| Ref | Part Number | Description |
|---|
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 503478901 |
503478901 |
SPACER Price: $3.99 |
| 503479001 |
503479001 |
SCREW Price: $2.99 |
| 503479601 |
503479601 |
SCREW Price: $2.99 |
| 503479701 |
503479701 |
INLET NEEDLE Price: $8.99 |
| 503480001 |
537020801 |
PIN This part replaces 503480001. Price: $2.99 |
| 503480101 |
503480101 |
SCREW Price: $2.99 |
| 503480501 |
503480501 |
SCREW Price: $2.99 |
| 503481101 |
503481101 |
PLUG Price: $3.99 |
| 503481801 |
503481801 |
SCREW Price: $2.99 |
| 503535601 |
503535601 |
PLUG Price: $3.99 |
| 503535701 |
503535701 |
STRAINER Price: $3.99 |
| 503665901 |
503665901 |
LEVER Price: $3.99 |
| 503974301 |
503974301 |
COVER Price: $5.99 |
| 531004552 |
531004552 |
GASKET KIT (ZAMA GND39) Price: $9.99 |
| 537012501 |
537012501 |
BALL Price: $2.99 |
| 537012601 |
537012601 |
SPRING Price: $2.99 |
| 537019701 |
537019701 |
SPRING THROTTLE Price: $2.99 |
| 537020001 |
537020001 |
PUMP DIAPHRAGM Price: $7.99 |
| 537020101 |
537020101 |
GASKET Price: $3.99 |
| 537020401 |
537020401 |
GASKET Price: $3.99 |
| 537048901 |
537048901 |
DIAPHRAGM Price: $11.99 |
| 537134901 |
537134901 |
SPRING Price: $2.99 |
| 537266801 |
537266801 |
CHOKE FLAP Price: $4.99 |
| 537273301 |
537273301 |
COVER Price: $32.99 |
| 537273401 |
537273401 |
SPRING Price: $4.99 |
| 537273701 |
537273701 |
SCREW Price: $12.99 |
| 537273801 |
537273801 |
SHAFT Price: $22.17 |
| 537274101 |
537274101 |
ARM Price: $5.99 |
| 537274301 |
537274301 |
ARM Price: $4.78 |
| 537274401 |
537274401 |
WASHER Price: $3.16 |
| 537387501 |
537387501 |
SCREW Price: $12.99 |
| 537388301 |
537388301 |
THROTTLE FLAP Price: $5.99 |
| 537413501 |
537413501 |
NOZZLE Price: $17.99 |
| 537416901 |
537416901 |
IDLE SCREW Price: $7.99 |
| 537417001 |
537417001 |
LIMITER CAP KIT Price: $5.99 |
| 544119001 |
544119001 |
SHAFT Price: $16.99 |
