| Ref | Part Number | Description |
|---|
| 1 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 1 |
580435801 |
SUBASM.SHAFT.BRAKE.WLDMNT.MED Price: $69.99 |
| 2 |
32121-24 |
PIN-SPRING Price: $0.95 |
| 2 |
574216602 |
SHAFT, LIFT, BLACK Price: $139.99 |
| 3 |
28-9570-03 |
LEVER-PUMP This part replaces 28-9570. Price: $264.06 |
| 3 |
510422902 |
Rods This part replaces 510422901. Price: $4.99 |
| 4 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 4 |
583629301 |
ROD.LATCH.RELEASE This part replaces 516008801. Price: $4.99 |
| 5 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 5 |
510030702 |
Springs This part replaces 510030701. Price: $3.99 |
| 6 |
46-8810 |
STOP-SPRING, LEAF Price: $9.17 |
| 6 |
596482001 |
Springs This part replaces 539118762. Price: $6.99 |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
510207201 |
GRIP, HANDLE, BLACK 4" Price: $5.99 |
| 8 |
3219-2 |
NUT-HEX Price: $0.37 |
| 8 |
510207301 |
BUTTON, PUSH, BLACK Price: $4.99 |
| 9 |
3210-7 |
SCREW-HH Price: $0.61 |
| 9 |
587623001 |
LINK.ASM.RZ.LIFT.SERVICE This part replaces 525847201. Price: $9.99 |
| 10 |
251-259 |
BEARING-BALL Price: $13.67 |
| 10 |
587623001 |
LINK.ASM.RZ.LIFT.SERVICE This part replaces 522858601. Price: $9.99 |
| 11 |
322-17 |
SCREW-HH Price: $2.62 |
| 11 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 12 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 12 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 13 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 14 |
237-21 |
O-RING Price: $0.70 |
| 14 |
539105069 |
E-RING 5/8 Price: $2.99 |
| 15 |
340-143 |
ELBOW-SWIVEL, 90 DEG Price: $58.91 |
| 15 |
589464902 |
NUT.LIFT LNK.7/16-2 This part replaces 532175994. Price: $3.99 |
| 16 |
237-78 |
O-RING Price: $3.85 |
| 16 |
510184901 |
PLASTIC NUT Price: $4.99 |
| 17 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 17 |
72-3710 |
BODY Price: $215.33 |
| 18 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 18 |
72-3720 |
DISCONTINUED Price: Call Us |
| 19 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 19 |
596204201 |
Washers This part replaces 819091216. Price: $2.99 |
| 20 |
72-3550 |
TUBE Price: $79.27 |
| 21 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 22 |
340-99 |
FITTING-HYD, 90 DEG Price: $32.27 |
| 23 |
110-9695 |
HUB-PUMP This part replaces 33-4380. Price: $55.09 |
| 24 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 25 |
3241-5 |
SCREW-SET Price: $0.61 |
| 26 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 27 |
71-4400-03 |
COUPLING-DRIVE This part replaces 71-4400. Price: $64.25 |
| 28 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 29 |
71-4411 |
SPACER Price: $2.42 |
| 30 |
322-8 |
SCREW-HH Price: $1.26 |
| 31 |
71-4410 |
SPACER Price: $5.97 |
| 32 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 34 |
322-10 |
SCREW-HH Price: $0.70 |
| 35 |
321-2 |
SCREW-HH Price: $2.79 |
| 36 |
321-4 |
SCREW-HH Price: $0.99 |
| 37 |
54-9290 |
BRACKET-MOUNTING Price: $16.99 |
| 38 |
237-80 |
O-RING Price: $6.10 |
| 39 |
68-8660 |
FITTING-HYD, 90 DEG Price: $181.88 |
| 40 |
237-81 |
O-RING Price: $2.76 |
| 41 |
23-9740 |
FILTER-OIL, HYDRAULIC Price: $13.14 |
| 42 |
68-8990 |
HEAD-FILTER Price: $153.83 |
| 43 |
323-7 |
SCREW-HH Price: $0.65 |
| 44 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 45 |
353-987 |
FITTING-ELBOW, 90 Price: $74.72 |
| 46 |
68-9650 |
HOSE-AXLE Price: $30.32 |
| 47 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 48 |
70-2620 |
FITTING-HYD, 90 DEG Price: $116.72 |
| 49 |
353-508 |
PLUG-HH Price: $7.96 |
| 50 |
119-2880 |
TRANSMISSION ASM This part replaces 92-8947. Price: $4,321.31 |
| 51 |
41-8760 |
GASKET Price: $5.99 |
| 52 |
86-7220 |
GEAR-PINION Price: $81.33 |
| 53 |
32120-72 |
RING-SNAP Price: $2.09 |
| 54 |
29-6170 |
EXTENDED LEAF SPRING ASM Price: $45.56 |
| 55 |
110-9650 |
LEAF SPRING ASM This part replaces 29-6150. Price: $33.06 |
| 56 |
29-6120-03 |
PUMP PLATE ASM This part replaces 29-6120. Price: $93.02 |
| 57 |
3217-6 |
NUT-HEX Price: $1.19 |
| 58 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 59 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 60 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 61 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 62 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 63 |
237-42 |
O-RING Price: $2.78 |
| 64 |
237-22 |
O-RING Price: $2.43 |
| 65 |
237-30 |
O-RING Price: $2.50 |
| 66 |
54-9300-03 |
COVER-SHAFT, PUMP This part replaces 54-9300. Price: $31.70 |
| 67 |
321-6 |
SCREW-HH Price: $0.25 |
