| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 1 |
93-3418 |
GAUGE-OIL, LEVEL Price: $47.16 |
| 2 |
42-8830 |
O-RING Price: $2.96 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
93-7013 |
DIPSTICK TUBE Price: $157.34 |
| 4 |
112-8409 |
FILTER-OIL This part replaces 93-4295. Price: $11.64 |
| 5 |
56-1310 |
SWITCH ASM Price: $40.76 |
| 6 |
92-1920 |
OIL PLUG Price: $15.70 |
| 7 |
92-1921 |
OIL GASKET Price: $3.58 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
93-3422 |
PAN ASSY-OIL Price: $1,053.01 |
| 10 |
67-2340 |
BOLT W/WASHER Price: $2.19 |
| 11 |
93-3414 |
GASKET Price: $2.84 |
| 12 |
48-1990 |
NUT Price: $4.69 |
| 13 |
93-3413 |
DISCONTINUED Price: Call Us |
| 14 |
93-3421 |
BOLT Price: $2.89 |
| 15 |
93-3420 |
PUMP ASSY-OIL Price: $484.04 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
93-3417 |
GASKET Price: $5.02 |
| 17 |
93-3416 |
HOUSING Price: $99.77 |
| 18 |
67-2500 |
PLUNGER Price: $22.88 |
| 19 |
42-8930 |
SPRING MM 407142 Price: $16.42 |
| 20 |
42-7290 |
GASKET-PLUG Price: $7.56 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 21 |
67-2520 |
PLUG Price: $5.65 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 22 |
93-3415 |
RELIEF VALVE ASM Price: $172.00 |
| 23 |
93-4291 |
DISCONTINUED Price: Call Us |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 24 |
93-4296 |
DISCONTINUED Price: Call Us |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $7.99 |
| 25 |
93-4290 |
DISCONTINUED Price: Call Us |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 26 |
93-4285 |
COOLER ASSY - OIL Price: $635.41 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 27 |
93-4297 |
CLAMP-HOSE Price: $5.07 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 28 |
93-4289 |
HOSE - RUBBER OUTLET Price: $47.96 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 29 |
93-4288 |
JOINT - WATER DRAIN Price: $275.25 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 30 |
93-4287 |
O-RING Price: $11.30 |
| 31 |
93-4284 |
SPACER - OIL COOLER Price: $161.67 |
| 32 |
93-4286 |
O-RING Price: $39.16 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 33 |
93-4294 |
HOSE - WATER INLET Price: $17.20 |
| 34 |
42-9440 |
BOLT/WASHER Price: $4.52 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
98-0659 |
COVER - SPIRAL Price: $15.13 |
| 40 |
532401104 |
HARNESS.IGN.DASH.HUQ/P Price: $59.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532400724 |
COVER.TERMINAL.BATTERY Price: $3.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
