External Power Unit
Parts (95)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 108-9083 | PLATE-SIDE, RH Price: $328.36 |
| 1 | 530047198 | Flywheel Ass'y. Price: $23.99 |
| 2 | 108-9082 | PLATE-SIDE, LH Price: $328.36 |
| 2 | 530015126 | Flywheel Key Price: $1.99 |
| 3 | 104-3396 | SCREW-HH Price: $0.75 |
| 3 | 530016141 | Screw This part replaces 530015036. Price: $1.99 |
| 4 | 530015123 | Washer Price: $1.99 |
| 4 | 99-8662 | TUBE-SPRING Price: $21.55 |
| 5 | 3218-5 | NUT-JAM Price: $0.27 |
| 5 | 530069288 | Starter Pulley Price: $4.99 |
| 6 | 545008007 | SPRING-STARTER This part replaces 530042023. Price: $5.23 |
| 6 | 87-7270 | WASHER-THRUST Price: $0.89 |
| 7 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 7 | 530038646 | Grommet-Idle Price: $1.99 |
| 8 | 3290-357 | NUT-HHF, WHIZ Price: $0.61 |
| 8 | 530038571 | Grommet-Mixture Price: $1.99 |
| 9 | 110-4079 | SPRING-COMPRESSION Price: $13.57 |
| 9 | 530069772 | Carburetor Kit w/Limiter Caps Price: $47.76 |
| 10 | 530023791 | Air Filter Price: $2.99 |
| 11 | 530015242 | Screw Price: $1.99 |
| 12 | 110-4069 | BRACKET Price: $5.57 |
| 12 | 530019045 | Gasket Price: $1.99 |
| 13 | 115-2007 | ROD-SPRING Price: $34.97 |
| 13 | 530023817 | Starter Dog Spring Price: $1.99 |
| 14 | 530015127 | Flywheel Washer Price: $1.99 |
| 14 | 92-2762 | PIN-HAIR Price: $1.09 |
| 15 | 119-4162 | SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 15 | 530626605 | Nut Price: $1.99 |
| 16 | 530015245 | Screw Price: $1.99 |
| 17 | 110-4058 | BRACKET-CHAIN Price: $32.43 |
| 17 | 530023865 | Spacer Price: $2.99 |
| 18 | 107-7400 | PIN-LYNCH Price: $9.56 |
| 18 | 530015254 | Washer Price: $1.99 |
| 19 | 107-3258 | FRAME Price: $331.61 |
| 19 | 530023805 | Choke Shutter Price: $0.99 |
| 20 | 107-2979 | BOLT-SHOULDER Price: $3.94 |
| 20 | 530029826 | Throttle Trigger Price: $1.99 |
| 21 | 3234-19 | SCREW-HHF Price: $1.73 |
| 21 | 530019252 | Gasket Price: $1.99 |
| 22 | 530053549 | Throttle Wire Price: $0.99 |
| 22 | 67-9410 | WASHER Price: $2.04 |
| 23 | 108-4279 | SPACER-FRAME Price: $8.34 |
| 23 | 530036331 | Reed Valve Price: $1.99 |
| 24 | 108-4284 | TUBE-SUPPORT Price: $60.29 |
| 24 | 530036332 | Reed Stop Price: $1.99 |
| 25 | 110-9713 | CARRIER FRAME ASM Price: $642.24 |
| 25 | 545227101 | SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 26 | 3256-24 | WASHER-FLAT Price: $0.28 |
| 26 | 530014347 | Fuel Cap Ass'y. Price: $4.99 |
| 27 | 323-7 | SCREW-HH Price: $0.65 |
| 27 | 530019093 | Seal-Fuel Tank Price: $1.99 |
| 28 | 114-3972 | CHAIN Price: $8.62 |
| 29 | 112-6564 | BRACKET-CHAIN Price: $47.71 |
| 29 | 530015812 | Screw Price: $1.99 |
| 30 | 530015247 | Screw Price: $1.99 |
| 31 | 530052405 | Handle Cover Ass'y. Price: $3.99 |
| 32 | 530069216 | Line Kit Price: $3.99 |
| 33 | 530023373 | Throttle Wire Boot Price: $1.99 |
| 34 | 530015239 | Screw Price: $1.99 |
| 35 | 530052315 | Carb. Handle Hsg. Price: $8.20 |
| 36 | 530023877 | Fuel Line Fitting Price: $1.99 |
| 37 | 530056402 | Handle-Starter This part replaces 530037485. Price: $2.99 |
| 38 | 530095646 | Fuel Pick-up Ass'y. Price: $2.99 |
| 39 | 530015515 | Locknut Price: $1.99 |
| 40 | 530069232 | Rope Kit Price: $3.99 |
| 41 | 530069602 | Fan Hsg. Kit Price: $26.07 |
| 42 | 530015650 | Screw Price: $1.99 |
| 43 | 530023807 | Choke Knob Price: $1.99 |
| 44 | 530053599 | Carb. Cover Price: Call Us |
| 45 | 530015168 | Screw Price: $1.46 |
| 46 | 530015147 | Wave Washer Price: $1.99 |
| 47 | 530023806 | Choke Lever Price: $1.99 |
| 48 | 530015407 | Screw Price: $0.56 |
| 49 | 530025567 | Isolator Cup Price: $1.99 |
| 50 | 530025566 | Isolator Price: $2.99 |
| 51 | 530069202 | Ignition Module Kit Price: $43.74 |
| 52 | 530015816 | Screw Price: $1.99 |
| 53 | 530069216 | Fuel Line Kit Price: $3.99 |
| 54 | 530039116 | Switch Lead Price: $3.99 |
| 55 | 530015151 | Washer Price: $1.99 |
| 56 | 530025565 | Spacer Price: $0.32 |
| 57 | 530026659 | Bracket-Isolator Price: $1.99 |
| 58 | 530015505 | Bolt Price: $1.99 |
| 59 | 530001648 | Screw Price: $1.99 |
| 60 | 530053732 | Handlebar Ass'y. Price: $14.16 |
| 61 | 530015209 | Washer Price: $1.99 |
| 62 | 530024317 | Isolation Pad Price: $1.99 |
| 63 | 530069286 | Fan Hsg. Screw Kit Price: $4.99 |
| 64 | 952044368 | BAR 14" .050 3/8 041 52DL This part replaces 952044367. Price: $14.99 |
| 65 | 581562101 | ACCY CHN 14" 52DL 3/8 .050 This part replaces 952051209. Price: $17.99 |
| 66 | 530015459 | Screw Price: $1.99 |
| 68 | 530016080 | Rope Retaining Screw Price: $1.99 |
| 69 | 530038312 | Air Baffle Price: $1.99 |
| 70 | 530001726 | Screw Price: $1.99 |
| 72 | 530001711 | Screw Price: $1.99 |
