| Ref | Part Number | Description |
|---|
| 1 |
32120-14 |
Snap Ring Price: Call Us |
| 1 |
510375601 |
HG_EZT, LT Price: $899.99 |
| 2 |
510375602 |
HG_EZT, RT Price: $899.99 |
| 2 |
98-5339 |
SHAFT - FRONT Price: $88.51 |
| 3 |
596930401 |
Links This part replaces 574030501. Price: $6.99 |
| 3 |
98-5592 |
Coupler Assembly (Incl. Ref. #3-8) This part replaces 98-5594. Price: $642.44 |
| 4 |
596930701 |
Links This part replaces 574030502. Price: $5.99 |
| 5 |
539110411 |
BELT, HYDRO PUMP Price: $27.99 |
| 5 |
98-5592 |
Coupler Assembly (Incl. Ref. #3-8) This part replaces 98-5593. Price: $642.44 |
| 6 |
580624201 |
ROD MOTION CONTROL This part replaces 522945001. Price: $3.99 |
| 7 |
579764601 |
JOINT.HEIM.FEML.5/16.RH.THREAD This part replaces 539115729. Price: $7.99 |
| 8 |
588692502 |
ROD.END.MALE.LH.THREAD This part replaces 539116690. Price: $8.99 |
| 9 |
596718601 |
Coupling This part replaces 539116689. Price: $2.99 |
| 9 |
98-5595 |
WING SCREW Price: $5.49 |
| 10 |
596299801 |
Springs This part replaces 539110342. Price: $2.99 |
| 10 |
98-5567 |
KEY - SQUARE Price: Call Us |
| 11 |
3246-4 |
SCREW-SET Price: $0.75 |
| 11 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 12 |
539120080 |
HG_DISC COG BRAKE 51635 Price: $29.99 |
| 12 |
61-0140 |
JACKSHAFT PULLEY Price: $61.35 |
| 13 |
33124-035 |
DISCONTINUED Price: Call Us |
| 13 |
539120079 |
HG_KIT BRAKE ARM (EZT) Price: $32.99 |
| 14 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 14 |
575507001 |
HG_KIT, HYDRO-GEAR HUB Price: $279.99 |
| 15 |
522941102 |
Links This part replaces 522941101. Price: $4.99 |
| 15 |
76-2460 |
BEARING ASM Price: $67.16 |
| 16 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 16 |
539120785 |
HG_HYDRO FAN 51365 Price: $29.99 |
| 17 |
593852803 |
Spacers This part replaces 510184101. Price: $11.99 |
| 17 |
94-3405 |
BEARING-BALL Price: $22.27 |
| 18 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 18 |
580806502 |
SUPPORT.FRONT.TRANS.PNTX431 This part replaces 522460702. Price: $5.99 |
| 19 |
3245-35 |
SCREW-SET, HSH Price: $0.41 |
| 19 |
510185102 |
EZT MOUNT, REAR, BLACK Price: $32.99 |
| 20 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 20 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 21 |
539101721 |
HCS 5/16C X 2-3/4 Price: $3.99 |
| 21 |
61-2350-03 |
BEARING PLATE This part replaces 61-2350. Price: $18.09 |
| 22 |
32128-10 |
NUT-LOCK, HHF Price: $0.27 |
| 22 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 23 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 23 |
76-2440 |
DISCONTINUED Price: Call Us |
| 24 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 24 |
539976938 |
CAPSCREW Price: $3.99 |
| 25 |
539108535 |
SCR #10-24 X 3/4 Price: $2.99 |
| 25 |
76-2430 |
BRACKET - DEBRIS Price: $10.18 |
| 26 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 26 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 27 |
596433601 |
Nuts This part replaces 539115617. Price: $2.99 |
| 27 |
98-5597 |
KEY-SQUARE Price: $27.37 |
| 28 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 29 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 29 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 30 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 30 |
98-5598 |
PULLEY - JACKSHAFT Price: $365.59 |
| 31 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 32 |
596582301 |
Washers This part replaces 539990055. Price: $2.99 |
| 32 |
98-5596 |
TIE ROD MOUNT - WELDED Price: $181.40 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 34 |
33114-040 |
SCREW-HH Price: $1.22 |
| 34 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
