| Ref | Part Number | Description |
|---|
| 1 |
110-6120 |
ENGINE ASSEMBLY-REPLACEMENT This part replaces 95-6499. Price: $22,658.55 |
| 1 |
174619 |
Chassis Price: Call Us |
| 2 |
176554 |
Drawbar Price: Call Us |
| 2 |
99-8879 |
COUPLING-SPRING, CENTER Price: $643.95 |
| 3 |
17060612 |
Screw 3/8-16 X .75 Price: Call Us |
| 3 |
95-6481-03 |
PLATE-ADAPTER, PUMP Price: $909.81 |
| 4 |
98-0655 |
HYD HOSE ASM Price: $149.15 |
| 5 |
155272 |
Bumper Hood/Dash Price: Call Us |
| 5 |
323-7 |
SCREW-HH Price: $0.65 |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
353-992 |
FLANGE-SPLIT Price: $20.28 |
| 8 |
108-8047 |
GEAR PUMP REPLACEMENT KIT This part replaces 69-2050-03. Price: $4,136.66 |
| 9 |
168337X012 |
Dash P/L Price: Call Us |
| 9 |
354-42 |
FLANGE-SPLIT Price: $14.79 |
| 10 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 10 |
72140608 |
Bolt Carriage 3/8-16 x 1 Price: Call Us |
| 11 |
174996 |
Panel Dash Lh Price: Call Us |
| 11 |
69-5640 |
HOSE-RETURN Price: $36.06 |
| 12 |
145660 |
Clip Tinnerman Price: Call Us |
| 12 |
99-4969 |
TUBE-SUCTION Price: $139.85 |
| 13 |
172105X010 |
Panel Dash Rh Price: Call Us |
| 13 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 14 |
17490608 |
Screw Thdrol 3/8-16 x 1/2 Price: Call Us |
| 14 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 15 |
323-6 |
SCREW-HH Price: $0.66 |
| 16 |
69-9220-03 |
BRACKET-TUBE, SUCTION Price: $23.66 |
| 17 |
159639X428 |
Hood LT/PL Price: Call Us |
| 17 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 18 |
126938X |
Bumper Hood Price: Call Us |
| 18 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 19 |
3217-6 |
NUT-HEX Price: $1.19 |
| 20 |
180679 |
Plate Mtg Battery Fuel Tank Price: Call Us |
| 20 |
325-6 |
SCREW-HH Price: $1.42 |
| 21 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 22 |
3213-2 |
SCREW-HH Price: $1.90 |
| 23 |
124028X |
Bushing Price: Call Us |
| 23 |
33115-030 |
SCREW-HH Price: $0.68 |
| 24 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 24 |
74780616 |
Bolt Fin Hex 3/8-16 x 1 Gr 5 Price: Call Us |
| 25 |
19131312 |
Washer 13/32 X 13/16 X 12 Ga Price: Call Us |
| 25 |
33115-025 |
SCREW-HH Price: $0.61 |
| 26 |
321-6 |
SCREW-HH Price: $0.25 |
| 26 |
73800600 |
Nut Lock Hex W/Ins 3/8-16 Unc Price: Call Us |
| 27 |
95-6465-03 |
RH REAR MOUNT ASM Price: $93.67 |
| 28 |
179844 |
Grille/Lens Asm Price: Call Us |
| 28 |
323-10 |
SCREW-HH Price: $0.89 |
| 29 |
170472X599 |
Lens LT/PL Price: Call Us |
| 29 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 30 |
169470X428 |
Fender Footrest STLT Pnt Price: Call Us |
| 30 |
69-8490-03 |
BRACKET-CABLE, THROTTLE Price: $22.94 |
| 31 |
136619 |
Bracket Fender Price: Call Us |
| 31 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 32 |
33113-016 |
SCREW-HH Price: $0.34 |
| 33 |
179716X428 |
Footrest Pnt Lh Price: Call Us |
| 33 |
32128-21 |
NUT-HF Price: $0.39 |
| 34 |
179717X428 |
Footrest Pnt Rh Price: Call Us |
| 34 |
95-6489-03 |
DISCONTINUED Price: Call Us |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 35 |
72110606 |
Bolt Rdhd Sht Sqnk 3/8-16 x 3/4 Price: Call Us |
| 36 |
33116-050 |
SCREW-HH Price: $15.13 |
| 37 |
17490508 |
Screw Thdrol 6/16-18 x 1/2 TYT Price: Call Us |
| 38 |
175710 |
Bracket Asm Pivot Mower Rear Price: Call Us |
| 38 |
95-6470-03 |
LH FRONT MOUNT ASM Price: $109.73 |
| 39 |
32128-23 |
NUT-HF Price: $1.51 |
| 40 |
98-3023 |
WASHER Price: $10.18 |
| 41 |
95-6486 |
SPACER-MOUNT Price: $11.33 |
| 42 |
98-0830 |
RETAINER-MOUNT Price: $19.21 |
| 43 |
98-3024 |
MOUNT-ENGINE Price: $103.88 |
| 44 |
323-38 |
SCREW-HH Price: $2.62 |
| 45 |
325-9 |
SCREW-HH Price: $1.87 |
| 46 |
33116-030 |
SCREW-HH Price: $1.56 |
| 47 |
95-6467-03 |
RH FRONT MOUNT ASM Price: $99.77 |
| 48 |
95-6465-03 |
RH REAR MOUNT ASM Price: $93.67 |
| 49 |
282-28 |
CLEVIS-ADJUSTABLE Price: $58.02 |
| 50 |
77-2990 |
CABLE-THROTTLE Price: $348.96 |
| 51 |
69-0090 |
PIN-THROTTLE Price: $18.93 |
| 51 |
73800400 |
Nut Lock Hex W/Ins 1/4-20 Price: Call Us |
| 52 |
19091416 |
Washer 9/32 x 7/8 x 16 Ga. Price: Call Us |
| 52 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 53 |
144697 |
Bracjet Grukke Lh Price: Call Us |
| 54 |
161464 |
Screw Hex Wshd 8-18 x 7/8 Price: Call Us |
| 54 |
93-3526 |
SWITCH Price: $177.42 |
| 55 |
144696 |
Bracket Grille Rh Price: Call Us |
| 55 |
67-4510 |
GUAGE-TEMP, WATER Price: $151.90 |
| 56 |
51-5070 |
SWITCH-THERMAL Price: $149.69 |
| 57 |
69-1750 |
DISCONTINUED Price: Call Us |
| 57 |
74780412 |
Bolt Hex 1/4-20 x 3/4 Price: Call Us |
| 58 |
174930 |
Duct Air Price: Call Us |
| 58 |
99-4968 |
TUBE-SUCTION Price: $199.94 |
| 64 |
154798 |
Dash Lower STLT Price: Call Us |
| 142 |
175702 |
Plate Reinforcement STLT Price: Call Us |
| 145 |
156524 |
Rod Pivot Chassis/Hood Price: Call Us |
| 159 |
169473X428 |
Cupholder Price: Call Us |
| 206 |
170165 |
Bolt Shoulder 5/16-18 Price: Call Us |
| 207 |
17670508 |
Screw Thdrol 5/16-18 x 1/2 Price: Call Us |
| 208 |
17670608 |
Screw Thdrol 3/8-16 x 1/2 Price: Call Us |
| 212 |
156229 |
Insert Lens Relect Price: Call Us |
| 219 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
