.92 |
| 0100 |
1960032SM |
SCREW, Hex Head, 3/8-16 x 1 1/4 This part replaces 1960032. Price: $4.70 |
| 0110 |
1611705SM |
SPACER-0.385IDX0 This part replaces 1611705. Price: $3.85 |
| 0120 |
1751964BMYP |
ROD, Tie This part replaces 1751964. Price: $30.61 |
| 0130 |
1727872ASM |
SPINDLE & CUP ASSEMBLY, R.H. This part replaces 1727872A. Price: $91.15 |
| 0140 |
1930645 |
NUT, Hex, Flange, Locking, 3/8-16 Price: Call Us |
| 0150 |
1751922YP |
WHEEL SPINDLE ASSEMBLY, LH This part replaces 1751922. Price: $89.94 |
| 0170 |
1759842BMYP |
SUPPORT, Front Footrest R.H. This part replaces 1727904. Price: $36.85 |
| 0180 |
703949 |
SCREW, 5/16-18.625 This part replaces 1930601. Price: $3.40 |
| 0190 |
703354 |
SCREW, 5/16-18 This part replaces 1930591. Price: $4.70 |
| 0200 |
885536AYP |
SUPPORT, Front Footrest L.H. This part replaces 885536A. Price: $23.81 |
| 0210 |
1960035SM |
WASHER-0.625(0.64IDX1 This part replaces 1960035. Price: $3.72 |
| 0220 |
2860744SM |
CAPSCREW, Hex Head, 5/8-11 x 3 1/4 This part replaces 2860744. Price: $7.55 |
| 0230 |
1738051YP |
LINK, Drag This part replaces 1738051. Price: $56.13 |
| 0240 |
885694YP |
PEDAL ASSEMBLY, Brake This part replaces 885694. Price: $49.99 |
| 0250 |
1735595ASM |
LATCH, Brake Lock This part replaces 1735595. Price: $9.30 |
| 0260 |
703851 |
BOLT, 5/16-18X1.15 This part replaces 1729576. Price: $4.70 |
| 0270 |
1727935SM |
SPACER-PIVOT 0.330ID This part replaces 1727935. Price: $5.17 |
| 0280 |
1736714AYP |
PEDAL ASSEMBLY, Forward This part replaces 1736714A. Price: $82.79 |
| 0290 |
1727246SM |
PEDAL, Reverse This part replaces 1727246. Price: $19.05 |
| 0300 |
703446 |
BOLT, 5/16-18X1.25 G5 This part replaces 1960223. Price: $3.61 |
| 0310 |
1728024SM |
SPACER, Foot Pedal This part replaces 1728024. Price: $4.41 |
| 0320 |
1728025BMYP |
ACTUATOR, RMO Switch This part replaces 1728025. Price: $5.88 |
| 0330 |
885591YP |
BRACKET, PEDAL PIVOT This part replaces 885591A. Price: $19.98 |
| 0340 |
1727911ASM |
PLATE, Bearing This part replaces 1727911A. Price: $11.40 |
| 0350 |
1758772YP |
LIFT SHAFT ASSEMBLY This part replaces 885579A. Price: $109.99 |
| 0360 |
1727940SM |
BRACKET, Sector Support This part replaces 1727940. Price: $30.99 |
| 0370 |
1751110YP |
GEAR, Steering This part replaces 1751110. Price: $31.79 |
| 0380 |
1728122SM |
SPACER, Sector Gear This part replaces 1728122. Price: $5.09 |
| 0390 |
1960032SM |
SCREW, Hex Head, 3/8-16 x 1 1/4 This part replaces 1960032. Price: $4.70 |
| 0400 |
1930645 |
NUT, Hex Flange, Two Way Lock, 3/8-16 Price: Call Us |
| 0420 |
885508AYP |
BRACKET, Rear Frame, RH This part replaces 885508A. Price: $114.99 |
| 0430 |
885509AYP |
BRACKET, Rear Frame, LH This part replaces 885509A. Price: $114.99 |
| 0440 |
885532AYP |
BRACE, Middle Cross This part replaces 885532A. Price: $28.99 |
| 0450 |
703185 |
BOLT, Round Head, Short Square Neck This part replaces 1931333. Price: $2.87 |
| 0460 |
703409 |
NUT, 5/16-18, GR5 This part replaces 1931277. Price: $4.92 |
| 0470 |
703228 |
SCREW, 5/16-18 X .75 This part replaces 1664847. Price: $3.94 |
| 0480 |
885474AYP |
BRACKET, Transaxle, RH This part replaces 885474A. Price: $58.99 |
| 0490 |
885475AYP |
BRACKET, Transaxle, LH This part replaces 885475A. Price: $88.99 |
| 0500 |
885411AYP |
SUPPORT, Deck, R.H. This part replaces 885411A. Price: $40.99 |
| 0510 |
885412AYP |
SUPPORT, Deck, L.H. This part replaces 885412A. Price: $40.99 |
| 0520 |
5025011X8FS |
BOLT This part replaces 1921333. Price: $3.26 |
| 0530 |
703409 |
NUT, 5/16-18, GR5 This part replaces 1931277. Price: $4.92 |
| 0540 |
885469AYP |
BRACKET, Middle Back Plate This part replaces 885469A. Price: $36.99 |
| 0550 |
885466AYP |
SUPPORT, Upper, Back Plate This part replaces 885466A. Price: $18.39 |
| 0560 |
885467AYP |
SUPPORT, Lower, Back Plate This part replaces 885467A. Price: $25.43 |
| 0590 |
885503AYP |
BRACE, Cross Deck Support This part replaces 885503A. Price: $23.49 |
| 0600 |
703228 |
SCREW, 5/16-18 X .75 This part replaces 1664847. Price: $3.94 |
| 0610 |
885441AYP |
BRACKET, Torque This part replaces 885441A. Price: Call Us |
| 0620 |
885486AYP |
BRACKET, Idler Mount This part replaces 885486A. Price: $15.69 |
| 0630 |
1728990ASM |
CLEVIS, Lift This part replaces 1728990A. Price: $10.52 |
| 0640 |
1727935SM |
SPACER-PIVOT 0.330ID This part replaces 1727935. Price: $5.17 |
| 0650 |
1960044SM |
WASHER-0.312(0.33IDX1 This part replaces 1960044. Price: $3.61 |
| 0660 |
5025011X8FS |
BOLT This part replaces 1921333. Price: $3.26 |
| 0670 |
703332 |
WASHER This part replaces 1919326. Price: $3.72 |
| 0680 |
1960703SM |
WASHER, 5/8 This part replaces 1960703. Price: $3.61 |
| 0690 |
1921977 |
CAPSCREW, Hex Head, 5/16-18 x 1-1/4, G5 Price: Call Us |
| 0700 |
703302 |
WASHER, 5/16 This part replaces 1924874. Price: $3.82 |
| 0710 |
885695BMYP |
BRACKET, Tower Support, LH This part replaces 885695BM. Price: $27.99 |
| 0720 |
885696BMYP |
BRACKET, Tower Support, RH This part replaces 885696BM. Price: $27.99 |
| 0730 |
885791YP |
UPSTOP This part replaces 885791. Price: $11.33 |
