| Ref | Part Number | Description |
|---|
| 1 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 2 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 3 |
60-2160 |
R-CLIP ASM Price: $8.47 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 5 |
33095-00 |
WASHER-FLAT This part replaces 48-9580. Price: $0.25 |
| 6 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 7 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 8 |
65-5890 |
CAP-END Price: $8.09 |
| 9 |
58-1650 |
ROD-SEAT Price: $110.80 |
| 10 |
82-9340 |
LEVEL SWITCH ASM Price: $201.99 |
| 11 |
65-5870 |
TUBE Price: $20.33 |
| 12 |
71-4040 |
HYD FILLER ASM Price: $69.67 |
| 13 |
353-961 |
FLANGE Price: $29.89 |
| 14 |
32144-107 |
SCREW Price: $0.68 |
| 15 |
353-963 |
GASKET Price: $4.33 |
| 16 |
62-2610 |
STRAINER-CAP, FILLER Price: $22.31 |
| 17 |
46-0670 |
SCREW-PPH Price: $1.89 |
| 18 |
92-9200 |
COVER Price: $276.63 |
| 19 |
60-5580 |
SWITCH-TEMPERATURE Price: $178.50 |
| 20 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 21 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 22 |
58-6820 |
GASKET Price: $13.28 |
| 23 |
58-6530 |
HYD OIL DECAL Price: $12.38 |
| 24 |
60-0050 |
SPRING-TRAY, SEAT Price: $78.73 |
| 25 |
58-1640 |
PIN-PIVOT, SEAT Price: $59.26 |
| 26 |
68-7850 |
STRIP-SEALING Price: $41.39 |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 30 |
58-1580-03 |
FRAME-SEAT This part replaces 58-1580. Price: $402.10 |
| 31 |
58-9830-03 |
PLATE-SEAT This part replaces 58-9830. Price: $355.56 |
| 32 |
5-0652 |
SPACER This part replaces 26-4840. Price: $5.35 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 34 |
2412-102 |
CLAMP-R Price: $6.85 |
| 539101175 |
594944601 |
Bolts This part replaces 539101175. Price: $2.99 |
| 539101331 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 539102582 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 539102612 |
539102612 |
SCREW 3/8C X 2 3/4 HEX CAP Price: $4.99 |
| 539102641 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 539103230 |
539103230 |
IDLER ARM Price: $159.99 |
| 539103257 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 539103258 |
539103258 |
IDLER PULLEY (TALL) Price: $44.99 |
| 539103295 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 539103299 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 539103303 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 539103427 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 539103433 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 539105192 |
539105192 |
DECK SPRING Price: $13.99 |
| 539105476 |
539105476 |
BLADE OEM - 25" Price: $34.99 |
| 539106504 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 539107279 |
539112126 |
PULLEY, 72 This part replaces 539107279. Price: $44.99 |
| 539108449 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 539108450 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 539108754 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 539108758 |
539108758 |
SPACER Price: $1.55 |
| 539108761 |
539112123 |
SPINDLE 72 NLA-ORDER HOUSING This part replaces 539108761. Price: $26.18 |
| 539108773 |
966956101 |
KIT HSG ASM 52/61 This part replaces 539108773. Price: $129.99 |
| 539109660 |
539109660 |
DRAW LATCH Price: $13.99 |
| 539109693 |
594722001 |
Chains This part replaces 539109693. Price: $3.99 |
| 539110737 |
539110737 |
SPRING - TORSION Price: $12.99 |
| 539110739 |
539110739 |
PIN - CLEVIS 5/16 DIA X4.69 ZD Price: $5.99 |
| 539111379 |
539111379 |
DECK W/DECALS 72" HUS Price: $6,799.99 |
| 539111561 |
539111561 |
DECAL, TUNNEL RAM 8" Price: $6.99 |
| 539112120 |
539112120 |
HCS 7/16-20 GD 8 SPEC Price: $24.99 |
| 539976979 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 539976998 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 539977326 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 539990247 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 539990333 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 539990365 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 539990517 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 539990550 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 539990582 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 539990627 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 539990717 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
